INTELLIGENT ADDRESSABLE FIRE DETECTION SYSTEM
User Guide
(TO BE RETAINED BY USER)
26-0397 Issue 2
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SITA 200 PLUS V2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Rafiki Protection SITA 200 PLUS V2

  • Page 1 http://www.firealarmengineers.com sita 200plus INTELLIGENT ADDRESSABLE FIRE DETECTION SYSTEM User Guide (TO BE RETAINED BY USER) 26-0397 Issue 2...
  • Page 2 Sita 200 plus User Guide Rafiki Protection Limited Rafiki policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has been taken to ensure that the contents of this document are correct at time of publication, Rafiki shall be under no liability whatsoever in respect of such contents.

  • Page 3: Table Of Contents

    http://www.firealarmengineers.com Sita 200 plus User Guide Contents Introduction Purpose of the guide Definitions Understanding the equipment System configuration What to do if!!! . Installation Details General Operation Normal Access Levels and Soft Keys. Fire Alarm Power Supply Unit On hearing the alarm Accessing the controls Silencing the alarms Resetting the system...

  • Page 4: Introduction

    http://www.firealarmengineers.com Sita 200 plus User Guide Introduction Purpose of the Guide This guide is provided to enable the person responsible for the fire alarm system (see Definitions) to operate the system, undertake their responsibilities with regard to testing and maintenance of the system, and to record events and service/maintenance visits.

  • Page 5: System Configuration

    http://www.firealarmengineers.com Sita 200 plus User Guide System Configuration The detectors and call-points are arranged in zones to enable the location of a fire alarm to be identified. The number of zones depends on the size and the layout of the premises, and is limited to 32 zones per control panel (there may be more than one).

  • Page 6: Installation Details

    Date of Handover: ……….………………………………………………………………………………… Name and address of installer: …………...………...………………………………………………………… .…………………………………………………………….………………………………………………………. Tel: ………………………………….……………………………………………………………………..….. Fax: ………………………………….………………………………………………………………………… Equipment: Control Panel: Sita 200 plus V2 Serial No.…………………………………………………………… No. of zones used: ………………………………………………………………….……………………… No. of detectors: ………………………………………………………………….……………………… No. of call-points: ………………………………………………………………….……………………… No. of sounders: ………………………………………………………………….……………………… Interfaces: ………………………………………………………………….…………….

  • Page 7: General Operation

    http://www.firealarmengineers.com Sita 200 plus User Guide General Operation Normal In the normal operating mode only the green POWER LED is lit. If any other LEDs are lit and/or the buzzer is sounding there is an abnormal condition present. Access Levels and Soft Keys In normal operation the panel controls are inoperable, to prevent unauthorised operation.

  • Page 8: Accessing The Controls

    http://www.firealarmengineers.com Sita 200 plus User Guide Accessing the Controls The user controls are accessed from ACCESS LEVEL 2 which is reached as follows: Press the button below the section of display which shows [AL2 CODE] The display will now ask you to enter the AL2 code, so do so by pressing the relevant buttons, ie # # # (see installation details shown earlier for the code) The amber SHIFT LED will now be lit.

  • Page 9: Exit Access Level Two

    http://www.firealarmengineers.com Sita 200 plus User Guide Exit ACCESS LEVEL 2 In order to prevent unauthorised access to the system, return to ACCESS LEVEL 1. If left untouched the display will time out after a short while and return automatically to ACCESS LEVEL 1, but this can be achieved manually if required by pressing the [EXIT AL2] prompt.

  • Page 10: Advanced Operation

    http://www.firealarmengineers.com Sita 200 plus User Guide Advanced Operation Additional Functions Certain additional functions are available for advanced operation of the control panel. The functions summarised below should only be used in consultation with you fire alarm service organisation. Zone Disable / Enable This function allows the disablement or enablement of a zone.
  • Page 11 http://www.firealarmengineers.com Sita 200 plus User Guide Zone Test A The ‘Zone Test A’ function allows the selection of one or more zones to operate in a ‘silent one-man walk test mode’. On triggering a device the LED in that device operates and the event is recorded into the event log as a test activation, but the sounder does not sound and the control panel does not show an alarm.

  • Page 12: Important Note

    http://www.firealarmengineers.com Sita 200 plus User Guide Fault Status The ‘>faults’ function causes the control panel to display any items which are in fault. One point shows at a time and the continued pressing of the ‘>faults’ prompt allows the messages to be scrolled through, one at a time.

  • Page 13: User Responsibilities

    http://www.firealarmengineers.com Sita 200 plus User Guide User Responsibilities Introduction The responsible person is required under BS5839 to undertake certain tasks with respect to the testing and maintenance of the fire alarm system. The responsible person should also ensure that written procedures are in place for the actions to be taken by the occupants in a fire condition, and that staff required to operate the system have received adequate training.
  • Page 14 http://www.firealarmengineers.com Sita 200 plus User Guide Any defects should be recorded in the log book and reported to the responsible person. A certificate of testing should also be completed and given to the responsible person. Annual The requirements of the annual test are similar to the quarterly test except that each device on the system should be tested.

  • Page 15: Log Book

    http://www.firealarmengineers.com Sita 200 plus User Guide Log Book Record all fire and fault events, whether or not an engineer was called Event Log Date Time Zone/Device Event Action Initials...
  • Page 16 http://www.firealarmengineers.com Sita 200 plus User Guide Date Time Zone/Device Event Action Initials...

  • Page 17: Weekly Testing

    http://www.firealarmengineers.com Sita 200 plus User Guide Test the alarm each week using a different call point in rotation. All call points should be numbered for identification Weekly Testing Date Point No Comment Initials...
  • Page 18 http://www.firealarmengineers.com Sita 200 plus User Guide Date Point No Comment Initials...

  • Page 19: Routine Maintenance

    http://www.firealarmengineers.com Sita 200 plus User Guide Record all routine maintenance visits and note parts used/ replaced Routine Maintenance Date Comment Initials Date Comment Initials...
  • Page 20 http://www.firealarmengineers.com Sita 200 plus User Guide Date Comment Initials...
  • Page 21 http://www.firealarmengineers.com Sita 200 plus User Guide...

  • Page 22: Modifications

    http://www.firealarmengineers.com Sita 200 plus User Guide Modifications Date Description of Modification Contractor Complete...

  • Page 23: Notes

    http://www.firealarmengineers.com Sita 200 plus User Guide Notes...
  • Page 24 http://www.firealarmengineers.com Sita 200 plus User Guide...
