Four-Faith F-NVR100 User Manual

Iot network video recorder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
The Document Version
Pages
F - NVR100
User Manual
V1.0.1
65
F - NVR100 User Manual
Add: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China.
Tel: +86 592-5907276
Fax: +86 592-5912735
Web: en.four-faith.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-NVR100 and is the answer not in the manual?

Questions and answers

Related Manuals for Four-Faith F-NVR100

Summary of Contents for Four-Faith F-NVR100

  • Page 1 The Document Version Pages F - NVR100 User Manual V1.0.1 F - NVR100 User Manual Add: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Tel: +86 592-5907276 Fax: +86 592-5912735 Web: en.four-faith.com...
  • Page 2 Files Revised Record Date Version Remark Author 2019-02-21 V1.0.0 The initial release 2021-01-18 V1.0.1 Update the latest UI introduction and JONAS device information Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: en.four-faith.com Tel: +86-592-5907276 Fax: +86-592-591273...
  • Page 3 Trademark Statement Four-faith, four-letter, and, are registered trademarks of xiamen sixin communication technology co., LTD. Without prior written permission, no one shall use the name of sixin and the trademarks and marks of sixin in any way.
  • Page 4 NVR100 User Manual Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: en.four-faith.com Tel: +86-592-5907276 Fax: +86-592-591273...

  • Page 5: Table Of Contents

    4.2.4 Channel Setting Interface ............57 4.2.5 System Setting Interface ............58 4.2.6 System Information Interface ............ 63 4.2.7 Device Reboot ................65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: en.four-faith.com Tel: +86-592-5907276 Fax: +86-592-591273...

  • Page 6: Chapter 1 Product Introduction

    Chapter 1 Product Introduction ⚫ 1.1 Product Overview F – NVR100 is Four-Faith company independent research and development of a new generation of NVR terminals, the integration of advanced 4G/WIFI communications technology, with 8 road POE power supply of 1080 p video input and 1 road, real-time...

  • Page 7: Product Features

    NVR100 User Manual Topology: 1.2 Product Features Outdoor Application Design ⚫ High performance processor ARM Cortex A7 Dual-core 1.3GHz ⚫ Wide power input (DC 9~60V) ⚫ Wide temperature design (-10℃~75℃) ⚫ Metal shell, good heat dissipation, impact resistance ⚫ Waterproof, dustproof, moisture-proof suitable for outdoor use (add waterproof water tank) ⚫...
  • Page 8 NVR100 User Manual ⚫ Up to 8 channels full real-time coding, standard H. 264, H. 265 decoding format, lower code stream, better picture quality. ⚫ 4 way and 8 way display switch, according to different needs to choose. ⚫ Support 4 or 8 channels of video and audio synchronous recording and playback. ⚫...

  • Page 9: Product Specifications

    NVR100 User Manual ⚫ Support alarm video recording protection mechanism, can protect important video. ⚫ Stable storage, sudden power failure is not easy to be destroyed. ⚫ Power protection function, after power off the machine to ensure the integrity of data preservation. ⚫...
  • Page 10 NVR100 User Manual Protocol Video Decoding 4 x 1080p @ 30 fps H. 265 / H. 264 decoding Performanc 8 x 720p @ 30 fps H. 265 / H. 264 decoding Video 12 MP / 8 MP / 6 MP / 5 MP / 3MP / 4MP / 1080P/ UXGA / 720P / VGA / 4CIF/ Storage 2CIF/CIF /QCIF Resolution...
  • Page 11 NVR100 User Manual Wireless Parameters Item Content The Wireless Industrial wireless module (optional menu module or no module) Module Support TDD LTE/FDD - LTE/EVDO/WCDMA/TD-SCDMA/CDMA1X/GPRS/EDGE Standard Single mode, multi - mode or full - network communication is optional FDD LTE(downlink rate 150Mbps, uplink rate 50Mbps) TDD LTE(downlink rate 130Mbps, uplink rate 35Mbps) The Theory of CDMA2000 1X EVDO Rev A (downlink rate 3.1Mbps, uplink rate 1.8Mbps)
  • Page 12 NVR100 User Manual Transmission Power 20dBm (11n), 21.5dBm (11g), 26dBm (11b) Reception < - 72 dBm @ 54Mbps Sensitivity Application Support client mode, AP mode Other External Interfaces and Indicators Number Item Content 1 RJ45 10M/100M/1000M adaptive Ethernet port 8 RJ45 10M/100M adaptive Ethernet port, support POE power AF&AT (optional) Serial 3, standard RS485/RS232 serial interface time division multiplexing, support...
  • Page 13 NVR100 User Manual Physical Properties Item Content Casting Metal, IP30 Dimensions 182 x 152 x 45mm (Excluding antenna and mounting) Weight 1.5kg (Excluding antenna and mounting parts) The other Parameters Item Content - 10 ~ + 75° C ( + 14 ~ + 167 ℉) Working Temperature - 40 ~ + 85°...
  • Page 14 NVR100 User Manual The Front Panel Stitch Definition Number Identification Picture Definition Instructions Grounding Pin 1: GND Access to the chassis. Screw Parameters restore factory default. Press this button for more Reset Pin 1: RESET than 10 seconds to restore factory default parameters of NVR device.
  • Page 15 NVR100 User Manual CPU_RS485_A - MCU_RS232 and Pin 7: GND RS485 hydraulic and Pin 8: GND environmental version Pin 9: GND sensor collection. Pin 10: GND Pin 17/18/19/20: Pin 11: MCU_RS232 and MCU_RS232_RX RS485 hydraulic and Pin 12: environmental version MCU_RS232_TX sensor collection.
  • Page 16 NVR100 User Manual Pin 1: 12 V0_OUT Pin 2: GND Pin 3: 5 V0_OUT Pin 1: +12V power Pin 4: GND output, maximum Pin 5: AD1 output current 0.5A. Pin 6: GND Pin 3: +5V power Pin 7: AD2 output, maximum Pin 8: GND output current 0.5A Pin 9: AD3...
  • Page 17 NVR100 User Manual Pin 17: RELAY1B 100mA. Pin 18: RELAY1A Pin 17/18: The first Pin 19: RELAY2B relay output Pin 20: RELAYAB Pin 19/20: The second relay. Maximum switching voltage: 30VDC/250VAC Maximum switching current: 5A Maximum switching power: 150W/1250VA DC input voltage range: 9V~60V, note the POE version must Pin 1: GND...
  • Page 18 NVR100 User Manual Number Identification Picture Definition Instructions Lan1-8 webcam 10M/100M adaptive LAN1-8 input interface, Ethernet port, Interface gateway address support POE power 192.168.63.1 AF&AT (Optical) Video output, HDMI HDMI standard HDMI interface RJ45 10M/100M/1000M adaptive Ethernet WLAN + 2 WLAN port.
  • Page 19 NVR100 User Manual SATA heating chip power interface Hard Disk SATA hard disk power interface SATA data interface 4G Module 4G Module 14 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...

  • Page 20: Chapter 2 Installation Of Device

    NVR100 User Manual Chapter 2 Installation of Device 2.1 Power Supply Installation Remove the power adapter and power terminal from the package, install the positive and negative terminals of the power adapter on the power terminal in the correct access mode: 2.2 Hard Disk Installation 1.
  • Page 21 NVR100 User Manual ⚫ Put an insulating sticker between the hard disk and the sheet metal of the support plate (to prevent the conductivity of the hard disk and the sheet metal of the support plate). ⚫ Use M3*5 round head screw to lock the hard disk on the support plate. ⚫...
  • Page 22 NVR100 User Manual ⚫ Connect SATA data line, SATA power line and heater line to the corresponding seat. 17 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...

  • Page 23: Chapter 3 Nvr Web Page Configuration

    NVR100 User Manual Chapter 3 NVR Web Page Configuration 3.1 Configuration Connection Diagram Before configuring the NVR, you need to connect the NVR to the PC for configuration through the factory configured network cable or WIFI. When connecting with WIFI, you must turn on the WIFI function and configure the corresponding routing SSID and password.

  • Page 24: Install Web Plugin

    NVR100 User Manual 3.2.2 Install Web Plugin Run the ff-video-plugin.exe, by using IE 3.2.3 Login to the NVR Web Page This chapter describes the main functions of each page. Web tools can be accessed through a web browser using a computer connected to the NVR. There are five level pages: video, video settings, system configuration, system management, system information.

  • Page 25: Management And Configuration

    NVR100 User Manual After login to the NVR Web management tool, user can go to the web main page. 3.3 Management and Configuration 3.3.1 Video Viewing 20 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...

  • Page 26: Video Setting

    NVR100 User Manual ① Video Preview: User can view the real-time monitoring video on the video preview interface. According to the configured video channels to use 4/8 split screen display. 3.3.2 Video Playback Click the " Playback" button and the following interface will appear. ①...

  • Page 27: System Configuration

    NVR100 User Manual ② Video Playback: After the searching, the video recording will display on the playback interface. Select the time period and click the play button to play recording video. 3.3.3 System Configuration Click the " Config " button and the following interface will appear. 22 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China.
  • Page 28 NVR100 User Manual ① Picture Review: Users can search capture pictures in the storage server by selecting a device. Before searching the picture, the user must first fill in the selection searching condition, and the server returns results according to the searching condition. ②...
  • Page 29 NVR100 User Manual ⚫ File Packaging Duration: In order to facilitate file retrieval and playback, the video file packaging time is too long which is unfavorable to the time spent on file retrieval and playback. If the video file packaging time is too short, the file is too trivial. So that it is not conducive to management. File packaging time ranges from 5 to 30 minutes.
  • Page 30 NVR100 User Manual ③ System Settings: Users can setting the those parameters on the NVR web page such as general setting, IPC channel setting, code setting and so on. ⚫ General Setting General setting allows user to setting the device general configuration such as device ID, device position, data transmission type and other parameters.
  • Page 31 NVR100 User Manual Device ID: Set the device ID number and modify it according to the actual needs. Device Position: Device position is the location information installed by the device, which can be configured with 0-20 characters (10 Chinese characters). The device name can be configured with 0-20 characters (10 Chinese characters).
  • Page 32 NVR100 User Manual Language: Set the web display language, currently only support simplified Chinese and English. ⚫ IPC Channel: User can configure the IPC channel settings such as IPC address, IPC username, IPC password and so on. Camera Type: Code close is to close the IPC configuration of the current channel with no output. Code manual allows user to setting the IPC address, IPC username and IPC password.
  • Page 33 NVR100 User Manual ⚫ Code Setting: Code Stream Type: User can set the stream type to main stream, subcode stream and third stream. Code Rate Type: User can set the code rate type to change rate and fixed rate. Image Quality: User can select the image quality according to the user’s requirement.
  • Page 34 NVR100 User Manual Configuration Recommendations: If the storage requirements are high, set the resolution to a higher resolution and frame rate. If the requirements for network transmission are high, you can choose no sub-code rate. Video recording and network transmission use the data encoded all the way. If the network bandwidth is limited, but there is a high demand for storage, the sub-code rate can be turned on.
  • Page 35 NVR100 User Manual Network Priority: If configured as "wired", "WIFI" and "3G/4G" in turn, NVR device has priority over network wired communication mode to communicate with the server under the condition that the cable enable is turned on. When the wired communication is abnormal, it will switch to WIFI mode.
  • Page 36 NVR100 User Manual LAN Configuration: User can edit the parameters of LAN such as LAN IP, start IP, end IP and so on. WIFI Configuration: User can edit the parameters of WIFI such as WIFI mode, IP mode, end IP and so on. SSID and password of wireless router must be configured.
  • Page 37 NVR100 User Manual 4G/3G Configuration: User can edit the 4G/3G configuration and must configure the dialing number, username, password, APN, PIN code, online persistence detection, online persistence detection IP. Call Center Number: General unicom 3G select "*99# (UMTS/3G/3.5G)" Telecom 3G option "#777(CDMA/EVDO)" Mobile 3G select "*98*1# (TD-SCDMA)"...
  • Page 38 3G/4G is online or not, and automatically redial if it is abnormal. ⚫ Server： Platform Access Mode: Four-Faith, GB28181. ➢ Platform access mode select the option of Four-Faith: 33 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276...
  • Page 39 NVR100 User Manual Signaling Server Address: Device video platform address, only need to configure the login server address, other server addresses are given by the login server communication. The address can be represented by a domain name. For users without fixed IP, the device can be connected to the platform through the domain name if they need to apply for a domain name.
  • Page 40 NVR100 User Manual Device ID: Uniformly managed and distributed by the server platform. Registered Password: Uniformly managed and distributed by the server platform. Local Port: NVR technology SIP signaling port, default is 5060. Registered Expires: Validity of SIP registration initiated by NVR and re-registered upon expiration.
  • Page 41 Automatic obtain: The default option is automatic obtain, so the captured pictures will be sent to Four-Faith's network platform. Custom: If it is necessary to send the capture pictures to the designated address, user can set the address here.
  • Page 42 NVR100 User Manual ⚫ Alarm Setting: Alarm Linkage Config: The status option can enable or disable the corresponding alarm event. Alarm mode include high to low alarm and low to high alarm. Alarm Record Config: Configure the video channel associated with the alarm event. The diagram below: Alarm Parameters Config: Including OSD display configuration, alarm mode, alarm effective time, alarm output time.
  • Page 43 NVR100 User Manual ➢ Alarm Mode: It is configured as pull-up alarm if and only if IO input changes from low to high jump, and vice versa. ➢ Alarm Output Time: It is the time period of alarm linkage IO output. If the time exceeds this configuration, IO output will be turned off again.
  • Page 44 NVR100 User Manual ⚫ Upload Record: ⚫ Serial Port Setting: User can set the serial port parameters according to requirements, including baud rate, data bit, stop bit and other parameters. Function: User can select application, PTZ (cradle head) and GPS as serial port function. 39 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China.
  • Page 45 NVR100 User Manual Protocol Type: The protocol type options including UDP(DTU), simple UDP, TCP (DTU), simple TCP, TCP server, TCST, Modbus TCP and close. ➢ UDP (DTU) and TCP (DTU) and Modbus TCP and TCST: Protocols corresponding to data transfer. ➢...
  • Page 46 NVR100 User Manual ④ Administration: ⚫ Hard Disk Management: The device allocates the storage space in advance for each file of the same size to store the video and prevent the file system from being damaged due to the abnormal power failure of the device.
  • Page 47 NVR100 User Manual In addition, user also can check the role information. ⚫ Auto Maintenance: User can configure the timing automatic reboot. You can reboot the device according to the reboot time setting. ⚫ Import and Export: ➢ Export: Exports the current device configuration as a file. ➢...
  • Page 48 NVR100 User Manual ⚫ Restore Default: The configuration parameters corresponding to the selected option are restored to the factory configuration. User can choose to restore them all or select specific items for specific functional parameters. ⚫ Firmware Upgrade: Click "Browse" to pop up the file interface to be upgraded, select the file package to be upgraded from the local location, click "open"...
  • Page 49 NVR100 User Manual Please wait patiently for the upgrade to finish, after finish the web will be prompted with “Update Successful” or “Update Failure”. ⚫ Boot Mode: Boot mode configuration including ADC lower power off time setting and boot mode setting.
  • Page 50 NVR100 User Manual ➢ Timer Mode In the timer mode, the remote control can be switched on and off. It can be switched on during the timing period and off during the timing period. The ACC switch is invalid. At most four switch time periods can be set on a regular day.
  • Page 51 NVR100 User Manual ⚫ Reboot: Reboot the NVR device ⚫ Command Debugging: User can enter the command such as ps, route, ifconfig to check the system log. 46 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
  • Page 52 NVR100 User Manual ⑤ System Information ⚫ System Status: The system status shows the 3G/4G network status, WIFI status, storage status, GPS status, record status and system running time of the NVR device. 47 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
  • Page 53 NVR100 User Manual ➢ 3G/4G Network Status: 3G/4G dialing, wireless module name, SIM card status, wireless signal. ➢ WIFI Status: WIFI connection status and signal strength. ➢ GPS Status: Display the GPS information such as antenna, location, longitude and other parameters. ➢...
  • Page 54 NVR100 User Manual ⚫ Log Information: Display and download the latest log information of the device, which can be used to judge the abnormal state of the device: ➢ Refresh: Refresh the latest log information. ➢ Backup: User can download the latest log information to your computer for enquiry. 49 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China.

  • Page 55: Chapter 4 Nvr Embedded Ui System Configuration

    NVR100 User Manual Chapter 4 NVR System Configuration User can connect a screen directly to the NVR’s HDMI port and use the embedded UI to operate the NVR. We recommend user to use this UI to get better experience. The embedded UI configuration is similar as the web page configuration.

  • Page 56: Quick Menu

    NVR100 User Manual 4.1.2 Quick Menu On the Live View page, right click the mouse on any place to show the quick menu. Main Menu: Switch to the main menu display. Mode: Switch to different display mode. Previous Screen: Move all the screen back 1 slot. Next Screen: Move all the screen forward 1 slot.

  • Page 57: Main Menu

    NVR100 User Manual 4.2 Main Menu Main Menu is shown as below： ‘ Including Playback, Hard Disk, Recording Plan, Channel Setting, System Setting, System Info and Reboot. 52 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...

  • Page 58: User Login

    NVR100 User Manual 4.2.1 User Login If the user has not logged in, he can only operate some functions of the "video preview interface", and access to operations without permission. The username and password are both “admin” by default, users can modify them. How to use the soft keyboard: When the cursor selects the input box, click again to pop up the system software keyboard, and click the characters on the keyboard to enter.

  • Page 59: Video Playback Interface

    NVR100 User Manual 4.2.2 Video Playback Interface The video playback query interface displays the video information by selecting the specified channel and the month and date to be queried. On the monthly calendar, the date of recording will be set to the specified color, blue is for ordinary recording, and red is for alarm recording on the current day.
  • Page 60 NVR100 User Manual The time axis is shifted upwards, such as the current selection of 24h, click this button to display the contents of the previous day. The time axis is shifted upwards, such as the current selection of 24h, click this button to display the content of the next day.

  • Page 61: Record Schedule Interface

    NVR100 User Manual 4.2.3 Record Schedule Interface The recording schedule is configured by using a table. The abscissa is 0-24 blocks, each block represents one hour, and the ordinate represents Monday to Sunday. Select the specified block and fill the time in the grid (after selecting the time grid, click the corresponding color rectangle with the mouse) to specify the recording type.

  • Page 62: Channel Setting Interface

    NVR100 User Manual 4.2.4 Channel Setting Interface The content of the channel configuration page can be previewed but not edited. To edit the channel information, click the icon of the corresponding channel and the system will pop-up the channel editing interface. ⚫...

  • Page 63: System Setting Interface

    NVR100 User Manual ⚫ Code Settings: On the code settings interface, user can edit the parameter such as stream type, rate type, video frame rate, maximum frame rate and so on 4.2.5 System Setting Interface ⚫ General Settings: 58 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China.
  • Page 64 NVR100 User Manual Display Mode: Set the default video preview display mode of the UI after the device restart. Loop Screen: Set whether the default loop video preview after the device restart. Loop Screen Time: Set how often the default loop video preview after the device restart. ⚫...
  • Page 65 NVR100 User Manual ⚫ Account Settings: In the account setting interface can display the current account’s information such as username, password, user code and so on. In addition, user can edit the current account information at this page. Besides, User can also add new account and enter the new account’s information.
  • Page 66 NVR100 User Manual ⚫ Record Upload: User can edit the record upload configuration at this interface such as type of record to upload, record period and other parameters. ⚫ Date & Time: System Date: Set the system date. System Time: Set the system time. Time Zone: Set the time zone of the system.
  • Page 67 NVR100 User Manual ⚫ Import and Export: To use this function, you need to connect with USB drive. Import: Import the device configuration file of USB drive to the device and select the file to be imported through "Preview". Export: Guide the device configuration file to the USB drive, and select the path to be exported through "Preview".

  • Page 68: System Information Interface

    NVR100 User Manual User can set to the default value of each setting in order to achieve the configuration parameters of the device can be restored to the factory default parameters. 4.2.6 System Information Interface ⚫ System Information: The system information interface is use for checking the system status such as WIFI status, 3G/4G network status, GPS status, storage device status and system operation time.
  • Page 69 NVR100 User Manual ⚫ Channel Status: On the channel status interface, user can check the status of each channels. ⚫ Version Information: 64 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...

  • Page 70: Device Reboot

    NVR100 User Manual The version information interface shows the current NVR software version. 4.2.7 Device Reboot User can click the reboot button to reboot the NVR. 65 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
  • Page 71 NVR100 User Manual 66 / 65 Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. Website: www.fourfaith.com Tel: +86-592-5907276 Fax: +86-592-5912735...
