Scheda Elettronica
Printed Circuit Board
Codice scheda/circuit board model
MVECS504R
MVECS506R
MVECS510R
MVECS515R
MVECS204R
MVECS206R
MVECS210R
MVECS215R
•
Disconnettere l'alimentazione principale;
•
Disconnettere il cavo del solenoide e del motore (ove pre-
sente);
•
Rimuovere la morsettiera estraibile;
Valido per / valid for MVE5.R (24 Vad/dc)
st
1° Emissione / 1
Issue rev. a
PARTI DI RICAMBIO / SPARE PARTS
09/20
1
MVECSxxxR
Modello attuatore/Actuator model
MVE504R, MVE504SR, MVE504R-65, MVE504SR-65
MVE506R, MVE506SR, MVE506R-65, MVE506SR-65
MVE510R, MVE510SR, MVE510R-65, MVE510SR-65
MVE515R, MVE515SR, MVE515R-65, MVE515SR-65
MVE204R, MVE204SR, MVE204R-65, MVE204SR-65
MVE206R, MVE206SR, MVE206R-65, MVE206SR-65
MVE210R, MVE210SR, MVE210R-65, MVE210SR-65
MVE215R, MVE215SR, MVE215R-65, MVE215SR-65
•
Disconnect main power supply;
•
Disconnect solenoid and motor cable (where present);
•
Remove the removable terminal block;
Valido per / valid for MVE2.R (230 Vdc)
CONTROLLI S.p.A. - 16010 Sant'Olcese (GE) - Italy
Tel. +39 010 73061 | Fax +39 010 7306870/871
info@controlli.eu | www.controlli.eu
DPR029
Advertisement
Related Manuals for Controlli MVECS R Series
Summary of Contents for Controlli MVECS R Series
- Page 1 Valido per / valid for MVE5.R (24 Vad/dc) Valido per / valid for MVE2.R (230 Vdc) 1° Emissione / 1 Issue rev. a 09/20 DPR029 CONTROLLI S.p.A. - 16010 Sant’Olcese (GE) - Italy Tel. +39 010 73061 | Fax +39 010 7306870/871 info@controlli.eu | www.controlli.eu...
- Page 2 • Rimuovere la vite “A” con la relativa colonnina; • Remove “A” screw with the corresponding column; • Rimuovere le colonnine in plastica “B” (per facilitare l’ope- • Remove the plastic supports “B” (use small pliers to crimp razione stringerne l’estremità superiore con delle piccole their upper ends in order to ease the operation);...
