Model
Prepared by
Subject
Disassembly
This section covers the assembly and disassembly of ESL808 phone. In order to carry out the
assembly or disassembly the following precautions should be taken:
1. A Plus screwdriver is required to remove the four retaining screws, which holds the two casings
together. Ensure that the screwdriver is narrow enough to reach the screws without causing
damage to the casing parts.
2. The phone should always be placed on a soft surface to minimise the risk of damage being caused
to the casing, window and keypad. If the PCB is to be removed, then care should be taken not to stress
or scratch the exposed LCD.
3. Observe anti-static precautions when handling the main PCB or any of its components.
4. Repairs must only be undertaken by Ezze M Tech approved service centres.
5. Repairs carried out by unauthorised persons will result in the warranty on the unit becoming void.
6. Do not use solvents to clean any of the casing parts or the LCD window.
ESL808
H/W
Technical Manual
Version
Date
Page
V_0.01
20/09/2005
1/10
Advertisement
Summary of Contents for Elson ESL808
- Page 1 1/10 Disassembly This section covers the assembly and disassembly of ESL808 phone. In order to carry out the assembly or disassembly the following precautions should be taken: 1. A Plus screwdriver is required to remove the four retaining screws, which holds the two casings together.
- Page 2 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 2/10 Phone disassembly 1. Battery Cover and Battery Disassembly A. Pull up the lock knob in the arrow direction. B. Remove the battery 2. Sim card & Screw & Sheet & Io cap & Rear Cover & Internal Antenna & Disassembly A.
- Page 3 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 3/10 3. Side Key & Caps Disassembly A. Remove the caps and side key along the arrow direction. 5. Main PCB Disassembly A. From the front cover, separate the main PCB.
- Page 4 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 4/10 6. Keypad, Flexible PCB and Front cover Disassembly A. Separate the key PCB and Keypad from the front cover. B. Unscrew the four screws, and Remove the front cover.
- Page 5 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 5/10 8. LCD module & Keypad Disassembly A. Remove the LCD module from the top cover. B. Remove the keypad from the top cover. 9. LCD window Disassembly...
-
Page 6: Phone Assembly
Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 6/10 Phone Assembly 1. LCD window Assembly A. Group the LCD window on the top cover. 2. Keypad & LCD module Assembly A. Group the keypad onto the top cover... - Page 7 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 7/10 3. Back cover & Slide unit & Decos Assembly A. Group the back cover on the top cover. B. Group the slide unit along the arrow direction on the back cover C.
- Page 8 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 8/10 5. Main PCB Assembly A. Group the main PCB along the arrow direction. 6. Side Key & Caps Assembly A. Carefully group the caps and side keys along the arrow direction.
- Page 9 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 9/10 7. Rear cover & Screw & Deco & Sim card Assembly A. Group the internal antenna along the arrow direction B. Carefully group the rear cover along the arrow direction. Screw the four screws and attach the deco along the arrow direction.
- Page 10 Model ESL808 Version V_0.01 Prepared by Date 20/09/2005 Subject Technical Manual Page 10/10 A. Group the battery along the arrow direction. B. Pull down the lock knob along the arrow direction.
