Summary of Contents for RICE HYDRO TR Series
-
Page 2: Connecting The Pump
RICE HYDRO, INC. - MANUFACTURER'S OPERATING INSTRUCTIONS TR-SERIES MODEL TEST PUMPS FOR WARRANTY REGISTRATION CALL: 1-800-245-4777 REMEMBER THESE CAUTIONS: Electric Models - Power source must meet voltage, phase, hertz and amperage requirements of electric motor, as stated on label. If an extension cord is used, requires at least 12 gauge 3 wire with maximum of 25 foot length. - Page 3 UDOR U.S.A. Plunger Pump Parts Breakdowns & Reference Guide...
- Page 4 PARTS BREAKDOWN FOR MODEL TRD-2/TRH-2 RICE HYDRO, INC. PART NUMBER.. DESCRIPTION.. REQ'D UD04-0006.09 BEARING UD04-0007.18 SEAL UD02-0007.24 SEAL UD04-0009.09 RETAINER CLIP UD04-0014.20 PLUNGER ROD UD04-0023.22 SUPPORT RING UD04-0031.49 CRANKSHAFT UD04-0103.41 CONNECTING ROD UD04-0208.70 BEARING COVER UD04-0208.72 BACK COVER UD04-0209.56 CRANKCASE UD04-0214.21...
- Page 5 PARTS BREAKDOWN FOR MODEL TRD-2/TRH-2 RICE HYDRO, INC. OUTLET HOSE.. HOSE-3/8X8-RH 8' FOOT OUTLET HOSE - STANDARD COUPLERPLUG-3/8M MALE PUMP OUTLET - PIPING COUPLERBODY-BR-3/8F FEMALE PUMP OUTLET - HOSE HOSE-3/8-3000XFT SPECIFY LENGTH OF HOSE FITTING-3/8-MPIPE FITTING FOR HOSE - RIGID...
