Quick Start Guide
HAVEN® LOCKDOWN Z
High-strength, Z-WAVE enabled smart lock for
Commercial applications.
1
Safety, Warnings, Regulations
3
Warranty
4
Installing Your HAVEN Lockdown
5
Z-WAVE Operation
9
LED and Sounds
10
Outward-swinging door con guration
11
In-swinging door con guration
12
Hardware Accessory Installation
14
Troubleshooting
15
Important Safeguards
Patent Protected: European Patent Number: 3,194,692; Issued: China; U.S.A. Patent: 10,669,758 / 10,851,568
HavenLock Inc - The Smarter, Stronger Way to STOP An Active Threat
™
PLACE DSK HERE
V 4.4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HavenLock HAVEN LOCKDOWN Z
Summary of Contents for HavenLock HAVEN LOCKDOWN Z
- Page 1 In-swinging door con guration Hardware Accessory Installation Troubleshooting Important Safeguards PLACE DSK HERE Patent Protected: European Patent Number: 3,194,692; Issued: China; U.S.A. Patent: 10,669,758 / 10,851,568 HavenLock Inc - The Smarter, Stronger Way to STOP An Active Threat V 4.4...
-
Page 2: Important Safety Instructions
Owner is responsible to ensure proper t and correct installation. Owner is responsible for safety of themselves and others. If you are unsure if this product is right for you, please consult our Help Team at support@havenlock.com or other security professional. -
Page 3: Regulatory Information
(2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modi cations which are not expressly approved by HavenLock Inc could void the user’s authority to operate the equipment. AVERTISSEMENT: Les changements ou modi cations qui ne sont pas approuvés par HavenLock Inc pourrait annuler l'autorité de l'utilisateur de faire fonctionner l'équipement... -
Page 4: Warranty Information
Any major malfunction of HAVEN Lockdown caused by a defective part or construction of the unit will be fixed by HavenLock Inc up to one year from the date of receiving the unit. This warranty only covers the original purchaser of HAVEN Lockdown. Only commercial use by the original purchaser is covered by this warranty. If HAVEN Lockdown is installed improperly, used in any way not in accordance with our guidelines, or altered in any way, this warranty is void. - Page 5 Your lock may come with a wire harness (G) protruding from the control panel. This wiring harness is used for connecting an accessory to the lock. Before you proceed to hardwiring any accessory please follow the instructions on the hardwire accessory installation page. Need help? Contact us at support@havenlock.com...
-
Page 6: Button Functions
QUICK START GUIDE 5 Z-WAVE OPERATION Haven Lockdown with Z-Wave Plus This product can be operated in any Z-WAVE network with other Z-WAVE certified devices from other manufacturers. All mains operated nodes within network will act as repeaters regardless of vendor to increase reliability of the network. Button Functions There are two buttons on the Haven Lock device. -
Page 7: Association Groups
6 HAVEN Lockdown Z-WAVE Lock Operation 1. To Lock: Sending command class = COMMAND_CLASS_DOOR_LOCK, command = DOOR_LOCK_OPERATION_SET, mode = 0xFF (DOOR_SECURED) or BASIC_SET value 0xFF will raise the gate. Notification Type Access Control, Event 0x03 (RF lock operation) is sent to the Lifeline and then one second later, a Door Lock Operation Report is sent to the Lifeline. - Page 8 7 HAVEN Lockdown Command Class List (Security: None) Name Version COMMAND_CLASS_ZWAVEPLUS_INFO COMMAND_CLASS_TRANSPORT_SERVICE COMMAND_CLASS_SECURITY COMMAND_CLASS_SECURITY_2 COMMAND_CLASS_SUPERVISION Command Class List (Security: S0 or Access Control) Name Version COMMAND_CLASS_VERSION COMMAND_CLASS_MANUFACTURER_SPECIFIC COMMAND_CLASS_DEVICE_RESET_LOCALLY COMMAND_CLASS_INDICATOR COMMAND_CLASS_POWERLEVEL COMMAND_CLASS_BATTERY COMMAND_CLASS_NOTIFICATION COMMAND_CLASS_DOOR_LOCK COMMAND_CLASS_CONFIGURATION COMMAND_CLASS_ASSOCIATION COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION COMMAND_CLASS_ASSOCIATION_GRP_INFO COMMAND_CLASS_FIRMWARE_UPDATE_MD...
-
Page 9: Configuration Parameters
8 HAVEN Lockdown Notification Command Class All notifications are sent unsolicited. Notification Name Type (Value) Notification Name Value Manual lock operation 0x01 Access Control (0x06) Manual unlock operation 0x02 RF lock operation 0x03 RF unlock operation 0x04 Lock jammed 0x0B Impact detected 0x0A Home Security (0x07) -
Page 10: Led And Sounds
Yellow Every 2.5 Seconds Battery is charging. Reset successful (after pressing 3 Yellow, 2 Chirp (After Reset) reset button) 3 Yellow, 1 Chirp (Security Unit is locked and detects an impact notification) Need help? Contact us at support@havenlock.com... - Page 11 10 HAVEN Lockdown OUTWARD-SWINGING DOOR CONFIGURATION...
- Page 12 QUICK START GUIDE 11 IN-SWINGING DOOR CONFIGURATION...
- Page 13 (exit ability on both sides of side bracket) Accessory attachment connector (W) Strain relief (X) Haven Lockdown Z is equipped with optional wired control capability to support accessories, such as egress, emergency lock (panic), motion sense and others. The wiring harness contains five conductors: Conductor Color...
- Page 14 DISCLAIMER Use of this guide at your own risk. HavenLock Inc and its parent or partner companies are not liable for any damages to property or bodily injuries that occur during or after installation. HavenLock Inc assumes no responsibility in providing the correct tools and accessories needed for installation unless otherwise noted.
-
Page 15: Pairing Troubleshooting
Below are some common issues you might encounter while installing or operating your HAVEN Lockdown Z. If you do not see your issue below, contact us at support@havenlock.com. -
Page 16: Important Safeguards
The Z-Wave™ word mark and logos are registered trademarks owned by Silicon Laboratories, Inc. and its subsidiaries and any use of such marks by HavenLock, Inc is under license. Other trademarks and trade names are those of their respective owners.
