The OPITEC handicraft packs are not toys in a typical off-the-shelf sense, but rather
additional teaching and learning material for educational purposes. This craft pack
may only be constructed by children and adolescents under the guidance and su-
pervision of experienced adults. Not suitable for children under 36 months. Cho-
Stocklist
Raised Countersunk Screw - Philips
Cylinder Head Bolt
Nut
Wingnut
Washer
Wooden Ball
Wooden Ball
Pine Strip
Gabon Plywood
Acrylic Sheet
Aluminium Sheet
1
Please note:
king hazard!
Quantity
6
1
1
1
2
1
6
1
1
1
1
117558
Tools required:
Drill Bit ø 3
ø 4, ø 10
Pencil or Ed-
ding Marker
Slot Screwdri-
ver
Size (mm):
2,9X9,5
4x30
M 4
M 4
M 4
ø25
ø50
100x15x15 mm
210x170x4 mm
170x170x2 mm
170x170x0,8 mm
Philips
Fretsaw
Screwdriver
Sandpaper
Ruler
Round File
Wood Glue
Description
Fixing
Fixing
Fixing
Fixing
Fixing
Game Ball
Game Ball
Spacer Pieces
Ball Holder
Cover
Base Plate
File
Wrench
Part-No.
1
2
3
4
5
6
7
8
9
10
11
Advertisement
Summary of Contents for Opitec Indoor & Outdoor Boccia
- Page 1 Marker Please note: The OPITEC handicraft packs are not toys in a typical off-the-shelf sense, but rather additional teaching and learning material for educational purposes. This craft pack may only be constructed by children and adolescents under the guidance and su- pervision of experienced adults.
- Page 2 Instruction Manual 117.558 Indoor & Outdoor Boccia ø4, ø3, ø10 ø10 Copy the template (page 4) to the acrylic glass or just fix the template Copy the template (page 5) to the aluminium sheet or just fix the tem- to the acrylic sheet with sellotape. Drill ø4 and ø10 holes . plate to the aluminium sheet with sellotape.
- Page 3 Instruction Manual 117.558 Indoor & Outdoor Boccia Screw the aluminum sheet (11) onto the spacer pieces using bolts (1). Put the wooden balls (6&7) into the appropriate holes. Place the cover (10) on the cylinder head bolts (2), align it with the Done! wooden balls and then fasten it with wing nuts (4).
- Page 5 Instruction Manual 117.558 Indoor & Outdoor Boccia Template S 1:1 Acrylic Sheet - Cover...
- Page 7 Instruction Manual 117.558 Indoor & Outdoor Boccia Template S 1:2 Aluminum Sheet - Base Plate...
- Page 9 Instruction Manual 117.558 Indoor & Outdoor Boccia Template S 1:3 Plywood - Ball Holder...
