Mindsensors EV3 Console User Manual

What is EV3Console

Connections

Serial Connection Parameters

USB Drivers for Windows

Using EV3Console on Linux

Copyright © 2016 mindsensors.com
EV3 Console is adapter is designed for use
with EV3 brick, to access the Operating
System (Linux) console through external
computer.
Connect the USB connector of the EV3Console to your computer
(Windows/Mac/Linux) using USB cable.
Connect the Gray connector to Sensor Port 1 of your EV3 brick using
Mindstorms sensor cable.
Baud rate: 115200.
Other parameters: 8 bit, No Parity, 1 stop bit.
Download driver from following URL
http://www.mindsensors.com/index.php?
controller=attachment&id_attachment=168
Installation instructions are here:
http://www.mindsensors.com/content/14-ev3console-usb-driver-
installation-instructions
The EV3Console USB drivers use FTDI chip for communication,
which uses FTDI serial drivers (these are commonly available in any
Linux).
To configure USB, we use FTDI chip with manufacturer ID as
0403, and Device ID as ABB9.
You will have to configure your installation's USB enumerations
based on these values. (Essentially, you will have to configure your
USB driver such that when it sees device with the ID's above, it
loads Serial drivers for it.)
EV3Console User Guide
1/2
