- Page 1 The Sound That Will Move You Earthquake Tactile Transducers Q10B MQB-1 Installation Manual www. earthquake sound.com...
- Page 2 ® Earthquake Tactile Transducers Basic Information By now, you may have some knowledge about Tactile Transducers. To help clarify this application further, please read on: What is a Tactile Transducer? A tactile transducer or "bass shaker" is a device which is made on the principle that low bass frequencies can be felt as well as heard.
- Page 3 Mounting Quake Tactile Transducers ® The Earthquake Q10B and MQB-1 need to be mounted vertically at all times. Mounting them vertically maximizes the output and increases the over all tactile experience.
- Page 4 ® Connecting Earthquake Tactile Transducers Tools/supplies that will be needed for installation: 16 to 12-gauge speaker cable a pair of pliers a powered screw driver measure tape two (2) wing nut wire connectors or electrical tape Connecting 1 MQB-1 to an XJ-300ST amplifier NOTE: Make sure the amplifier’s front toggle switch is set to “LOWPASS”...
- Page 5 Receiver/Processor - LFE/SUB OUT TRIGGER IN FUSE: T6.3AL/250V Connecting 1 Q10B to an XJ-300ST amplifier NOTE: Make sure the amplifier’s front toggle switch is set to “LOWPASS” prior to connecting the tactile transducers. Receiver/Processor - LFE/SUB OUT TRIGGER IN FUSE: T6.3AL/250V...
- Page 6 Mounting the MQB-1 to Seating Directly MQB-1 MQB-1 Mounting Bracket Strongest Joist / Brace in Sofa or Chair Mounting the Q10B to Seating Directly Q10B Q10B Mounting Bracket Strongest Joist / Brace in Sofa or Chair Specifications are subject to change without notice...
- Page 7 In addition, the rubber feet will provide a great suspension, allowing the Q10B to really shine. The optional Platform Mount Multiplier can be installed underneath or inside couches or chairs as in previous illustrations, but it is more effective when mounted directly to the platform.
- Page 8 ® Installing/Mounting Earthquake Tactile Transducers Mounting the MQB-1 to Gaming Chair Pre-built gaming chairs come in all different shapes and sizes. The illustration to the right is only a demonstration on how you may install a MQB-1 to this type of application.
- Page 9 ® Earthquake Tactile Transducers Specifications 3-1/16” Q10B 2-5/16” (77mm) (58mm) Frequency Response: 5 - 40 Hz Nominal Impedance: 8-Ohm Power Handling: 40 - 1000 Watts 5-1/8” 6-3/16” 3-15/16” (128mm) (158mm) (100mm) 3-3/4” (95mm) 3/16” (5mm) 3-9/16” 3-9/16” (90mm) 8-1/8” (90mm)
- Page 10 Customer will be charged a minimum of one (1) hour of labor (ongoing rates) plus shipping charges back to customer. (C) Earthquake agrees to repair or replace - at our option - all such defective products/parts subject to the following provisions: Defective products/parts have not been altered or repaired by other than ...
- Page 11 Subsequent damage to other products. A warranty claim will not be valid if the warranty registration card is not properly filled & returned to Earthquake with a copy of the sales receipt. (E) Service Request: To receive product(s) service, contact Earthquake Sound’s...
- Page 12 The Sound That Will Move You Earthquake Sound reserves the right to amend details of the specifications without notice. Copyright © Earthquake Sound Corporation Earthquake Sound Corporation • 2727 McCone Avenue Hayward CA, 94545 Phone: 510-732-1000 Fax: 510-732-1095...
