Instructions for Firmware Update to Version 2.1.5
1. Download firmware version 2.1.5 for the remote control from the Pluggit website:
2. Check compatibility between the firmware of your air handling unit and the firmware of your
remote control.
All components shown in the following table are compatible with firmware version 2.1.5.
1. Remove batteries from the remote control.
On the inside of the remote control you will find a micro-USB slot. It is located above the
battery compartment.
2. Connect remote control to your computer with a micro-USB cable.
3. Find the small hole on the back of the remote. A small push button is located inside the hole.
4. Use a pin or similar object to press the push button for 5 seconds.
The file folder of the remote control will open on your computer. It contains a BIN file
named firmware.bin.
5. Delete firmware.bin.
Instructions for Firmware
Upgrade to Version 2.1.5 AKL
APRC Remote Control
Firmware of Air
Handling Unit
Firmware
Version 268
for
AP190
AP310
AP460
AD160

UPGRADING THE FIRMWARE

REQUIREMENTS

PC-Software
APPs
iFlow II
IOS 2.02.30
2.13.74
AS 20.41 ipa
und
2.12.67
September 2017
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLUGGIT APRC and is the answer not in the manual?

Questions and answers

Summary of Contents for Soler & Palau PLUGGIT APRC

  • Page 1 APRC Remote Control Instructions for Firmware Update to Version 2.1.5 REQUIREMENTS 1. Download firmware version 2.1.5 for the remote control from the Pluggit website: 2. Check compatibility between the firmware of your air handling unit and the firmware of your remote control.
  • Page 2 Note The BIN file name is always the same. It does not indicate the firmware version. 6. Go to the folder where you saved the BIN file containing firmware version 2.1.5. 7. Copy the BIN file. Insert it in place of the deleted file. Close the file folder of the remote control.
  • Page 3 3. You are now in the installer menu. Move as far to the left to 88:88, and then click down In this position you can read out the firmware, and as well other firmware hardware, by clicking further down. 4. Leave the menu by clicking on the enter bottom for 3 seconds. You are in the start display menu.
