HPM LWK0110WBL Instruction Manual

LWK0240WBL
1 Specifications
Cat No LWK0110WBL
Supply Voltage
Input Power
Power Output
Lumens Output
Colour Temperature
Protection Class
Lens/Glass
IP Rating
Length of power cord
Weight (excl packaging)
Height adjustment
2 Assembly
For LWK0110WBL, LWK0120WBL and LWK0130WBL, mount the head lamp
on the stand and fix in place with mounting bolt. Tighten to secure.
For LWK0220WBL and LWK0240WBL:
1. Release the 3 leg adjustment bolts, set the 3 legs and allow to lock in
position as shown in diagram.
2. Mount the cross bar on to the tripod stand and fix in place with mounting
bolt. Tighten to secure.
3. Mount the head lamps on the cross bar and fix in place with mounting
bolt. Tighten to secure.
4. Set the height of the worklight to desired position and tighten the height
adjustment knobs.
5. Tilt and swivel the head lamps to desired position. Tighten moulded
knob. When adjusting the head lamps ensure no strain is placed on the
supply cord.
LWK0220WBL
LWK0120WBL
11W 23W
10W 20W
730lm 1615lm
1.1kg 1.7kg
N/A
Cat. LWK0110WBL, LWK0120WBL,
LWK0130WBL, LWK0220WBL,
LWK0130WBL LWK0120WBL
LWK0130WBL LWK0220WBL
230-240V a.c 50Hz
32W
30W
2250lm
Cool White 4000K Nominal
Class 1
4mm thick tempered glass
IP44
1.8m
2.5kg
Cross bar
Tripod stand
Cord storage hooks
LED Worklights
Instruction Manual
LWK0240WBL
LWK0110WBL
LWK0240WBL
22W 46W
2 x 10W 2 x 20W
2 x 730lm 2 x 1615lm
4.1kg 5.5kg
Tripod: min 0.65m, max 1.25m
Mounting bolt
Height adjustment knobs
Leg adjustment bolt (x3)
Head lamps
