Groups

Receivers can be configured with a group (from 0 to 7) so that there is no interference when working near each other.

Group configuration

The configuration can be carried out with the programming tool or by self-programming as follows.
Self-programming: After the receiver has been totally reset, it will be configured with the group of the first radio-pro-
grammed transmitter by enabling the hands free mode.
Exception: If the receiver has been configured using programming tools, the group may only be changed with the pro-
gramming tool.
Operations: On powering the receiver, the led R1 will flash the same number of times as the group number with which it
is configured.
C = channel
G = group
Group 0 enables all groups.
