Multi-Function Convection Microwave
Instruction Manual
Model: ZEACMKT120S
1.0 Cu. Ft. Air Fryer, Convection Microwave Oven and Grill
with Built-in Trim Kit
For your safety and the ongoing enjoyment of this product
always read these instructions carefully before using your
microwave oven.
SAVE THESE INSTRUCTIONS
www.zest-usa.com
Advertisement
Table of Contents
Related Manuals for Zest ZEACMKT120S
Summary of Contents for Zest ZEACMKT120S
- Page 1 Multi-Function Convection Microwave Instruction Manual Model: ZEACMKT120S 1.0 Cu. Ft. Air Fryer, Convection Microwave Oven and Grill with Built-in Trim Kit For your safety and the ongoing enjoyment of this product always read these instructions carefully before using your microwave oven.
-
Page 2: Specifications
Specifications Model: ZEACMKT120S Rated Voltage: 120v~60hz Rated Input Power (microwave): 1500 watts Rated Output Power (microwave): 1000 watts Rated Input Power (Grill): 1150 watts Rated Input Power (Convection): 1500 watts Oven Capacity: 1.0 cubic feet ( 28 Liters) Turntable Diameter: 12.4 inches (315mm) -
Page 3: Safety And Precautions
SAFETY AND PRECAUTIONS Thank you for purchasing this quality Zest appliance. This manual contains important information on the installation, use, and care of your appliance. Please read this manual carefully before installation and operation of this machine to prevent injury and property damage. -
Page 4: Important Safety Instructions
Safety and Precautions ➢ WARNING This product contains a chemical known to the State of California to cause cancer, birth defects, or other reproductive harm. This appliance can cause low- level exposure to some of the substances listed, including benzene, formaldehyde, and carbon monoxide. - Page 5 Safety and Precautions ➢ IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) WARNING - To reduce the risk of fire in the oven interior: • DO NOT overcook food. • carefully attend appliance when paper, plastic or other combustible materials are placed inside the oven to facilitate cooking. •...
- Page 6 Safety and Precautions ➢ IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) WARNING – PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY • DO NOT attempt to operate this oven with the door open, this can result in harmful exposure to microwave energy. It is important not to break or tamper with the safety interlocks.
-
Page 7: Critical Installation Warnings
Safety and Precautions ➢ IMPORTANT SAFETY INSTRUCTIONS (CONTINUED) CRITICAL INSTALLATION WARNINGS The installation of this appliance MUST be performed by a qualified technician or service company. Failing to have a qualified technician or service company install the oven may result in electric shock, fire, an explosion, problems with the product or injury. -
Page 8: Grounding Instructions
Safety and Precautions ➢ GROUNDING INSTRUCTIONS (SAVE THESE INSTRUCTIONS) This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord with a grounding plug. -
Page 9: Radio Interference
Safety and Precautions ➢ RADIO INTERFERENCE Operation of your microwave oven may cause interference to your radio, TV or Similar equipment. If there is interference, it may be reduced or eliminated by using the following steps: • Clean the door of the microwave and seal the surface of the oven •... -
Page 10: About Microwave Cooking
➢ About Microwave Cooking MATERIALS YOU CAN USE IN A MICROWAVE Arcing is a spark or electric flash that crackles and/or pops. Arcing can produce heat that is very intense and can damage the interior of the microwave or container(s) used. Arcing can also cause fire. - Page 11 ➢ About Microwave Cooking 5. Please take precautions when testing all “microwave-safe” materials and or containers. 6. DO NOT allow children to conduct this test. MATERIALS YOU CAN USE IN A MICROWAVE | COOKWARE It is not required to buy all new cookware after purchasing your microwave oven. Many of the cookware pieces you already own can be used successfully in your new power convection microwave oven.
-
Page 12: Materials To Be Avoided In A Microwave Oven
➢ About Microwave Cooking MATERIALS TO BE AVOIDED IN A MICROWAVE OVEN The chart below will help you decide what utensils, containers and coverings may be used with each feature. Make sure utensils DO NOT touch the interior walls of the oven during cooking. - Page 13 ➢ About Microwave Cooking UNDERSTANDING YOUR OVEN (continued) Convection microwaves will become HOT after use. Look for the top grill or grill and convection symbols to be lighted in the display panel when the unit is hot. DO NOT use the oven for anything other than food preparation. DO NOT use the oven to dry clothes or newspapers.
-
Page 14: Parts And Accessories
SETTING UP YOUR OVEN (PARTS & ACCESSORIES Thank you for purchasing this quality Zest appliance. We are excited for you to get started using your new Multi-Function Air Fryer, Convection Microwave Oven and Grill. Remove all packaging materials and accessories from the carton and oven cavity. - Page 15 ➢ Parts & Accessories SETTING UP YOUR OVEN (TURNTABLE INSTALLATION) Please reference the diagram below to help during installation. NEVER place the glass tray upside down. The glass tray should NEVER be restricted. Both glass tray and turntable ring assembly must always be used during cooking. All food and containers of food should always be placed on the glass tray for cooking.
-
Page 16: Built-In Model
➢ Installation Built-in Model This model is provided with duct work and trim pieces which are UL listed to be installed as a built-in unit. (Separate instructions are provided for this feature). If you use this product without the provided built-in assembly the countertop installation application below applies. -
Page 17: Control Panel And Features
➢ Control Panel & Features UNDERSTANDING THE CONTROL PANEL Please reference the diagram below: Multi-Function Microwave Oven Settings: 1- CONVECTION 2- BROIL/GRILL 3- DEHYDRATION 4- POWER 5- DEFROST 6- AUTO MENUS: POPCORN POTATO BEVERAGE REHEAT FRESH VEGETABLE FROZEN VEGETABLE 6 - CONVECTION MENU: ROAST CHICKEN CAKE PIZZA... - Page 18 ➢ Operation Instructions BEFORE OPERATING YOUR OVEN Before operating your new microwave oven it is important that you read and understand the instruction booklet and operating instructions completely. Before the oven can be used, please complete the following procedures: (1) Plug in the oven and close the door (2) Touch the Stop/Clear pad so that 0:00 appears (3) Set the clock SET THE DISPLAY CLOCK...
- Page 19 ➢ Operation Instructions STOP / CLEAR Touch the STOP/CLEAR pad if you would like to: (1) Erase your selection if you made a mistake during program selection. (2) Cancel the kitchen timer set. (3) Return the time to the display (4) Touch once to temporarily stop the oven during cooking (5) Touch twice to cancel a program during cooking SAFETY PRECAUTIONS TO UNDERSTAND...
-
Page 20: Microwave Cooking
➢ Operation Instructions MICROWAVE COOKING Your microwave has 10 preset power levels. Pressing POWER will allow you to change or choose the power level. You can program your oven for up to 99 minutes and 99 seconds. Enter the seconds after the minutes even if they are both 0 (zeros). -
Page 21: Power Levels
➢ Operation Instructions POWER LEVELS The default power level for your microwave oven is HIGH. To change the power level to something other than HIGH, repeatedly press the power button until the power level you desire is reached. Power counts down from HIGH to LOW and the number buttons allow you to set the cooking time. - Page 22 ➢ Operation Instructions DEFROST This is the perfect feature if you want to defrost by weight or by time To DEFROST BY WEIGHT • Press DEFROST once so the oven displays dEF1. Micr. and indicators will light • Use the number keys to set defrosting weight within the range of •...
- Page 23 ➢ Operation Instructions – Convection Cooking UNDERSTANDING CONVECTION COOKING The CONVECTION feature of this oven allows you to use your microwave oven as a traditional oven. When the CONVECTION function is on the microwave function is NOT used. The CONVECTION feature can be used for cooking, baking, roasting, reheating and grilling foods offering limitless family cooking options.
- Page 24 ➢ Operation Instructions – Convection Cooking CONVECTION SETTINGS There are 2 different setting options when using CONVECTION cooking (1) convection with preheating and (2) convection without preheating. You can preheat your oven to the convection temperature required. CONVECTION Cooking with Preheating EXAMPLE: Preheat to 350F and cook 30 minutes at the same temperature •...
- Page 25 ➢ Operation Instructions – Food Dehydration USING DEHYDRATION (refer to diagram on following page) 1. Press Dehydration once, the oven LED will display LP. 2. Press the number buttons to select the expected function, a) for Warming box, Press number 1, LED will display L1. b) for Keep warm, Press number 2, LED will display L2.
- Page 26 ➢ Operation Instructions –Food Dehydration & Air Fry Menu Display Function Time Range Temperature Level 105° F 120° F 140°F Warming box 5sec~95min 160°F 175°F 195°F 210°F Keep warm 5sec~95min 140°F 160°F 175°F 105° F 120° F 140°F Food dry 10min~ 12hour 160°F 175°F 195°F yogurt/ ferment...
- Page 27 ➢ Operation Instructions – Convection & Grill GRILLING Use the GRILL program to program up to 2 automatic cooking options. Your oven includes a reversible grill rack. One side has shorter legs to allow you to place food closer to the grilling heat, the side with the longer legs allows you to place food further away from the grilling heat.
- Page 28 ➢ Operation Instructions – Express Menu Buttons Auto Menu Express Cooking To help make your microwave oven experience easier we have included several popular automatic settings to help prepare commonly cooked foods. Each food is cooked using the best cook time as indicated in the below cooking guide. To use the Auto Menu Express Cooking settings press the function you need (Example: Popcorn) enter the weight (lbs or oz) or the amount (cups or units) of food, then press START/+30SEC to begin cooking.
- Page 29 MICROWAVE AUTO MENU EXPRESS COOKING GUIDE Auto Express Cook Guide for Microwave Auto Express Cook Guide-CONVECTION Menu Weight (Oz) Display 1.75 oz 1.75 oz Menu Weight (Oz) Display Popcorn 3.00 oz 3.00 oz 16.00 OZ 16.00 OZ 3.5 oz 3.5 oz 24.00 OZ 24.00 OZ Potato...
- Page 30 ➢ Operation Instructions – Express Menu Buttons EXPRESS COOKING WITH CONVECTION Your microwave has automatic convection cooking settings to help prepare roasted chicken, cake and pizza. Each food is cooked using the best cook time as indicated in the below cooking guide. To use the EXPRESS COOKING settings press the function you need (Example: Cake) enter the weight (lbs or oz) or the amount (cups or units) of food, then press START/+30SEC to begin cooking.
-
Page 31: Child Safety Lock
➢ Operation Instructions – Other Features CHILD SAFETY LOCK Using your child safety lock will prevent unwanted or accidental oven operation by setting the oven to deactivate or lock the control panel. Lock your control panel by pressing STOP/CLEAR for 3 seconds. You will hear a long beep confirming that the child lock is activated and a lock icon will appear. -
Page 32: Maintenance
➢ Maintenance KEEP YOUR OVEN CLEAN Your oven was designed with an easy to sanitize stainless steel interior and deluxe NO FINGERPRINT stainless steel front. ONLY use mild, non-abrasive soaps or detergents with a soft cloth or sponge to clean the oven’s surface and oven walls. DO NOT clean the outside of the microwave oven using cleaners that container ammonia or alcohol as they will damage the appearance of the microwave. -
Page 33: Troubleshooting
➢ Troubleshooting Trouble Possible Cause Possible Remedy (1) Electrical cord is not plugged in. (1) Plug into the outlet (2) Close the (2) Door is open (3) Wrong door & try again (3) Check Oven will not start operation is set instructions (1) Use microwave-safe cookware (1) Materials to be avoided in... -
Page 34: Limited Warranty
CONSEQUENTIAL DAMAGE OF PROPERTY. SOME STATES DO NOT ALLOW THE ABOVE LIMITATION; THEREFORE THE EXCULSION MAY NOT APPLY TO YOU. IN ADDITION, THIS WARRANTY GIVES SPECIFIC LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS, WHICH VARY FROM STATE TO STATE. Warranty Provided By: Zest c/o Salvinco LLC www.zest-usa.com...
