Summary of Contents for Sercomm BC852
- Page 1 FCC ID: P27BC852 BC852 Full HD Battery Camera Setup Guide Copyright 2019. All Rights Reserved. Document Version: 1.0...
-
Page 2: Table Of Contents
FCC ID: P27BC852 Table of Contents Chapter 1 Introduction ......................1 Package Contents ......................... 1 Chapter 2 Setup......................... 2 System Requirements ......................2 Physical Details - HD Battery Camera ................2 Pre-Installation ........................5 Installation ..........................7 Mounting Installation ......................7 Chapter 3 Viewing Live Video .................... -
Page 3: Chapter 1 Introduction
FCC ID: P27BC852 Chapter 1 Introduction Package Contents The following items should be included: If any of these items are damaged or missing, please contact your dealer immediately. 1. Full HD Battery Camera x 1 2. Battery Pack x 1 3. -
Page 4: Chapter 2 Setup
FCC ID: P27BC852 Chapter 2 Setup This Chapter provides details on how to install and configure the HD Battery Camera. System Requirements • A computer or mobile device with Internet access • You can use the following web browser while using a computer: •... - Page 5 FCC ID: P27BC852 Front Panel Microphone The built-in microphone is useful for bi-direction voice conversation. Light Sensor This is hardware sensor to detect LUX. Lens No physical adjustment is required or possible for the lens, but you should ensure that the lens cover remains clean. The image quality is degraded if the lens cover is dirty or smudged.
- Page 6 FCC ID: P27BC852 Side Panel Reset/WPS This button has two functions: • WPS: -WPS PBC Mode: When pressed and released (less then 3 seconds), the Camera will be in the WPS PBC mode (Auto link mode). -WPS Pin Code Mode: When pressed and held for over 3 seconds, the Camera will be in the WPS Pin Code mode.
-
Page 7: Pre-Installation
FCC ID: P27BC852 Pre-Installation Insert the Battery Pack Align the battery contacts and then insert the battery pack into the camera. Note: Be sure to charge the battery when use it for the first time. - Page 8 FCC ID: P27BC852 Battery Pack Charging You can charge your camera battery indoors using the Micro USB cable (not provided). Note: For safety reasons, the battery charging temperatures are from 5°C to 35°C. Put the battery pack into the camera. Connect the power Micro USB cable (not provided) to the USB port of the camera.
-
Page 9: Installation
FCC ID: P27BC852 Installation Move the camera to where it is to be placed. Check the LED: The Power LED should be solid blue when the camera is powering on. Mounting Installation Place the camera in a flat surface or mount it on the wall/ceiling. ... -
Page 10: Chapter 3 Viewing Live Video
FCC ID: P27BC852 Chapter 3 Viewing Live Video This Chapter provides basic information about viewing live video. Overview This Chapter has details of viewing live video using Internet Explorer. Requirements To view the live video stream generated by the HD Battery Camera, you need to meet the following requirements: •... - Page 11 FCC ID: P27BC852 7. The first time you connect to the camera, you will be prompted to install decoders. Choose "I accept the terms of the license agreement" and click "OK". 8. Video will start playing automatically. There may be a delay of a few seconds while the video stream is buffered.
-
Page 12: Chapter 4 Troubleshooting
FCC ID: P27BC852 Chapter 4 Troubleshooting This chapter covers the most likely problems and their solutions. Overview This chapter covers some common problems that may be encountered while using the HD Battery Camera and some possible solutions to them. If you follow the suggested steps and the HD Battery Camera still does not function properly, contact your dealer for further advice. -
Page 13: Appendix A Specifications
FCC ID: P27BC852 Appendix A Specifications Model BC852 Dimensions 72mm x 93mm x 71.35mm (H x W x D) ° ° Operating Temperature C to 50 ° ° Charging Temperature C to 35 ° ° Storage Temperature C to 50... -
Page 14: Regulatory Approvals
FCC ID: P27BC852 Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
