| 2021 Quick Setup Guide
FORK TUNING
First, set your fork sag with your riding gear on, using the tradtional seated method.
You will likely need to raise or lower pressures to get the recommended setting.
AIR PRESSURES
Using the traditional
seated method and
EXIE
pressures on the charts
STARTING SAG
below as a starting
/ 24
point, adjust air
20
%
pressures up
mm
or down until you get
to the recommended
SAG METHOD
SEATED
starting sag.
FOX FACTORY FLOAT 34 STEP-CAST: 29
AIR PRESSURES
RIDER WEIGHT
LB
120-130
130-140
140-150
150-160
160-170
170-180
180-190
NOTE: All Fox 2022 Model Year forks
(MY22) have a sticker calling out the
190-200
QR code registration, the QR code
replaces the old 4-digit identification
200-210
codes. It contains a product serial
210-220
number and also directs you to a URL
with product information.
220-230
https://tinyurl.com/yf4vxnvb
230-240
240-250
MAX
DO NOT EXCEED MAXIMUM AIR PRESSURES
Air pressures above are for both Factory and Performance forks from Fox.
34 FLOAT and FLOAT STEP-CAST, maximum air pressure is 120 psi.
COMPRESSION ADJUST
FOX FACTORY - FIT4:
There's a 3-POSITION ON-THE-FLY
(REMOTE LEVER) adjustment on the Exie.
It is useful to make on-the-fly adjustments
to control fork performance under significant
changes in terrain, and is intended to be
SAG 20% (24
)
mm
adjusted throughout the ride.
OPEN
MEDIUM
FIRM
120MM
KG
PSI
54-59
58
59-64
63
64-68
68
68-73
72
73-77
77
77-82
82
82-86
86
OPEN MODE ADJUST is useful to control fork performance under rider weight shifts,
G-outs, and slow inputs.
86-91
91
OPEN
mode adjust provides 18 additional fine tuning adjustments for the OPEN mode.
91-95
96
Setting 18 will have a more plush feel and setting 1 will have a firmer feel.
95-100
100
100-104
105
104-109
110
109-113
114
120
mode for use during rough descending.
mode for undulating terrain.
mode for smooth climbing.
OPEN
MEDIUM
FIRM
REBOUND ADJUST
FOX FACTORY - FIT4:
Adjust the rebound settings according
to the chart below.
FIT4 REBOUND ADJUSTER
REBOUND controls the rate of speed at
which the fork extends after compressing.
Turn your rebound knob to the closed
position (full clockwise) until it stops.
Then back it out (counter-clockwise)
to the number of clicks shown in the
table below.
FOX FACTORY FLOAT 34 STEP-CAST: 29
FIT4: REBOUND ADJUSTER
RIDER WEIGHT
FIT4 RECOMMENDED
LB
KG
REBOUND SETTINGS
120-130
54-59
12
130-140
59-64
11
140-150
64-68
10
150-160
68-73
9
160-170
73-77
8
170-180
77-82
7
180-190
82-86
6
190-200
86-91
6
200-210
91-95
5
210-220
95-100
4
220-230
100-104
3
230-240
104-109
2
240-250
109-113
1
MAX
RANGE 0-12
