RBH Access Technologies FR-360N Quick Start Manual

PROXIMITY READER
Works with
• Clam Shell Cards
*
Up to 6 inches (152 mm) @ 125 KHz AWID
• Printable Cards
*
Up to 4 inches (102 mm) @ 125 KHz AWID
• Key Fobs
*
Up to 3 inches (76 mm) @ 125 KHz AWID
• Adhesive Tags
*
Up to 3 inches (76 mm) @ 125 KHz AWID
*Read range is stated in a clean RF and
electrical environment using clamshell
card presented parallel to reader
surface with reader operating at 12 VDC.
Additionally, read range may be aff ected
by local installation conditions. Range
will be less when mounted to metal.
PLEASE VISIT WWW.RBH-ACCESS.COM FOR MORE PRODUCTS
Utilizing proven digital radio frequency identifi cation (RFID)
technology, RBH FR-360N Proximity Readers deliver best in
class read ranges and reliable operation.
Mounting is simplifi ed with vertical and horizontal mounting
slots, instead of holes, which allow the reader to be
conveniently adjusted and leveled. To allow both indoor
and outdoor operation the electronics are sealed in tamper
resistant epoxy potting.
Notable features for these are: low power consumption,
easy-to-install readers that include Wiegand interface,
independently controllable multi-color LED and audio
sounder.
These readers are also available with additional formats* as
well as Mifare CSN and Mifare Sector.
AWID + Keri (Wiegand) - 125 kHz
RBH-FR-360N
RBH-FR-360N-H AWID and more* - 125 kHz
MIFARE and more*- 13.56 MHz
RBH-FR-360N-CSN
RBH-FR-360N-MS MIFARE and more*- 13.56 MHz
* Call for a complete list of compatible formats
• Compatible with all standard
access control systems
• Best-in-class read range
• FR-360N direct on-metal mounting
• Fits single-gang US wall-box
with optional mounting plate
• Internal Piezo Sounder
• Tri-color LED standard
• Multiple Wiegand formats
• Optional Other 125 kHz formats*
• Optional MIFARE compatibility
• Many additional features...
* Call for a complete list of compatible formats
FR-360N
FAMILY
Features :
Externally controlled
built-in piezo sounder
Resin filled for all
weather installations
