Summary of Contents for Acuity Controls Blue Box
- Page 1 Blue Box ™ BLUE BOX PARTS REPLACEMENT GUIDE...
- Page 2 If any Emergency Circuits are fed or controlled from this panel, it must be located electrically where fed from a UPS, generator, or other guaranteed source of power during emergency and power outage situations. Blue Box LTD Parts Replacement Guide...
- Page 3 5. Blue Box LTD Control Cards - LCDACC 1404DM PCBA, LCDACC 1408DM PCBA and LCDACC 1416DM PCBA 6. Blue Box LTD Digilink - GR1400 LTD DIGILINK D6 (6 inputs) and GR1400 LTD DIGILINK D14 (14 inputs) DIN Relay Clips - LCDACC FCR CNVTKIT...
- Page 4 PARTS REPLACEMENT INSTRUCTIONS RELAY REPLACEMENT AND INSTALLATION ADDRESS function (Refer to Blue Box LTD Hardware Troubleshooting manual). Disconnect the RJ45 jumper cable from the DI card (leave it To remove a relay: connected to the control card). For master panels: Unscrew and open the hinged display-panel door Label and remove all low voltage conductors for contact closure to expose the low-voltage section.
- Page 5 Set time and date Re-connect all cables and conductors to the control card. Set location Power up the Blue Box LTD panel, look for the blinking “on line” LEDs on the control card(s). If necessary disable daylight savings time After the part replacement installation is complete, return the part using the prepaid UPS return label to factory.
- Page 6 TRANSFORMER REPLACEMENT AND INSTALLATION To remove a transformer De-energize the Blue Box LTD by switching off the breaker feeding the power supply (the relays in that panel will close). De-energize any other breakers that may present a hazard during installation.
