- Page 1 Operating instructions KNX Smart Panel 8 ALBRECHT JUNG GMBH & CO. KG Ref.-no.: SP 0081 U Volmestraße 1 58579 Schalksmühle GERMANY Tel. +49 2355 806-0 Fax +49 2355 806-204 kundencenter@jung.de www.jung.de 04/2021 0024022000...
-
Page 3: Table Of Contents
Table of contents Table of contents Safety instructions and device components ....... 2 Safety instructions ..............Device components ..............Function .................. 3 System information ..............Intended use ................Product characteristics ............. Installation and electrical connection ........4 Information for electrically skilled persons ......Mounting in installation box or appliance box ...... -
Page 4: Safety Instructions And Device Components
Safety instructions and device components KNX Smart Panel 8 Safety instructions and device components Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. read and follow manual fully. Danger of electric shock. During installation and cable routing, comply with the regulations and standards which apply for SELV circuits. -
Page 5: Function
Function Function System information This device is a product of the KNX system and conforms to the KNX Directives. Detailed knowledge attained through KNX training is a prerequisite for understanding. The device is planned, installed and commissioned by means of an external of external project planning software. The latest software version and the technical descriptions can be found on our website at all times. -
Page 6: Installation And Electrical Connection
Installation and electrical connection Installation and electrical connection Information for electrically skilled persons DANGER Electrical shock on contact with live parts in the installation environment. Electrical shocks can be fatal. Before working on the device, disconnect the power and cover live parts in the area! Mounting in installation box or appliance box adapter is screwed onto the installation box. -
Page 7: Mounting The Adapter
Installation and electrical connection Mounting the adapter Fig. 2: Montage Adapter 1 Adapter locking screw 2 Fixing hooks • Mount the adapter on the installation box with a total of four When mounting on an appliance box, the adapter must be mounted on the wall. -
Page 8: Connection
Installation and electrical connection Connection Fig. 3: Connection 3 Power supply 5 LAN/Ethernet 6 KNX bus Requirements: - Power supply via power supply adapter, ref. no.: NT 2415 REG VDC mobile end devices: Ethernet connection • • Connect LAN (5) optionally. i Do not connect any other products and loads outside the KNX standard to the bus output. -
Page 9: Mounting The Smart Panel
Installation and electrical connection Mounting the Smart Panel Fig. 4: Montage Smart Panel 7 Openings for wall mounting 8 Smart Panel locking screws • Place the openings for wall mounting (7) on the Smart Panel To do this, place the openings for wall mounting above the hooks and engage them downwards. -
Page 10: Commissioning
Commissioning Commissioning Switching on After connecting, the device is switched on automatically and the operating system is started. After the start-up process, you must make the settings for commissioning. Settings – Overview of the menu structure - General - Language - Date/time - Design - Display... -
Page 11: Selecting Date And Time
Commissioning Selecting date and time • Open the settings. • Select the menu “General”. • Select the submenu “Date/time”. • Make the settings: - autom. date/time: activated - autom. time zone: deactivated - select the time zone (e.g. GMT+2) - 24-hour format: activated Changing the system password i The system password grants access to all settings. -
Page 12: Cleaning
The device is operated via pre-installed apps. The apps must be started via the main menu. The device is planned and designed exclusively with the aid of external project planning software. product documentation is available for downloading on our website. Cleaning i The cleaning mode is started with the “Screencleaner”... -
Page 13: Technical Data
Technical data Technical data Screen diagonal 203 mm / 8“ Resolution 1280 x 800 (WXGA) Aspect ratio 16:9 Overall dimensions Smart Panel 225 x 145 mm (W x H) Adapter 216 x 141 mm Structure height 16 mm Installation depth 22 mm Power consumption max. -
Page 14: Accessories
Accessories Accessories Power supply adapter NT 2415 REG VDC Installation box Warranty The warranty follows about the specialty store in between the legal framework as provided for by law. SP 0081 U... - Page 16 ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Tel. +49 2355 806-0 Fax +49 2355 806-204 kundencenter@jung.de JUNG.DE...
