QUICK START GUIDE
TBS Remote battery switch
12V: DCM RBS 12V-500A
24V: DCM RBS 24V-500A
TBS RBS CONNECTIONS
WARNING
- Always consult the latest manual on the TBS website to be
informed about pre-cautions and specifications.
- The TBS relay is delivered default bi-stable mode. Please
use the manual to put the relay in mono-stable mode.
- A complete power loss of the system (eg. Fuse blow or
wire cut) might cause the TBS relay to stay in the last
position since in basics it is a bi-stable relay. This means
that it might stay on. When replacing the fuse it might
lead to the system turning on again leading to an unsafe
v +
situation. Please verify if this behavior fits the safety
requirements in your system or contact Super B.
switch on/o
Not used
Optional feedback signal
ww w. su pe r- b. co m
CONNECTING A TBS
RBS TO A NOMIA
NOMIA
Version 1.0
