RFID Reader for FireCR Dental
The RFID reader supports Direct Connection Mode for a single FireCR Dental
reader with a single computer and Network Sharing Mode for multiple FireCR
Dental readers with multiple computers. This manual describes Network Sharing
Mode using .
3DISC RFID Reader are trademarks of 3D Imaging & Simulations Corp, South Korea, and its
affiliates. All other trademarks are held by their respective owners and are used in an editorial
fashion with no intention of infringement. The data in this publication are for illustration purposes
only and do not necessarily represent standards or specifications, which must be met by 3D
Imaging & Simulations Corp.
purposes only, and characteristics of the products and services described in this publication can
be changed at any time without notice. Products and services may not be available in your local
area. Please contact your local sales representative for availability information. 3D Imaging &
Simulations Corp. strives to provide as accurate information as possible, but shall not be
responsible for any typographical error.
© Copyright 2013 3D Imaging & Simulations Corp, all rights reserved, printed, and published
in South Korea by 3D Imaging & Simulations Corp.
User Manual
Doc No. : TM-501-EN
Rev 0.1.4 Oct. 2013
Part No. : CR-FPM-54-001-EN
All information contained herein is intended for guidance
Advertisement
Table of Contents
Summary of Contents for 3Disc FireID
- Page 1 Rev 0.1.4 Oct. 2013 Part No. : CR-FPM-54-001-EN 3DISC RFID Reader are trademarks of 3D Imaging & Simulations Corp, South Korea, and its affiliates. All other trademarks are held by their respective owners and are used in an editorial fashion with no intention of infringement. The data in this publication are for illustration purposes only and do not necessarily represent standards or specifications, which must be met by 3D Imaging &...
- Page 2 User Manual FireID TM-501-EN Contact 815, Tamnip-Dong, Yuseong-Gu, Daejeon, Korea Tel : 82-42-931-2100 Fax : 82-42-931-2299 Website : www.3DISCimaging.com E-mail : info@3DISCimaging.com 3DISC Americas 22560 Glenn Dr, Suite 116 Sterling, VA 20164 USA Tel : 1-703-430-6080 E-mail : info@3DISCimaging.com 3DISC Europe...
- Page 3 User Manual FireID TM-501-EN The device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. NOTE : This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules.
- Page 4 User Manual FireID TM-501-EN Warnings and Used Symbols To ensure the safety of patients, staff and other persons, any changes to software and hardware delivered by 3D Imaging & Simulations Corp. may only be made with prior written permission from 3D Imaging & Simulations Corp.
- Page 5 User Manual FireID TM-501-EN General Safety Guidelines All the safety and operating instructions should be read carefully before this device is operated. This device has been designed and tested to meet strict safety requirements applicable to medical equipment, and has been supplied in a safe condition. To ensure personnel and patient safety, the device shall be operated and serviced in compliance with all procedures, warnings and precautions during all phases of operation and service of this device.
-
Page 6: Table Of Contents
User Manual FireID TM-501-EN Table of contents Chapter 1. Introduction ..............7 Chapter 2. Unpacking..............8 Inspection for Damage ..............8 Identify the Components..............8 Chapter 3. Setting Up ..............10 Connection ..................10 PC Driver Installation on the PC............11 Computer Requirements .............. -
Page 7: Chapter 1. Introduction
TM-501-EN Chapter 1. Introduction Dear Customer Thank you for choosing the RFID Reader to complement your 3DISC Imaging FireCR Dental Reader. The advanced technology of the RFID Reader provides quick and accurate registration of data relevant to each individual patient. By pre-registering the unique tag code and imaging plate on the , the scanned image, imaging plate size information and the serial number of the imaging plate are automatically assigned to the individual patient file. -
Page 8: Chapter 2. Unpacking
User Manual FireID TM-501-EN Chapter 2. Unpacking Inspection for Damage is shipped in a custom designed container to protect the from external shock. Before unpacking the product, inspect the shipping container for damage. In case the container is damaged, notify the shipper immediately. - Page 9 User Manual FireID TM-501-EN ARNING If the FireID needs to be returned to manufacturer or one of its representatives, the reader must be repacked in the original container with all accessories. ARNING Improper disposal of this product may result in environmental contamination.
-
Page 10: Chapter 3. Setting Up
User Manual FireID TM-501-EN Chapter 3. Setting Up ARNING Unsuitable Installation Sites Locations with excessive humidity or dust Locations subject to high temperature Locations subject to shaking or vibration Locations exposed to considerable electrical or magnetic noise, or other forms of electromagnetic energy... -
Page 11: Pc Driver Installation On The Pc
User Manual FireID TM-501-EN PC Driver Installation on the PC The Windows driver for will be located and installed automatically if the PC is connected to the internet. If internet is not available or the driver installation did not complete normally (see Figure 4), the driver for the will need to be installed manually with the driver file provided. - Page 12 User Manual FireID TM-501-EN When the driver is installed correctly, a USB Serial Converter is added under Universal Serial Bus Controller category and a new USB Serial Port is displayed under Ports category. Figure 5. Driver is installed correctly.
-
Page 13: Computer Requirements
User Manual FireID TM-501-EN Computer Requirements Recommended Requirement Operation System Microsoft Windows 7 or Windows 8 (32 bit or 64 bit) Core Duo / Core2 Processor Memory RAM 4GB or more Hard Disk 300GB Free Hard Disk Space Network 100Mbps Ethernet for Network Sharing Mode 2.0 HighSpeed... -
Page 14: Chapter 4. Operation
User Manual FireID TM-501-EN Chapter 4. Operation System Specifications Dimension 27 x 60 x 96 (H x L x W) Weight Frequency 13.56MHz Protocol ISO 15693 Interface Mini USB B Power Supply USB Power * Specifications subject to change without notice. -
Page 15: Operating Instructions
User Manual FireID TM-501-EN Operating Instructions Before an imaging plate is scanned from a FireCR Dental reader that is connected to a router through an Ethernet cable, the imaging plate should be tagged on the in order to identify the target PC. -
Page 16: Chapter 5. Symbols
User Manual FireID TM-501-EN ARNING Do not pull out the USB cable during tag information reading. Chapter 5. Symbols Symbol Description... - Page 17 User Manual FireID TM-501-EN Manufacturer Warning, Consult Accompanying Documents General mandatory action manual General prohibition indication User Manual Reference Keep Dry Fragile Handle with care This side up Non-ionizing electromagnetic radiation CE Mark...
-
Page 18: Manufacturer's Declaration
User Manual FireID TM-501-EN Manufacturer’s Declaration- Electromagnetic Emission The RFID reader system is intended for use in the electromagnetic environment specified below. The customer or the user of RFID reader system should assure that it is used in such an... - Page 19 User Manual FireID TM-501-EN Radiated RF 3 V/m 3 V/m Recommended separation distance IEC 61000-4-3 80.0 MHz to 2.5 GHz 80.0 MHz to 2.5 GHz Where P is the maximum output power rating of the transmitter watts according to the transmitter...
-
Page 20: G U I D A N C E A N D M A N U F A C T U R E R 'S D E C L A R A T I O N
User Manual FireID TM-501-EN system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the system can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the system as recommended below, according to the maximum output power of the communications equipment. - Page 21 User Manual FireID TM-501-EN Radiated RF 3 V/m 3 V/m Field strengths outside the shielded IEC 61000-4-3 80.0 MHz to 2.5GHz 80.0 MHz to 2.5GHz location from fixed RF transmitters, as determined by an electromagnetic site survey, should be less than 3V/m.a...
-
Page 22: Chapter 6. Warranty And Repair Service
User Manual FireID TM-501-EN Chapter 6. Warranty and Repair Service Standard Warranty 3D Imaging & Simulations Corp. warrants its non-consumable hardware products to be free from defects in materials and workmanship. The warranty covers the cost of parts and labor to repair the product. -
Page 23: Shipping
User Manual FireID TM-501-EN Shipping The RFID Reader is a solidly built accessory designed to survive shipping around the world. However, in order to avoid damage during shipping, the RFID Reader must be properly packaged. In general, the best way to package the RFID Reader is in the original factory container. If this is no longer available, we recommend that user carefully wraps the RFID Reader in at least 25 mm (1 inch) of foam or bubble pack sheeting. - Page 24 Fax : +82-42-931-2299 E-mail : support@3DISCimaging.com Date of Installation : Customer Information Hospital / Institute Name Address E-mail Installer Information Company Name Address E-mail System Information Model FireID Reader System S/N Installer’s Signature: Date: Customer’s Signature: Date:...
