P
REMIER
INSTRUCTION MANUAL
CATALOGUE NUMBERS :
DT MFK6 and DT GFLK3
Thank you for your purchase of Premier Lights.
The Premier garden lighting range offers the ideal
lighting effect to any garden and feature
weatherproof transformers that can be positioned
outside safely. The transformer is equipped with
a photo-cell which switches the lights on at dusk
and off at dawn. Keep a copy of these
instructions for future reference.
Please read these instructions fully
before commencing the installation:
SAFETY INSTRUCTIONS
• These lights are only to be connected to a 12V
low voltage lighting system.
• Only use either lights provided with this kit or
compatible lights from the Homelec range.
• Only use the transformer supplied or a
transformer from the Homelec Premier garden
lighting range.
• Disconnect the power before changing a lamp
and ensure the lamp is cool before handling.
• Ensure the cable is routed so as not to be a trip
hazard.
• Ensure that the wattage of all the lights
combined does not exceed the rating of the
transformer.
RANGE
• The transformer must be plugged in indoors.
• Only adjust the cable and lights when the power
is switched off.
Kit Contents :
MFK6
6 Flood Lights
6 Threaded Caps
6 Inserts
6 Ground Spikes
2 Fixing Screw Packs
7 10W 12V Halogen Lamps
1 96W Transformer
15m approx. Cable
GFLK3
2 Flood Lights
1 Shrub Light
3 Threaded Caps
3 Inserts
2 Ground Spikes
1 Fixing Screw Pack
3 10W 12V Halogen
Lamps
2 20W 12V Halogen
Lamp
1 96W Transformer
15m approx. Cable
1
90-OM1865
Advertisement
Table of Contents
Summary of Contents for Premier Range DT MFK6
- Page 1 REMIER RANGE INSTRUCTION MANUAL CATALOGUE NUMBERS : DT MFK6 and DT GFLK3 Thank you for your purchase of Premier Lights. • The transformer must be plugged in indoors. The Premier garden lighting range offers the ideal • Only adjust the cable and lights when the power lighting effect to any garden and feature is switched off.
- Page 2 Installation : 2. At the point where you want to locate the 1. Locate the transformer in a suitable position, Shrub light, attach the Shrub light power considering that the transformer has to be connector by the following method. Place the plugged in indoors.
- Page 3 the screws provided. The screw locations are Do not loop the low voltage cable back to the to be positioned so they will slide onto the transformer. slots on the rear of the transformer. The transformer may now be plugged into an There are not any user serviceable parts within appropriate socket.
- Page 4 Specification : Light & Transformer Warranty MFK6 GFLK3 It is unlikely that this transformer and light Transformer fittings will fail in normal use due to faulty Input : 230V~ 50Hz 230V~ 50Hz materials or workmanship within 5 years for the Output : 12V~ 96W, 8A 12V~ 96W, 8A...
