- Page 1 ® USER’S MANUAL 4038 Weaver Court East Hilliard, OH 43026 Ph: (614) 921-8866 Fx: (614) 921-8877 Toll Free: (866) 532-3534 P/N 1.07080 Revision G 1 of 8...
- Page 2 USER’S MANUAL important safeguards When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: read all instructions and Warnings prior to operation. danger: to reduce the risk of electrocution: always unplug this product immediately after using. do not use while bathing.
- Page 3 UL/C-UL Classification with respect to electric shock, fire, and mechanical hazards only in accordance with UL 60601-1/CAN/CSA C22.2 No. 601.1. Meets UL 1431 Standards for Personal Hygiene and Healthcare Appliances. Product Description: The purpose of the FLEX-MATE K500 is to provide continuous passive motion to the knee or hip joint to increase ®...
- Page 4 Set Up Instructions 1. Open the shipping container and set aside the soft goods bag. Lift the FLEX-MATE K500 from the box ® and place it where it is to be used. 2. Plug the wall transformer into a 110/120V AC wall outlet close to the machine.
- Page 5 5. Loosen the adjustment knobs on the tibia bars and pull the foot plate out to a length greater than the patient’s lower leg. 6. Use the hand-held controller to bring the machine to the desired start position. 7. Place the patient’s leg in the machine, making sure the patient’s knee is aligned with the joint on the machine.
- Page 6 Foot Plate Adjustment for Plantar/Dorsiflexion and External/Internal rotation 2. External/Internal Rotation 1. Plantar/Dorsiflexion Loosen the adjustment knobs on the foot plate. Adjust Loosen the adjustment knobs on each side of the foot plate. the foot plate to the prescribed degree of external/internal Adjust the foot plate to the desired degree of plantar or rotation.
- Page 7 Hand-held Controller Operation Turn on the power switch located at the foot of the machine. Range of Motion Set Hold down “EXT” or “FLEX” and press “UP” or “DOWN” arrow to set the limits. Full range is from –10° extension to 120° flexion. Speed Set Hold down “SPEED”...
- Page 8 4038 Weaver Court East Hilliard, OH 43026 Ph: (614) 921-8866 Fx: (614) 921-8877 Toll Free: (866) 532-3534...
Need help?
Do you have a question about the Flex-Mate K500 and is the answer not in the manual?
Questions and answers
The hand control has went to error. How to reset the the control
To reset the hand control (pendant) for the KLC K500:
1. Turn the power off.
2. Wait 5 seconds.
3. Turn the power back on.
If the display shows “Err,” this reset procedure may resolve the issue. If pendant adjustments are still inoperative, check all connections at the P.C. Board.
This answer is automatically generated
