Summary of Contents for Purpleline Imperium LITHIUM BATTERY 105AH
- Page 1 LITHIUM BATTERY 105AH ULTRA LIGHT WEIGHT HIGH CAPACITY EXTREME POWER LONG LIFE USER MANUAL PART NUMBER: IMP001 Tel: 03 9588 2959 Email: enquiries@purpleline.com.au Web: www.purpleline.com.au...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Product description ............................2. Safety instructions ............................2.1 Safety instructions statement ......................2.2 Safety instructions ........................... 2.3 Transport alert ............................3. Description and Operation ......................... 3.1 Charging ................................ 3.2 Imperium Lithium App........................3.3 Storage ................................3.4 Installation .............................. -
Page 3: Product Description
PRODUCT DESCRIPTION The Imperium Lithium 105Ah is a Lithium-iron phosphate (LiFePO4) battery. This is the safest of the most important lithium-ion battery types. Besides safety, the LiFePO4 technology is characterized by: Minimal weight Small dimensions Low internal resistance High efficiency Excellent cycle performance Large permitted temperature range Almost constant Voltage throughout the entire discharge cycle... - Page 4 Too high temperature - The BMS will turn off the battery if the system temperature becomes too high. Too low temperature - The BMS prevents the battery from being charged at temperatures below -10°C. Short circuit - The BMS switches the battery off if the terminals are shorted.
-
Page 5: Safety Instructions
SAFETY INSTRUCTIONS 2.1 Safety instructions statement These safety instructions are divided into 3 categories, as follows WARNING! Danger, these instructions must be followed to prevent injury or harm CAREFUL! These instructions must be followed to prevent damage PAY ATTENTION! Important advice and guidance 2.2 Safety instructions Carefully read this manual before using the battery pack. - Page 6 Never short-circuit the + and - poles. The internal BMS is protected against short circuits, but to prevent dangerous sparks this is strongly discouraged. Never connect the battery pack in series or in parallel with any other type of battery pack. Do not use the battery as a starter battery.
-
Page 7: Transport Alert
CAREFUL! Using a charger that is not suitable for LiFePO4 chemicals can damage the battery because it is not properly charged. 2.3 Transport alert The Li-ion battery must be transported in its original packaging. Our battery has been tested according to the UN handbook for tests and criteria, part III, paragraph 38.3 (ST/SG/AC.10/11/Rev.5). -
Page 8: Description And Operation
DESCRIPTION AND OPERATION 3.1 Charging During charging, the LED lights red. At the end of the charging cycle the LED lights green. The battery capacity can be read by pressing the thickener in the foil. One, two or three green LEDs will light up as a rough indication of the charge status. -
Page 9: Imperium Lithium App
WARNING! Stop the charging process if the battery becomes too hot during charging (> 45 °C 50 °C). The battery can also be charged by solar panels if they are connected to a charger that is suitable for charging LiFePO4 batteries. The Imperium IMP004 40A DC-DC Charger, with built in MPPT, is ideal for this. - Page 10 Perfect, Normal, Bad indicator Battery Terminal capacity Ah voltage Back to search SOC means "State of Charge" or the state of charge of the battery. The voltage and capacity of the battery are listed below. STATUS" shows whether the battery is charging or discharging or whether the battery is in standby mode.
-
Page 11: Storage
3.3 Storage If you want to store the battery for a long period of time, disconnect the battery terminals. This will prevent the battery from being discharged by slumber consumption. Also disconnect the charging current connector from the battery. The battery has a very low self-discharge and can be stored for up to half a year without any problems. - Page 12 After unpacking, check all parts for possible damage. Fully charge the battery before first use. WARNING! Never use the LiFePO4 battery in locations with gas or dust explosion hazards or potentially flammable products. Mount the battery pack using the supplied mounting plate and Velcro fastener at the location of your choice in the camper.
- Page 13 CAREFUL! If bolts that are too long are used, the connections will be firm enough. This leads to large contact resistances and can cause the battery or equipment to spark or switch off. CAREFUL! Observe the polarity of the battery and avoid short circuits! Equipment whose polarity is incorrectly connected can be irreparably damaged Never connect the battery in parallel to any other type of battery, including...
-
Page 14: Decommissioning
After first use, check all connections for excessive heat. Repair or replace any connections that have over heated . Check the wiring and connections at least once a year. Immediately rectify defects such as loose connections and burnt cables. System overview: WARNING! Never connect the battery in parallel to any other type of battery, including the wiring from a car. -
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS 5.1 Technical data Model IMP001 Depth of Discharge 105 Ah 100 Ah Maximum Capacity 83 Ah 50 Ah Useable Cpacity 2000 Cycles ( of useable capacity) 141000 Ah 20000 Ah Effective lifetime capacity 11.8 kg 28.7 kg Battery weight 311.8 minutes 300.03 minutes Runtime @ 20A discharge... -
Page 16: Liability
Damage resulting from the use of the Imperium Lithium Battery; Use that is incompatible with the purpose of the product. EG DECLARATION OF CONFORMITY The IMP001 – Imperium Lithium Battery 105Ah LIFEPO4 conforms to IEC 62133-2:2017 and is complaint with AS/NZS 61000.6.3:2012. EG DECLARATION OF CONFORMITY OF ELECTRICAL EQUIPMENT... - Page 17 2014/30/EU DIRECTIVE 2014/30 / EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 26 February 2014 on the harmonization of the laws of the Member States concerning electromagnetic compatibility. 2011/65/EU DIRECTIVE 2011/65 / EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment...
- Page 18 EN60950 Information technology equipment - Safety - -1:2005+A1:2009+A2:2013 Part 1: General requirements and which the following natural or legal person established in the Community is authorized to compile the technical file: Name and position : Purple Line PTY LTD Address : 13-15 Indian Drive Keysborough VIC 3172 AUS Country : Australia...
- Page 19 WARRANTY YEARS WARRANTY PERIOD: Full 2 years warranty from date of purchase against all manufacturing defects. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: Any defect in design or manufacture which results in its failure to perform correctly as described.
- Page 20 Purple Line Pty Ltd 13 Indian Drive Keysborough VIC 3172 AUSTRALIA Web: www.purpleline.com.au Tel: 03 9588 2959 Email: enquiries@purpleline.com.au Cable Length/ Twin Core Photographs & diagrams for illustration purposes only. Actual product may differ slightly. All weights & dimensions are approximate. The manufacturer reserves the right to change product specification without prior notice. E & OE.
