GEM3NFC
Hardware Manual
Version .2
October 30, 2019
NORTH POLE ENGINEERING INTELLECTUAL PROPERTY
THIS DOCUMENT IS INTENDED FOR USE BY APPLICATION DEVELOPERS TO
CREATE APPLICATIONS COMPATIBLE WITH THE NORTH POLE ENGINEERING
GEM MODULE. USE OF THE TECHNICAL INFORMATION CONTAINED IN THIS
DOCUMENT TO CREATE COMPETING HARDWARE TO THE NORTH POLE
ENGINEERING GEM MODULE IS STRICTLY PROHIBITED.
North Pole Engineering
© North Pole Engineering Inc. 2019
221 N 1st St, Minneapolis, MN 55401
www.npe-inc.com
612.305.0440
Advertisement
Table of Contents
Related Manuals for npe GEM3NFC
Summary of Contents for npe GEM3NFC
- Page 1 GEM3NFC Hardware Manual Version .2 October 30, 2019 NORTH POLE ENGINEERING INTELLECTUAL PROPERTY THIS DOCUMENT IS INTENDED FOR USE BY APPLICATION DEVELOPERS TO CREATE APPLICATIONS COMPATIBLE WITH THE NORTH POLE ENGINEERING GEM MODULE. USE OF THE TECHNICAL INFORMATION CONTAINED IN THIS DOCUMENT TO CREATE COMPETING HARDWARE TO THE NORTH POLE ENGINEERING GEM MODULE IS STRICTLY PROHIBITED.
-
Page 2: Revision History
Revision History Version Revision Date Change History October 2, 2019 Initial draft October 30, 2019 Added mechanical drawing... -
Page 3: Table Of Contents
Table of Contents Revision History ............................. Overview and Key Features ........................ Features ..................................SpeciDication ............................SpeciJication Summary ............................Hardware SpeciDications ........................Block Diagrams ..............................GEM3NFC Overview ..........................Overview ................................... Data, power, & I/O connector ........................... Additional I/O ................................. NFC Reader ................................NFC Antenna ................................GEM3 module ................................SpeciDications ............................Operating Parameters ............................Operating Modes ............................ GymKit ..................................Smartphone Connection ..........................GEM3NFC Considerations ......................... -
Page 4: Specidication
GEM3NFC Hardware Manual Overview and Key Features The GEM3NFC module is been designed to allow OEMs to easily add Bluetooth, ANT+, Apple GymKit, Samsung Galaxy Active/Active 2 and NFC reader connectivity in their product offering. The GEM3NFC module incorporates North Pole Engineering GEMHCI protocol software speciJically designed to enable Jitness machines such as treadmills, exercise bikes, ellipticals, stair climbers and step machines to wirelessly communicate exercise data with the Apple Watch, smart phones, tablets, Jitness watches, and leaderboard software systems. The GEM3NFC module is based on Nordic Semicondutor’s nRF52840 multi-protocol Bluetooth and ANT+ chipset and integrates NXP’s PN7150X NFC reader controller. There is also space on the board for the Apple authentication 3.0 coprocessor to be mounted for applications where Apple GymKit support is needed. The GEM3NFC module offers a serial host interface and has a maximum transmit power of +8dBm, and a sensitivity of -95dBm. This manual is intended to assist with hardware integration of the GEM3NFC module into a given design. Details on North Pole Engineering’s GEMHCI protocol software can be found at http://npe-inc.zendesk.com. Features • -95 dBm sensitivity • TX Power-20 to +8dBm in 4dB steps • 240m line of sight range @ +8dBm • 15 mA peak TX @ 8dB, 6.2mA @ 0dBm • 4.6 mA peak RX • 1dB dB RSSI resolution • ARM® Cortex M4F 32 bit processor running at 64MHz • 1MB embedded Jlash memory and 256 kB RAM • Serial Host Interface • AES HW encryption • FCC, CE, IC certiJied •... -
Page 5: Hardware Specidications
Peripherals Serial Host Interface TX, RX 115.2kbps n,8,1 FW Upgrade North Pole Engineering Over the air Firmware Via JTAG interface Control Protocol GEMHCI binary command interface Supply Voltage Recommended 3.3V Power Consumption Less than 50mA peak Physical 40mm x 40mm Environmental -40 to +85C Approvals FCC, IC, CE, Bluetooth EPL North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com 612.305.0440... -
Page 6: Gem3Nfc Overview
GEM3NFC Overview Overview The following picture provides an overview of the various hardware elements of GEM3NFC board. NFC Antenna Additional I/O GEM3 Reader Data, Power & I/O Data, power, & I/O connector The data, power, and I/O connector provides a means to connect a supply voltage of 3.3V to the GEM3NFC module as well as UART TX and RX lines for serial communications between the GEM3NFC module and the Jitness equipment console MCU. The GEM3NFC UART lines are TTL level and operate at 115.2Kbps. The connector is JST BM14B-ZPDSS-TF(LF)(SN). The mating JST connector housing is JST ZPDR-14V-S and is available through Digi-Key and other distributors. Data, power, and I/O connections: V3R3 UART_TX Reset_N UART_RX North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com... -
Page 7: Nfc Reader
Addi8onal I/O The GEM3NFC module includes an additional connector for I/O. NFC Reader The GEM3NFC module incorporates an NFC reader chip allowing for decoding of compatible NFC tag data records enabling tap to pair support as well as NFC based user identiJication. NFC Antenna The GEM3NFC module includes an integrated NFC antenna. GEM3 module The GEM3NFC includes North Pole Engineering’s GEM3 Bluetooth 5.0 and ANT wireless OEM module and includes North Pole Engineering’s embedded software speciJically designed for Jitness equipment mobile app, group Jitness, and wearable connectivity applications. Specifica8ons Opera8ng Parameters Parameter Typical Supply Voltage 3.0V 3.3V +3.6V Operating Temperature @ 3.3V -40C +85C Serial Interface 3.3V 3.6V... -
Page 8: Operating Modes
Opera8ng Modes GymKit The GEM3NFC module when integrated into a Jitness equipment device can pair with a compatible Apple Watch using a “tap to pair” method where by an Apple watch is brought near an area of the Jitness equipment console where the GEM3NFC’s antenna has been located. The GEM3NFC module will sense the presence of the Apple Watch through it’s NFC antenna and reader circuitry and perform the necessary procedures to establish a Bluetooth connection with the Apple Watch. Once the connection has been established between the Apple Watch and GEM3NFC module, the console and Apple Watch can exchange workout data using the Bluetooth Fitness Machine Service and GymKit service. The following diagram outlines the operating Jlow for using the GEM3NFC for GymKit Applications: User messaging User messaging Integrated Integrated NFC Antenna NFC Antenna Fitness equipment is idle awai0ng connec0on User taps Apple Watch Area on Jitness equipment where GEM3NFC antenna is located. North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com... -
Page 9: Smartphone Connection
User conJirms connection and GEM3NFC establishes a Bluetooth connection with the User messaging Watch, performs link bonding, encryption, and authentication functions with the Watch User messaging User begins workout. GEM3NFC relays data from Jitness equipment to Watch using Bluetooth Jitness machine service. GEM3NFC receives HR and Calorie data from Watch using GymKIt service. Smartphone Connec8on The GEM3NFC module when integrated into a Jitness equipment device can pair with a mobile device with a compatible application such as North Pole Engineering GymTrakr using Bluetooth low energy. The GEM3NFC module will broadcast its presence to the mobile device and through the application’s user interface, the user can connect their mobile device to the Jitness equipment over a Bluetooth link. The following diagrams outlines the operating Jlow for using the GEM3NFC for Smartphone Connections:... - Page 10 GEM3NFC is idle awaiting connection from Watch or app User messaging through a Bluetooth connection. User initiates Bluetooth pairing through the console user interface and conJirms connection with the smart device. User begins workout. GEM3NFC relays workout data from Jitness equipment to smart device app using Bluetooth Jitness machine service. GEM3NFC sends received HR data to Jitness equipment console for display. North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com 612.305.0440...
-
Page 11: Gem3Nfc Considerations
GEM3NFC Considera8ons Mechanical items (especially metal) should be kept as far as possible from the module antenna in all directions, including above and below the board surface. If possible, move mechanical items out and away from a keepout area of 53mm x 20mm from the GEM3NFC module edge. Antenna Characteris8cs The GEM3NFC module includes an integrated monopole chip antenna. Antenna performance will depend on host PCB layout. The following plots show antenna radiation pattern of the GEM3NFC antenna. 2.4GHz 2.442GHz 2.484GHz Antenna Performance EfJiciency Peak Gain 2400MHz 65.72% 4.08 dBi -16.0 dB 2442MHz 62.72% 3.95 dBi -14.8 dB 2484MHz 59.73% 4.17dBi -13.3 dB... -
Page 12: Mechanical Information
Mechanical Informa8on Dimensions (in mm) 5.00mm Ø3.18mm Connec8ng GEM3NFC to Console MCU The GEM3NFC is designed for connection to Jitness equipment console MCUs through its Serial interface. The GEM3NFC serial interface has a TX line and RX line that are 3.3V tolerant and operate at 115.2Kpbs. North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com 612.305.0440... -
Page 13: Gem3Nfc Host Protocol
GEM3NFC Host Protocol The GEM3NFC supports North Pole Engineering’s GEMHCI protocol for communication between the GEM3NFC board and the console MCU using the GEM3NFC module’s serial host connection. The GEMHCI protocol supports a port speed of 115.2Kbps. The GEMHCI protocol is a binary protocol and is used to conJigure the GEM3NFC operation as well as pass Jitness equipment related data to the GEM3NFC for broadcasting to connection applications using its Bluetooth/ANT+ radio. The GEMHCI protocol can also be used to send data such as heart rate and calories from a connected Jitness application or device to the console through the GEM3NFC module. Details of the GEMHCI protocol are provided in the GEMHCI reference manual. Please visit our knowledge base at http://npe-inc.zendesk.com for the latest version of the GEMHCI reference manual. NFC Reader T4T card mode opera8on ISO/IEC 1444A card mode... -
Page 14: Iso/Iec 14443B Card Mode
ISO/IEC 14443B card mode Regulatory & Standards Informa8on FCC & Industry Canada The GEM3NFC module has modular approval for the United States and Canada. To ensure compliance when using the GEM3NFC module in a design, the OEM is required to adhere to the implementation considerations supplied in this hardware integration guide. Federal Communica8on Commission (FCC) Radia8on Exposure Statement: This device is in compliance with SAR for general population/uncontrolled exposure limits in ANSI/IEEE C95.1-1999 and had been tested in accordance with the measurement methods and procedures speciJied in OET Bulletin 65 Supplement C. This transceiver must not be co-located or operating in conjunction with any other antenna, transmitter, or external ampliJiers. Further testing / evaluation of the end product will be required if the OEM’s device violates any of these requirements. The GEM3NFC Module is fully approved for mobile and portable applications. North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com 612.305.0440... -
Page 15: Fcc Labeling Requirements
WARNING: The OEM must ensure that FCC labeling requirements are met. This includes a clearly visible label on the outside of the OEM enclosure specifying the appropriate FCC identiJier is visible. Contains FCC ID: XRH-NPE109 IC: 11922A-NPE109 If OEM device is larger than 8x10cm, the following FCC part 15.19 statement has to be visible on outside of device: The enclosed device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label and text information type should be large enough to be legible and consistent with the dimensions of the equipment and the label. The type size is not required to be larger than eight points. Comments The OEM should have their device tested by a qualiJied test house to verify compliance with FCC Part 15 Subpart B limits for unintentional radiators. Any modiJications to the GEM3NFC module could void the OEM’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does not cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to correct the interference by one or more of the following measures: • Re-orient or relocate the receiving antenna • Increase the separation between the equipment and the receiver • Connect the equipment to an outlet on a circuit that is different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC Warning: “THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES AND INDUSTRY CANADA LICENSE-EXEMPT RSS STANDARD(S). OPERATION IS SUBJECT TO THE FOLLOWING TWO... -
Page 16: Industry Canada (Ic) Warning
This device is in compliance with SAR for general population/uncontrolled exposure limits in IC RSS-102 and had been tested in accordance with the measurement methods and procedures speciJied in IEEE 1528. REMARQUE IMPORTANTE Déclaration IC d'exposition aux radiations Ce EUT est conforme avec SAR pour la population générale / limites d'exposition non contrôlée à IC RSS-102 et a été testé en conformité avec les méthodes de mesure et procédures spéciJiées dans la norme IEEE 1528. Modular Approval OEM is still responsible for testing their product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). Approbation modulaire OEM intégrateur est toujours responsable de tester leur produit Jinal pour les exigences de conformité supplémentaires nécessaires à ce module installé (par exemple, les émissions de périphériques numériques, les exigences de périphériques PC, etc.) IMPORTANT NOTE: In the event that these conditions cannot be met (for example certain laptop conJigurations or co-location with another transmitter), then the Canada authorization is no longer considered valid and the IC ID cannot be used on the Jinal product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate Canadian authorization. North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com 612.305.0440... - Page 17 NOTE IMPORTANTE: Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines conJigurations d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne peut pas être utilisé sur le produit Jinal. Dans ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit Jinal (y compris l'émetteur) et l'obtention d'une autorisation distincte au Canada. Le produit Jinal doit être étiqueté dans un endroit visible avec l'inscription suivante: " GEM3NFC Module Contient des IC: 11922A-NPE109"...
- Page 18 The GEM3NFC Module has been tested against the appropriate regulatory standards for European market. OEMs should consult a qualiJied test house to ensure their product meets all regulatory requirements. The GEM3NFC Module Declaration of Conformities is below. Test reports are available upon request. Health and Safety – EN60950-1: 2006+A11:2009+A1:2010+A12:2011 Electromagnetic compatibility – EN301489-17 V2.2.1 in accordance with EN 301 489-1 V1.9.2 Radio Frequency Radiated Emissions: EN300 328 V1.9.1 North Pole Engineering declares under our sole responsibility that the essential radio tests have been carried out and that the GEM Module to which this declaration relates is in conformity with all applicable essential requirements of Article 3 of the EU Directive 1999/5/EC when used for its intended purpose. Place of Issue: North Pole Engineering 221 North First Street, Suite 310 Minneapolis, MN 55401 Date: 8/1/2018 Authorized Person: Don Schroeder Signature: North Pole Engineering © North Pole Engineering Inc. 2019 221 N 1st St, Minneapolis, MN 55401 www.npe-inc.com 612.305.0440...
-
Page 19: Bluetooth Qualijication
The Bluetooth SIG requires every product implementing Bluetooth technology to have a Declaration ID even though the end product references a Bluetooth design with its own Declaration ID. An over of the Bluetooth SIG QualiJication Process is as follows: 1. Register as a member of the Bluetooth SIG – www.bluetooth.org Go to product listing page https://www.bluetooth.org/en-us/test-qualiJication/ qualiJication-overview 3. Go to Create a Listing: https://www.bluetooth.org/tpg/QLI_SDoc.cfm 4. In the area “Reference a QualiJied Design, Enter End Product ID: 77930 5. Select your Declaration ID or Purchase a Declaration ID. Fees for Declaration IDs vary based on Bluetooth SIG membership level. 6. Once you have completed your listing and paid your declaration fee, your design will be listed on the Blueooth SIG website. You can Jind more details on the Bluetooth SIG listing process at the following webpage: https://www.bluetooth.org/en-us/test-qualiJication/qualiJication-overview Ordering Details Part Number Trays Shipping Weight MOQ Multiple GEM3NFC0201 100 pieces Further Assistance Please contact North Pole Engineering at 1-612-305-0440 or via email at sales@npe- inc.com if additional help is needed. NORTH POLE ENGINEERING 221 North 1 Street, Suite 310 Minneapolis, MN 55401 Telephone: 1-612-305-0440 Email: sales@npe-inc.com www.npe-inc.com... - Page 20 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 21 FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance. Note 1: This module certified that complies with RF exposure requirement under mobile or fixed condition, this module is to be installed only in mobile or fixed applications.
- Page 22 Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
