Position your camera angle
1. Loosen the ball head
angle knob.
2. Position your camera at
the angle you want.
Note: To position the
camera at a 90˚ angle,
line the camera lens over
the ball head notch.
3. Tighten the ball head
angle knob to lock it into
place.
Panning
Loosen the panning tension
knob so you can rotate the
camera a full 360˚ clockwise
or counterclockwise.
Caution: If you don't loosen
the knob and attempt to
pan to the left, you can
unscrew the tripod head
10
1
2
