- Page 1 MK3 OUT OF PARLOUR REVIVER INSTALLATION Version - July 2009 Part Number - 39-0305...
-
Page 2: Table Of Contents
MK3 OUT OF PARLOUR REVIVER INSTALLATION: INDEX GOOD PRACTICE: Mains Supply. INDEX A clean 230volt 50Hz AC mains supply together with a sound earth is essential for trouble-free feeding management. Good Practice: INDEX Although ATL power supplies incorporate several advanced mains protection features, time spent installing a good Data and Feeder Cabling: mains source with be very beneficial. - Page 3 MK3 OUT OF PARLOUR REVIVER INSTALLATION: 1 Data Cables The data cable supplied is ‘twisted pair’ configuration especially designed for communications. The portable Console unit contains the computing circuitry, stores the herd data and controls the No other cables should be used as replacements. Ensure it is connected exactly as shown in the tag reading and feeding process.
-
Page 4: Interface Siting
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 2 Scanning Out Of Parlour Feeding System: Interface Siting: Systems up to 4 Stalls 230vAC In Out-Of-Parlour Power Supply Power Supply +12v Regulated: Feeders: BROWN 0v: Feeders: BLUE +15v Control: RED 0v Control: BLACK Pulse-to-Time Interface Contains 2 Pulse-to-Time PCB’s Out-Of-Parlour... -
Page 5: Fitting The Antennas
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 3 Fitting the Antennas Drill four holes 6.5mm diameter corresponding to the antenna mounting holes, though the inside 'cheek' of the manger- on the left hand side (standing in front of the installation). All of the antennas must be on the same side. Drill a 10mm hole through the manger wall directly behind the antenna and fit a grommet supplied. -
Page 6: Power Supply
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 4 Out of Parlour Power Supply Mains Voltage: 230volt AC Feeder Output Voltage: Nominal 12volt DC Control Output Voltage: Nominal 15volt DC Mains Fuse: 5 Amp - Use 1 Inch type conforming to BS1362 only Control Fuse: T2 Amp - Use 20mm type DISCONNECT MAINS SUPPLY BEFORE REMOVING... -
Page 7: Power Supply Connections
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 5 Out of Parlour Interface Power Supply Connections 0volts DC +12volts DC FEEDER +15volts DC CONTROL 0volts DC Connecting the Power to the Out-Of-Parlour Interface: each With the mains supply switched OFF, for Interface: Run RED 1.0csa from the Power Supply +15volt connector. - Page 8 MK3 OUT OF PARLOUR REVIVER INSTALLATION: 6 Antenna and Motor Interface PCB Connections: 12volt Regulator Trigger Pulse The Motor connections are the same for all 4 outputs: to Feeder(1) MOTOR Trigger Pulse to Feeder from Pulse-to-Time Interface(s) Trigger Pulse to Feeder(2) Trigger Pulse to Feeder(3) Trigger Pulse...
-
Page 9: Feeder Motor Connections
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 7 OOP Reviver Feeder Motor Wiring into Pulse-to-Time Interface and OOP Interface Controlling Competitors Feeders without feedback using Pulse-To-Time PCB. Time adjust: Feeder (2) Time adjust: Feeder (1) Turn clockwise to increase. Turn clockwise to increase. 1 2 3 4 5 6 7 8 Fuse: 20mm 5Amp Connected to pin (1) N/C... - Page 10 MK3 OUT OF PARLOUR REVIVER INSTALLATION: 8 OOP Reviver Feeder Motor Wiring into Pulse-to-Time Interface and OOP Interface Continued Controlling Competitors Feeders without feedback using Pulse-To-Time PCB. Feeder +V Supply Feeder Negative Control 0V Supply Control +V Supply Pulse To Time PCB Feeder Motor(1) Feeder(1) Feeder(2)
- Page 11 MK3 OUT OF PARLOUR REVIVER INSTALLATION: 9 Out of Parlour Interface Meridian Bus Connections Green Yellow Black Blue White Twisted Pair Meridian Bus: 2 x Black MERIDIAN White Connecting the Out-Of-Parlour Interface with Reader: Console Local Socket Connections: from Rear (Refer to Page 7) The Meridian Bus is the cable along which data is routed.
-
Page 12: Meridian Bus Connections
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 10 Interface Unit PCB Connections: For 8 Stalls: Meridian Bus to OOP Console From Pulse-to-Time Interface Feeder Trigger Pulse Interface 1: Feeders 1-4 Meridian Bus between the two Interfaces From Pulse-to-Time Interface Feeder Trigger Pulse Interface 2 - Feeders 5-8... - Page 13 MK3 OUT OF PARLOUR REVIVER INSTALLATION: 11A Interface PCB Reader Connections - TIRIS S2000 Reader: READER Antenna Tuning Point: Connect a multi-meter set to DC Volts 200 across the connectors: Positive probe to: TUNING Negative probe to: Red LED: Data Ready Green LED: Communicating Screen Reader Module...
- Page 14 MK3 OUT OF PARLOUR REVIVER INSTALLATION: 11B Interface PCB Reader and Power Supply Connections - ATL HDX Reader: READER Antenna Tuning Point: Connect a multi-meter set to DC Volts 200 across the connectors: Positive probe to: TUNING Negative probe to: Red LED: Data Ready Green LED: Communicating Screen...
-
Page 15: Tuning The Antennas
MK3 OUT OF PARLOUR REVIVER INSTALLATION: 12 Tuning the Antennas: Subroutine 305 (Pages 10A or 10B) The antennas must be tuned for effective performance. The antenna tuning voltages will vary slightly according to the distance from the reader. The object of tuning is to obtain the highest overall voltages for all the antennas. - Page 16 DATA SHEET: REVIVER MAIN BOARD MODIFICATION Details of the changes to Out-Of-Parlour main circuit board to accommodate Reviver installations: All 4 resistors (Value 10k Ohms) will have to be moved as shown below: 2: Carefully rotate the resistor to the right until it reaches the 3: Press the resistor to the pad using a small screwdriver 1: Snip the resistor lead at the left hand end spare solder pad.
