RS232-RS485 Converter
Description
The RBH H485-232 can convert the data from RS232C to a half-duplex RS485 signal. It
gets its power directly from the serial port of the PC so it doesn't require an additional
power supply. Because of its "Automatic Send Data Line Control" function you do not
need to connect RTS, just plug it in. There is no need to install any other hardware or
software.
Specifications
1) Ports:
a) RS232C
b) RS485
2) Distance to Baud Rate:
Distance
500ft (150m)
2000ft (600m)
4000ft (1200m)
3) Size: 88mm X 33mm X 17mm
4) Operation Temperature: 0-70°C
5) Operation Humidity: 5-95%
RBH Access Technologies Inc.
Model# RBH H485-232
Baud Rate
115.2Kbps
19.2Kbps
9600bps
RBH-H485-232
