- Page 1 Moisture Barrier Instruction Sheet Document No. 360-0169-01 (Revision A) Sensidyne, LP 1000 112 Circle N, Suite 100 St. Petersburg, Florida 33716 USA 800-451-9444 • +1 727-530-3602 • +1 727-539-0550 [fax] web: www.sensidyne.com • e-mail: info@sensidyne.com...
- Page 2 Moisture Barrier • The Plus series Moisture Barrier can be used with SensAlert Plus and SensAlert ASI Transmitters. The plus Moisture Barrier needs to be held in place by the Sensor Shield or the Rain Shield. The SensAlert Plus Moisture Barrier part numbers are listed below: 821-0201-01 ...ASSY, MOISTURE BARRIER...
- Page 3 Barrier into its machined slot. 5) Re-attach the Sensor Holder to the Sensor Interface Assembly on the Transmitter by aligning the Dowel Pins with the Holes in the Holder. Secure the Sensor Holder by tightening the Interface Ring. Sensidyne Document No. 360-0096-01 (Rev A)
- Page 4 2) Remove the Sensor Shield (or Rain Shield) from the Sensor Holder. Turn the Sensor Holder over to remove Moisture Barrier. If the Moisture Barrier fails to drop out, The Sensidyne magnetic screwdriver or a similar small screw driver can be used to push into the half moon access slot in the top of the Sensor Holder (at the edge of the sensor opening).
