ARTILLIAN ROPS MOUNTED TOOL BAR
The Artillian ROPS Mounted Tool Bar is an innovative system for attaching
accessories to your 2-Post tractor ROPS. It attaches to most rectangular
ROPS profiles in minutes. At 42" wide, it adjusts to fit many different ROPS
widths, without overhanging the rear tires on sub-compact models. Simple,
yet elegant mounting brackets provide limitless adjustability,
accommodating nearly any ROPS angle in either direction.
The proprietary Cam Lever Latching feature found on the many optional
accessories allows for installation and removal of a given accessory in
seconds.
Approximate Installation Time
Experienced Dealer Technician – 15 Minutes
Average Dealer Technician – 25 Minutes
Do-It-Yourself – 45 Minutes
CAUTION
The contents of this envelope are the property of the owner. Leave with the owner when installation is complete.
P/N: 1RMTB
Approximate Product Specifications
Mounting Bar Width: 42 inches
Weight: 9.76 lbs. (not including accessories)
Capacity: 100 lbs. (including accessories)
Do not exceed the rated capacity for the Tool Bar or its accessories.
Doing so may result in damage to the Tool Bar and will void the warranty.
Rev. A, 04/30/2020
p/n: IM-1RMTB
1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1RMTB and is the answer not in the manual?

Questions and answers

Summary of Contents for Artillian 1RMTB

  • Page 1 ARTILLIAN ROPS MOUNTED TOOL BAR P/N: 1RMTB The Artillian ROPS Mounted Tool Bar is an innovative system for attaching accessories to your 2-Post tractor ROPS. It attaches to most rectangular ROPS profiles in minutes. At 42” wide, it adjusts to fit many different ROPS widths, without overhanging the rear tires on sub-compact models.
  • Page 2 2 of 7 MOUNTING CONFIGURATION OVERVIEW This kit is designed to accommodate many sizes and shapes of vehicle ROPS (Roll-Over Protective Structures). Per the illustrations on this page, the brackets may face inward or outward, and may be attached to the inside or outside face of your ROPS.

  • Page 3: Kit Installation

    3 of 7 KIT INSTALLATION 1. Park the vehicle on a flat, level surface. 2. Once a mounting configuration has been decided upon, make a temporary mark of some kind on the ROPS tubing for locating where to fasten the ROPS brackets.
  • Page 4 C-clamp to clamp the stabilizer bracket to the ROPS tube prior to tightening the fastener. 7. Attach the mounting bar to the ROPS brackets, oriented so the Artillian logo is away from the seat as shown in fig. 7. Use a tube clamp, two bolts, and ROPS stabilizer two locknuts per bracket.

  • Page 5: Features And Operation

    FEATURES AND OPERATION FEATURES The Artillian ROPS Mounted Tool Bar allows for one or more Artillian ROPS Mounted Accessories to be attached to the vehicle ROPS. Additional Tool Bars allow for additional accessories. The innovation of the design is that any of the compatible accessories can be installed or removed from the Tool Bar in seconds, without the use of tools.

  • Page 6: Service Parts

    6 of 7 SERVICE PARTS: MOUNTING BAR ASSEMBLY ROPS BRACKET ASSEMBLY TUBE CLAMP ASSEMBLY P/N: 8SV-113-00186 (QTY.: ONE) P/N: 8SV-110-00069 (QTY.: ONE) P/N: 8SV-110-00068 (QTY.: ONE) U-BOLT CLAMP PLATE ROPS STABILIZER BRACKET ASSEMBLY PLASTIC TREE CLIPS P/N: 8SV-SM-01592 (QTY.: ONE) P/N: 8SV-110-00073 (QTY.: ONE) P/N: 9SV-CP01 (QTY.: 12) 1/2”...

  • Page 7: Available Accessories

    7 of 7 AVAILABLE ACCESSORIES: ROPS MOUNTED TOOLBOX, LARGE ROPS MOUNTED TOOL RACK ROPS MOUNTED TOOLBOX, SMALL P/N: 1RMTBXS P/N: 1RMTBXL P/N: 1RMTRK ROPS MOUNTED CHAINSAW MOUNT ROPS MOUNTED FUEL CAN HOLDER ROPS MOUNTED TOOL BASKET P/N: 1RMCSM P/N: 1RMFCH P/N: 1RMTBSK (chainsaw shown for illustration purposes) MORE ACCESSORIES COMING SOON!
