Summary of Contents for Kurzweil Air MIDI
- Page 1 Air MIDI...
-
Page 2: Table Of Contents
The LED of Air MIDI's main adapter is not lit....................11 Can I connect the sub adapter of Air MIDI to the MIDI IN DIN connector alone when I only use MIDI IN? ..11 Can Air MIDI connect wirelessly with other BLE MIDI devices? ...............11... -
Page 3: Important Information
Improper connection may cause damage to the device. ● COPYRIGHT Copyright © 2020 Kurzweil Music Systems. All rights reserved. Kurzweil is a registered trademark of HDC-Young Chang Co., Ltd in Korea and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. -
Page 4: Connection
Main adapter Sub adapter The Air MIDI main adapter can be used with MIDI DIN connectors of MIDI devices that apply to the MIDI standard, such as: synthesizers, MIDI controllers, MIDI interfaces, keytars, electric wind instruments, v-accordions, electronic drums, electric pianos, electronic portable keyboards, audio interfaces, digital mixers, etc. -
Page 5: Add Air Midi Bluetooth Midi Function For Standard Midi Devices
CONNECTION ● Add Air MIDI Bluetooth MIDI function for standard MIDI devices 1. Plug the 2.5mm mini jack connector of Air MIDI’s sub adapter into the mini jack socket of the main adapter. 2. Plug Air MIDI’s main adapter into the MIDI OUT DIN connector of the MIDI device, and plug the sub adapter into the MIDI IN DIN connector. -
Page 6: Connect Air Midi With Macos
CONNECTION ● Connect Air MIDI with MacOS X 1. Turn on the power of the MIDI device with the Air MIDI plugged in, and confirm that the blue LED flashes slowly. 2. Click the [Apple icon] on the upper left corner of the screen, click the [System Preferences] menu, click the [Bluetooth icon], and click [Turn Bluetooth On], then exit the Bluetooth settings window. -
Page 7: Connect Air Midi With Windows 10
Therefore, you need to use specific apps dedicated to connecting Bluetooth MIDI devices as a bridge. 1. Turn on the power of the MIDI device with the Air MIDI plugged in, and confirm that the blue LED flashes slowly. -
Page 8: Specification
Bluetooth 5, MIDI over Bluetooth Low Energy-Compliant Connectors MIDI IN/OUT (5pin-DIN) Compatible MIDI devices with 5-pin DIN OUT, Air MIDI, Bluetooth MIDI devices controllers. Mac, iPhone/iPad/iPod Touch with Bluetooth 4.0 or later Compatible OS iOS 8 or later, OSX Yosemite or later... -
Page 9: Faq
- Does the MIDI OUT DIN connector of MIDI device supply power? You can ask the manufacturer of the MIDI device for relevant information. ● Can I connect the Air MIDI sub adapter to the MIDI IN DIN connector by itself if I am only using MIDI IN? - The sub adapter cannot work as standalone and must be connected with the mini jack of the main adapter. - Page 10 Facebook Http://www.facebook.com/kurzweilmusicsystems 196, Bongsu-daero, Seo-gu, Incheon, Korea...
