Summary of Contents for Becom 150-3078-1
- Page 1 PoE-Splitter User Manual Version 3...
- Page 2 This document is protected by copyright. All rights reserved. No part of this document may be reproduced or transmitted for any purpose in any form or by any means, electronically or mechanically, without expressly written permission by BECOM Systems. Windows is a registered trademark of Microsoft.
-
Page 3: Table Of Contents
Top Hat Rail Mount ......................................8 2.3.2 Wall mount ..........................................8 Connecting the Device ........................................9 3.1.1 Connecting the Camera using a dedicated Camera Cable from BECOM Systems........10 Technical Information ........................................11 PoE ................................................ 11 Operating Conditions ......................................11 Product Anomalies ......................................... 11 Trouble Shooting .......................................... - Page 4 BECOM Systems takes no liability for any damages and errors causing of the usage of this board. The user of this board is responsible by himself for the functionality of his application. He is allowed to use the board only if he has the qualification.
-
Page 5: General Information
General Information This guide applies to the PoE-Splitter from BECOM Systems. Follow this guide chapter by chapter to set up and understand your product. If a section of this document only applies to certain camera parts, this is indicated at the beginning of the respective section. -
Page 6: Safety Instructions
The electric supply must only be made via PELV circuits. The device must only be powered by a limited energy source (≤ 30 V; ≤ 8 A; ≤ 100 VA). Disconnect power before connecting the unit. © BECOM Systems 2021 6 | 15... -
Page 7: Mechanical Installation
Figure 2-1: Front view dimensions 2.2 Top view Top Hat Rail Mount (optional) Nut for Wall Mounting Nut for Wall Mounting Figure 2-2: Top view dimensions 2.3 Mounting There are two mounting possibilities © BECOM Systems 2021 7 | 15... -
Page 8: Top Hat Rail Mount
Figure 2-3: Hat rail mount 2.3.2 Wall mount Two nuts in the housing can be used for wall mounting the device. Please refer to Figure 2-2 to see the dimensions and positions of the nuts. © BECOM Systems 2021 8 | 15... -
Page 9: Connecting The Device
Data OUT Connect this to your camera with a CAT5e or higher category patch cable or connect it with the RJ45 plug of your dedicated camera cable from BECOM systems. 24V DC OUT Connect this header to the power supply cable of your camera. Refer to Figure 3-2 for the pin description or connect it to the dedicated wires of your camera cable from BECOM Systems using an appropriate mating part. -
Page 10: Connecting The Camera Using A Dedicated Camera Cable From Becom Systems
User Manual - PoE-Splitter Last change: 25 March 2021/Version 3 3.1.1 Connecting the Camera using a dedicated Camera Cable from BECOM Systems Argos3D-P2x cable To Switch / Injector Figure 3-3: Example for connecting an Argos3D-P2xx camera to the PoE-Splitter © BECOM Systems 2021... -
Page 11: Technical Information
Depends on the connected camera device. The drawn peak current should not exceed the limit as defined in 802.3 for the negotiated PoE class. 4.3 Product Anomalies Applies to Date Description V1.0.0 14.09.2020 No anomalies reported yet Table 4-2: Product anomalies © BECOM Systems 2021 11 | 15... -
Page 12: Trouble Shooting
PoE class. Table 5-1: Troubleshooting list 5.1.2 Support General support for products can be found at BECOM Systems’ support site Support Link support.systems.becom-group.com For further questions please contact our support team at support.systems@becom-group.com. -
Page 13: Ordering Information
User Manual - PoE-Splitter Last change: 25 March 2021/Version 3 6 Ordering Information Product Ordering Product Description Number 150-3078-1 PoE-Splitter Basic device with different mounting options Table 6-1: Ordering information © BECOM Systems 2021 13 | 15... -
Page 14: Document Revision History
User Manual - PoE-Splitter Last change: 25 March 2021/Version 3 7 Document Revision History Version Date Document Revision 14.09.2020 Initial draft 03.12.2020 Figures added 25.03.2020 Typos corrected Table 7-1: Document revision history © BECOM Systems 2021 14 | 15... -
Page 15: A List Of Figures And Tables
Table 3-1: Connector Description ........................................... 9 Table 4-1: Operating Conditions ..........................................11 Table 4-2: Product anomalies ............................................ 11 Table 5-1: Troubleshooting list ..........................................12 Table 6-1: Ordering information ..........................................13 Table 7-1: Document revision history ........................................ 14 © BECOM Systems 2021 15 | 15...
