Summary of Contents for ARBRO LD1
- Page 1 ARBPRO LD1 Instruction Manual IMPORTANT INFORMATION Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference.
-
Page 2: Table Of Contents
LEGENDA: Warnings..............Page 2 Description and technical feautures.......Page 3 Working area............Page 4 Rigging rope ............Page 4 Installation..............Page 4/5 Use.................Page 5/6/7/8 Transport, maintenance and care......Page 8 Symbols and identification........Page 8 IDENTIFICATION OF SYMBOLS: WARNING! This device can be dangerous. Careless or improper us can cause serious or even fatal injury. Read and understand the instruction manual before using the device Protective Gear... - Page 3 Winch/Arborist Lowering Device Attention danger! Use of this device is only permitted in tree care. Professional trained persons can only use this product and in total respect of the instructions written in this manual. The instruction manual can only give indications on the correct use of the device and can not replace professional training in tree care rigging operations.
- Page 4 1. Description ARPRO LD1 is a combined tool, thanks to the multi function main frame can hold a powerful winch or a simple descending brake 2. Components and technical features Main Frame – Steel 10 mm dimensions cm 37*32*10 Winch- Manufacturer Harken Type 40.1 Maximum pulling force kg 800...
-
Page 5: Working Area
5/8”) 5. Installation ARBPRO LD1 can be installed on the same tree where the job will be done or on a different tree. User must be sure that the tree is strong enough. Two different types of installation are possible: -”Light”... -
Page 6: Use
- “Heavy”. This installation offer best anchor of Fig. 5 the device. Can be used only if the tree has to be removed. Remove rubber pads from the back of the main frame. Cut the tree (cm 22 x 4) using a chainsaw allowing the stabilisation plate (7) to fit inside. - Page 7 From a side view rope angle must be 0°. Different angles are not correct and potentially dangerous. Fig. 7 If ARBPRO LD1 is in a position not allowing correct rope entry angles, it is imperative to redirect the rope to obtain a correct installation.
- Page 8 Pull: Fig. 8 Turn the handle clockwise to obtain a 40,1:1 pulling rate. Turn the handle anticlockwise to obtain a 13,4:1 pulling rate Attention! Pulling winch handle is strictly a one man operation. User must NEVER stay in the rigging direction if any part of the rigging system should fail Lowering:...
- Page 9 6.3 Using ARBPRO LD1 with descending brake installed: - remove stopper frame opening locking pin - remove rope guide opening locking pins - insert tube in place with “top” sign pointing up. Lock it with pin - instal rope as shown. Rope must pass back of the guides (left and right) to avoid overlapping - it is possible to change breaking force by changing the number of wraps (more wraps more breaking force).
-
Page 10: Transport, Maintenance And Care
Repairs For repairs only address to manufacturer or distributor. 8. Simbols and identification On the main frame of ARBPRO LD1 there is a tag for identification and control wich gives essential product information: - Product name and model - Serial number... - Page 11 Bambin Sementi s.n.c. Di Mazza V. & C. Via Briantina, 25 20038 SEREGNO – Italy VAT# IT02088760968 Declares under his responsability that the following brand new product: ARBPRO LD1 Product Type: SEE PRODUCT TAG Serial Number: SEE PRODUCT TAG Year of production:...
