infobit 30 Quick Start

1080P Ultra-Wide Field USB Camera Quick Start
1
Product Appearance
2
Packing List
Name
Camera
Quick Start
3
Product Features
1080P Full HD Wide Angle
Support 1080P full HD, and can provide 1080P@30fps/25fps image coding
output. At the same time, it is compatible with 720P equal resolution
downwards, with wide field of view angle, and the maximum horizontal field
angle can be achieved 84°(Support Auto Focus)/110°.
USB 2.0
Full-featured USB 2.0 interface, power supply, video and audio all in one.
Built-in Microphone
Built-in microphone array, unique noise suppression algorithm, make your
voice perfect presentation.
INFOBIT AV
EPTZ
There is no need for mechanical transmission, which realizes more
accurate rotation, no noise, more reliable and durable pan-tilt function.
Low-light
The application of 2D and 3D noise reduction algorithm greatly reduces the
image noise. Even under the condition of ultra-low illumination, it still keeps
the picture clean and clear, and the SNR of image is as high as 55dB.
Easy Installation
Standard damping bracket support, suitable for market 100% monitor, easy
installation, stable and reliable.
4
Camera
Sensor
Scanning Mode
Lens Mount
Lens 1
Lens 2
Minimal Illumination
Shutter
White Balance
Camera bracket
Digital Noise
Reduction
Backlight
Compensation
Digital Zoom
USB Features
Operate System
Color / Compression
Quantity
1
Video Format
1
USB Communication
Protocol
EPTZ
Input/Output Interface
USB Interface
Physical Parameter
Input Voltage
Current
Consumption
Operating
Temperature
www.infobitav.ocm
Product Specifications
1/2.8'', CMOS, Effective Pixel: 2.07M
Progressive
M12
Focus: f=3.5mm, FOV: 84°
(Support Auto Focus)
Focus: f=2.2mm, FOV: 110°
0.5 Lux @ (F2.0, AGC ON)
1/30s ~ 1/10000s
Auto, Indoor, Outdoor, One Push,
Manual, VAR
bracket with damper
2D, 3D digital noise reduction
Support
4x
Windows 7/8/10, Mac OS X, Linux, Android
MJPEG/YUY2/H.264
1080P@30fps/25fps, 720P@30fps/25fps,
960x540P@30fps/25fps,
640x360P@30fps/25fps
UVC 1.1
Support
1 x USB 2.0: Type A
5V (USB power supply)
0.27A
-10°C ~ 40°C
