Operating instructions Commercial Dishwasher PFD 101 / PFD 101i / PFD 103 SCi en-AU, NZ It is essential to read these operating instructions before installing and using the appliance. This will prevent both personal injury and damage to the machine.
Caring for the environment ................19 Commissioning....................20 Basic settings ...................... 20 Setting the language ..................20 Setting up Miele@home ................. 20 Setting the time of day ................... 21 Setting the water hardness ................21 Miele@home ......................22 Opening the door ....................24 Close the door.....................
Contents Comparison tests ....................44 XXL height with cutlery tray................. 47 Detergent ......................50 Application ......................50 Detergent dispensing ..................51 Adding detergent....................52 Changing detergent..................... 54 Operation......................55 Switching on the dishwasher ................55 Selecting a programme ..................55 Display of programme duration ................
Contact in case of fault ..................90 Programme updates.................... 90 Warranty ......................90 Installation......................91 Electrical connection ................... 91 The Miele Waterproof system................92 Water intake ......................92 Connecting the drain hose .................. 94 Technical data....................95 Settings ......................96 Opening the Settings menu................. 96 Changing settings ....................
Notes about these instructions Warnings Information which is important for safety is highlighted in a thick framed box with a warning symbol. This alerts you to the potential danger of injury to people or damage to property. Read these warning notes carefully and observe the procedural instructions and codes of practice they describe.
Guide to the appliance Appliance overview a Top spray arm g Filter combination b 3D MultiFlex tray (depending on h Salt reservoir model) i Data plate c Upper basket (depending on model) j Rinse aid reservoir d Middle spray arm k Detergent compartment e Ventilation f Lower spray arm...
Guide to the appliance Control panel a Programme selection e Timer sensor For selecting a later programme = Short start. = Medium f OK sensor For selecting menu options and = Intensive values displayed. For confirming messages. ...
Guide to the appliance The OK sensor is used to confirm a Display functions message or setting and also to move to The display is used to select or set the the next menu or another level. following: Under Settings a scroll bar will - the programme appear in the right of the display.
Correct application This commercial dishwasher complies with all current local and national safety requirements. However, inappropriate use can lead to personal injury and damage to property. Read the operating instructions carefully before using the commercial dishwasher for the first time. They contain important information on the safety, use and maintenance of the machine.
This lamp must only be used for the purpose for which it is intended. The lamp is not suitable for room lighting. Replacement lamps may only be fitted by a qualified electrician or a Miele authorised technician. The lighting control element is integrated into the appliance controls and cannot be removed separately.
The appliance must only be operated with properly adjusted door springs. If the door cannot be adjusted properly, contact Miele. The maximum weight of the front panel that can be aligned with the factory fitted door springs is 10–12 kg (depending on model).
Miele Professional Service. Faulty components must only be replaced by genuine Miele original spare parts. Only when these parts are fitted can Miele guarantee the safety standards of the appliance. The electrical safety of this dishwasher can only be guaranteed when continuity is complete between it and an effective earthing system.
A damaged connection cable may only be replaced by a suitable connection cable of the same type. For safety reasons, such replacement may only be carried out by Miele Professional Service or a Miele authorised technician. ...
The manufacturer’s warranty will be invalidated if the dishwasher is not repaired by a Miele authorised service technician. In areas which may be subject to infestation by cockroaches or other vermin, pay particular attention to keeping the appliance and its surroundings in a clean condition at all times.
Warning and Safety instructions Correct use This dishwasher is designed for operation with water and cleaning agents suitable for use in commercial dishwashers only. Organic solvents and flammable liquid agents must not be used in it. This could cause an explosion, damage rubber or plastic components in the dishwasher and cause liquids to leak out of it.
(e.g. oxyhydrogen explosion). Miele cannot be held liable for any effect chemical cleaning agents may have on the material of the items being cleaned. Observe the cleaning agent manufacturer's instructions with regard to storage conditions, use and dosage.
Warning and Safety instructions Do not hose the dishwasher or near vicinity down to clean it, e.g. with a hose or a pressure washer. Be careful when sorting items with sharp pointed ends and positioning them in the dishwasher that you do not hurt yourself or create a danger for others.
Only use original Miele accessories. Using spare parts or accessories from other manufacturers will invalidate the warranty, and Miele cannot accept liability. Miele will guarantee to supply functional spare parts for a minimum of 10 years and up to 15 years following the discontinuation of your dishwasher. Transport ...
Caring for the environment Disposal of the packing Disposing of your old material appliance The transport and protective packaging Electrical and electronic appliances has been selected from materials which often contain valuable materials. They are environmentally friendly for also contain specific materials, disposal, and can normally be recycled.
Miele@home will appear in Switching on the dishwasher the display. Switch the dishwasher on using the To set up Miele@home now, confirm sensor. by touching OK. The welcome screen will appear when Useful tip: To postpone set-up until the dishwasher is switched on and the later, select the option ...
Commissioning Setting the time of day Setting the water hardness The display will change to the screen The time is updated automatically if a for setting the water hardness. connection is established to the Wi-Fi network. - The dishwasher needs to be programmed to the correct water The display will then change to the hardness for your area.
Dishwasher salt” and “Rinse aid”). Miele@mobile App Select OK to confirm the messages. - a Miele user account You can create a user account using the network When a programme is selected, it will solutions from Miele, .e.g via the appear briefly in the display and the Miele@mobile App.
Therefore, a constant Miele@mobile App availability of featured functions cannot be guaranteed. Miele@home availability The ability to use the Miele@mobile App, or other network solutions, depends on the availability of the Miele@home service in your country. The Miele@home service is not available in every country.
Commissioning At the end of the programme, if the Every dishwasher is tested at the AutoOpen function is on, the door factory. There will be residual water in locking pin automatically retract. the machine from this test. It is not an indication that the dishwasher has To prevent a technical fault, do not been used previously.
Commissioning Close the door Activating the safety lock Push the baskets right in. Use the safety lock to prevent children opening the dishwasher door. The door Raise the door upwards until the can then only be opened by using a lot catch engages.
Commissioning Reactivation salt Damage caused by using unsuitable salts. In order to achieve good cleaning results, the dishwasher needs to Some types of salt may contain insoluble components which can operate with soft water. Hard water results in the build-up of calcium cause the water softener to deposits on dishes and on the inner malfunction.
Commissioning Filling the salt reservoir Replenishing salt When Refill salt appears in the Before filling the salt reservoir for the display, wait until the end of the first time, you must fill it with approx. programme and then refill the salt 2 litres of water to enable the salt to reservoir.
Commissioning Rinse aid If you only ever use combination detergent products in your Rinse aid is necessary to ensure water dishwasher, you do not need to fill does not cling to and leave marks on the rinse aid reservoir. crockery during the drying phase, and it However, the best rinsing and drying helps crockery dry faster after it has results will be achieved by using a...
Commissioning Wipe up any spilled rinse aid. This Adding rinse aid prevents over-foaming occurring during the next programme. You can adjust the rinse aid dosage for best results (see "Settings - Rinse aid"). Refilling rinse aid When the Refill rinse aid message appears, the reservoir only contains...
- Make full use of the basket capacity You can find further tips on energy- without overloading the dishwasher. saving dishwashing in Miele’s guide to This results in the most economical dishwashing at www.miele.com. dishwashing in terms of energy and water consumption.
Caring for the environment 2. Displaying consumption EcoFeedback consumption display At the end of the programme, you can call up the actual water consumption The "Consumption" function is used for for the programme that has just been calling up information about the water run.
Loading the dishwasher - The spray arms must not be blocked General information by items that are too tall or hang Remove coarse food residues from through the baskets. Test for free crockery. movement by manually rotating the spray arms. There is no need to pre-rinse items under running water.
Loading the dishwasher Items not suitable for washing in the Damage due to caustic alkaline dishwasher: detergents. - Wooden cutlery and crockery or Aluminium parts (e.g. the grease items with wooden parts. These may filters of rangehoods) can be discolour and fade.
Loading the dishwasher Loading the FlexCare cup rack Upper basket You can put cups, small bowls, and flat See “Loading the dishwasher - dishes on the FlexCare cup rack. Loading examples” for examples of Glasses can be arranged along the cup how to load crockery and cutlery.
Loading the dishwasher Adjusting the FlexCare cup rack Loading the silicone elements of the FlexCare cup rack You can set the height and depth of the cup rack at 2 different levels so that it The silicone elements on the cup rack can accommodate larger cups and so are specially designed to hold tall that taller items can be placed...
Loading the dishwasher Lowering the spikes You can fold down every second spike in the two right-hand rows of spikes to make it easier to arrange larger pieces of crockery, e.g. cereal bowls. Press the yellow lever downwards and then lower the dark gray spikes .
Loading the dishwasher To raise the upper basket: Adjusting the upper basket Lift the basket up until it clicks into In order to gain more space for taller place. items, the upper basket can be adjusted on three levels with 2 cm To lower the upper basket: between each level.
Loading the dishwasher Lowering the spikes Lower basket The rows of spikes at the front are used See “Loading the dishwasher - for washing plates, soup bowls, Loading examples” for examples of platters, dessert bowls and saucers. how to load crockery and cutlery. Both rows of spikes can be lowered to Loading the lower basket make more room for large items such...
Loading the dishwasher Loading the FlexCare glass holders The MultiClips allow you to fasten light with MultiClips items such as plastic parts onto the glass holder. The silicone elements in the glass holders provide a stable and secure hold for delicate stemware. ...
Loading the dishwasher Loading the glassware rail Lowering the bottle holder This rail is designed to hold glasses The bottle holder can be used to keep with long stems securely. narrow items such as milk bottles and baby bottles secure during a programme.
Loading the dishwasher You can push the left insert to the Cutlery tray middle in order to accommodate tall See “Loading the dishwasher - items of crockery and long stemmed Loading examples” for examples of glasses in the upper basket (see “Upper how to load crockery and cutlery.
Comparison tests Test standard: AS/NZS 2007.1, AS/NZS 2007.2; AS/NZS 6400 Standard programme (for energy label): 14 place settings Capacity: Detergent amount: 32.5 g Rinse aid dosage: Setting 3 You can find information on adjusting the rinse aid dosage in the "Rinse aid" section of this booklet.
Comparison tests XXL height with cutlery tray Test standard: AS/NZS 2007.1, AS/NZS 2007.2; AS/NZS 6400 Standard programme for energy label comparison tests: 15 place settings Capacity: Detergent quantity: 33.7 g in compartment II Rinse aid dispensing: Setting 3 You can find information on adjusting the rinse aid dosage in the “Rinse aid” section of this booklet.
Avoid contact with detergents. detergents for commercial use in your Do not inhale powder detergent. Do dishwasher can be ordered on the Miele not swallow dishwasher detergent. website: Seek medical attention immediately if https://www.miele.com.au/professional/ detergent has been swallowed or accessories-dishwashers-441.htm...
Suitable tabs are available from the They also indicate the approximate fill Miele detergent range. If you are level in grams for powder cleaning using combination detergents (tabs agents, depending on the manufacturer which contain not only a cleaning and the coarseness.
Detergent Adding detergent The detergent must not cause the detergent compartment lid to get stuck. This can prevent the lid from opening during the programme sequence. Do not overfill the detergent compartment. Ensure that the detergent packaging is properly closed after use. This prevents the detergent from getting damp and clumping together.
Observe the colour coding. pump and set the cleaning agent dosage. For special soiling or if using liquid detergent dispensed by a liquid detergent pump, contact Miele for advice on how to adapt the detergent dosage to the particular circumstances. Refilling or changing...
Detergent Changing detergent If you want to change the cleaning agent, the dispensing system must first be rinsed with water in order to avoid a reaction due to the mixing of cleaning agents. Remove the suction lance from the container and place it in a container of water.
Operation Switching on the dishwasher Selecting a programme Make sure the spray arms can rotate Choose your programme according to freely. the type of crockery and the degree of soiling. Close the door. The different programmes and their ...
Operation Display of programme duration Starting a programme Touch the Start sensor. The estimated duration of the selected programme appears in the display Confirm the previously displayed before the programme starts. During message with OK. the programme, the time left until the The programme will start.
Operation At the end of the programme Energy management The signal tones may sound at the end To save energy, the dishwasher will of the programme. switch off automatically 10 minutes after the last time a sensor is pressed or The programme has finished when the after the end of a programme.
Operation Switching off the dishwasher Unloading the dishwasher The dishwasher can be switched off Dishes tend to break and chip more at any time using the sensor. easily when they are hot. Allow the dishes to cool until they are comfortable An ongoing timer can also be cancelled enough to handle before unloading by switching off the machine.
Operation Interrupting a programme Cancelling or changing a programme A programme will be interrupted as soon as the door is opened. If a programme is cancelled, important programme stages may be When you close the door again, the missed. query Continue with Start appears in the display.
Programme options Time left indicator Options The time left indicator option is Options can be selected and selected as standard and displays the deselected using the appropriate time remaining until the end of the buttons and the display before starting programme. the programme.
To switch the display back on for a few minutes, press the sensor. You can also activate the timer via the Miele@mobile App.
Programme options Setting “Start at” Setting “Finish at” With the Start at function, you set the Use the Finish at function to set the exact time at which you want the latest time by which the selected programme to start. programme has to be finished.
Use the sensors to enter the SmartStart (see “Settings - hour and confirm your entry with OK. Miele@home”). The hour will be saved and the minute If your energy provider offers this number block will be highlighted. service, they will send a signal to your ...
sensor will go out and switch the dishwasher off. the Start sensor will light up. Switching the dishwasher off while a timer is running stops the timer. You can also change the time set for the timer or delete it using the Miele@mobile App.
Programme chart Programme Application Detergent The following dosages are based on Miele detergents. Please follow the manufacturer's instructions. Detergent compartment For fresh, non-sticky food residues. 20–25 g Short or 1 tab For moderately dried-on food residues. 20–25 g Medium or 1 tab ...
Programme chart Programme sequence Pre-wash Main wash Interim rinse Final rinse Drying AutoOpen 60-65 °C 65 °C 40 s 20 min 1 min 30 s 65 °C 65 °C 6 min 3 min 30 min 2 min 75 °C 65 °C 6 min 6 min 3 min 30 min 2 min 50 °C 60 °C 6 min 1 min 5 min 1 min 30 min 50 °C 50 °C 1 min...
Programme chart Programme Consumption Duration Electrical energy Water Cold water Hot water Cold water Hot water 15 °C 55 °C 15 °C 55 °C 2.1 kW 7.3 kW 2.1 kW 7.3 kW 2.1 kW 7.3 kW 2.1 kW 7.3 kW 2.1 kW 7.3 kW Short 1.4 kWh 0.9 kWh 14.7 l 53 min 22 min 36 min 17 min ...
Programme chart Programme Consumption Duration Electricity Water Cold water Hot water Cold water Hot water 15 °C 55 °C 15 °C 55 °C 3.2 kW 5.1 kW 3.2 kW 5.1 kW 3.2 kW 5.1 kW 3.2 kW 5.1 kW 3.2 kW 5.1 kW Short 1.4 kWh 0.9 kWh 14.7 l 39 min 28 min 28 min...
Programme chart Consumption data in ECO programme Programme Consumption Duration (Programme time) Electrical energy Water Cold water Hot water (20 °C) Cold water Hot water 20 °C 60 °C 20 °C 60 °C 0.6 kWh 0.9 kWh 13.1 l 178 min 171 min 14 standard place settings ...
- Spray arms dishwasher cleaner (available from - Filter combination Miele directly or the Miele webshop). Follow the instructions on the product - Sump including drain pump and non- packaging. return valve ...
Cleaning and care Cleaning the spray arms Particles of food can get stuck in the spray arm jets and bearings. The spray arms should therefore be inspected regularly (approx. every 2–4 months). Damage due to soiling entering the circulation system. Without filters, soiling can enter the circulation system and cause a blockage.
Cleaning and care Cleaning the spray arms Refitting the spray arms Refit the upper and middle spray arms. Refit the lower spray arm and ensure that the filter combination lies flat in the base of the wash cabinet. ...
Cleaning and care Checking the filters in the Cleaning the filters wash cabinet Switch the dishwasher off. The filter combination in the base of the Remove the lower spray arm (see wash cabinet retains coarse soiling “Cleaning and care - Cleaning the from the suds solution.
Cleaning and care In order to clean the inside of the Rotate the screw thread clockwise filter, pull the microfilter by the plastic until the arrow in the viewing window ring downwards and away from the points to the lock symbol . filter combination.
Cleaning and care Cleaning the water inlet filter A filter is incorporated in the screw thread to protect the water inlet valve. If the filter is soiled, insufficient water flows into the wash cabinet. Risk of electric shock. The plastic housing of the water connection contains an electrical valve.
Cleaning and care Cleaning the drain pump If water remains in the wash cabinet after the end of a programme, the water has not been pumped away. The drain pump may be blocked by foreign objects. These foreign objects are easy to remove.
Cleaning and care Damage caused by incorrect cleaning. The components are delicate and can be damaged during cleaning. Take care when cleaning the drain pump. The drain pump (see arrow) is underneath the cover. Risk of injury from glass splinters.
With the help of the following guide, minor faults in the performance of the appliance, some of which may result from incorrect operation, can be remedied without contacting Miele. This will save you time and money because you will not need a service call.
Restart the desired programme. If the fault message appears again, there is a technical fault. Switch the dishwasher off. Turn off the tap. Call Miele. The Waterproof system has reacted. Waterproof Switch the dishwasher off.
Open the door manually (see “Using for the first time – Opening the door”) and switch the dishwasher back on. If the same fault message appears again, call Miele. The door locking pin does not retract after the door is opened. There may be a technical fault.
Problem solving guide Water drainage fault Problem Possible cause and remedy The warning buzzer is Before rectifying the problem, you must: sounding. Switch the dishwasher off. The message Water drainage fault. appears in the Drain There might be water in the wash cabinet. display.
Switch the lighting back on (see “Settings - opened. BrilliantLight”). The wash cabinet lighting is faulty. Call Miele. Detergent residue is left The detergent compartment was still damp when in the detergent detergent was added.
Problem solving guide Noises Problem Possible cause and remedy Knocking noise in the A spray arm is knocking against a crockery piece. wash cabinet. Carefully open the door and rearrange the wash items that are obstructing the spray arm. Rattling noise in the Items of crockery are not secure in the wash cabinet.
Problem solving guide Unsatisfactory washing result Problem Possible cause and remedy The crockery is not The items were not loaded correctly. clean. See notes under “Loading the dishwasher”. The programme was not thorough enough. Select a more intensive programme (see “Programme chart”).
Problem solving guide Problem Possible cause and remedy Dishes are not dry or The rinse aid dosage is set too low or the rinse aid cutlery and glasses are reservoir is empty. blotchy. Replenish the rinse aid, increase the dosage, or change the brand of rinse aid (see “Using for the first time - Rinse aid”).
Problem solving guide Problem Possible cause and remedy White residue is visible Not enough rinse aid was added. on the crockery. Increase the dosage (see “Settings – Rinse aid”). Clouding has occurred The salt reservoir is empty. on glassware and ...
The programme update function is Miele. designed to enable a service technician to update your dishwasher's electronics You can book a Miele customer in keeping with advances in technology. service call-out online at Programme updates can only be www.miele.com/service.
The Miele Waterproof system the connection point) must be As long as your dishwasher has been between 50 and 1000 kPa (0.5 and installed correctly, the Miele Waterproof 10 bar). anti-leak system will protect you from If the water pressure is lower than water damage throughout its lifetime.
*INSTALLATION* Installation To avoid any damage to the machine, the dishwasher must only be connected to a fully vented plumbing system. The inlet hose must not be shortened or damaged in any way as it contains electrical components (see illustration).
*INSTALLATION* Installation Hose positioning with a low water Connecting the drain hose drainage height - The machine drainage system is If the on-site drainage connection is fitted with a non-return valve, which situated lower than the guide path for prevents dirty water from flowing the lower basket rollers in the open back into the dishwasher via the door, the water drain hose must be...
Technical data Dishwasher Normal Model PFD 101, PFD 101i PFD 103 SCi Height of freestanding appliance 845 mm (adjustable + 35 mm) Height of built-in appliance 805 mm 845 mm (adjustable + 65 mm) (adjustable + 65 mm) Niche height from 805 mm from 845 mm (adjustable + 65 mm) (adjustable + 65 mm)
Settings Changing settings You can alter the dishwasher’s controls to suit changing requirements Use the sensors to select the by adjusting the settings. menu option you want to change and confirm your selection with OK. Settings can be altered at any time. Submenu options that have already Opening the Settings menu been selected will have a tick ...
Settings Language Time of day The display can be set to appear in one The current time of day must be set of several different languages. before you can use the timer option. You can change the language used in Setting the clock format the display and also the country via the You can select either a 24-hour or 12-...
Settings Water hardness °d mmol/l °f Display Your dishwasher is fitted with a water softener. - The dishwasher needs to be programmed to the correct water hardness for your area. - Your local water authority will be able to advise you of the water hardness level in your area.
Settings Rinse aid External dispensing You can adjust the rinse aid dosage for Activate automatic dispensing of liquid best results. detergent if you have installed the The rinse aid dosage can be set from 0 optional external dispensing module. to 6 ml. The DOS module is supplied with its 3 ml is the factory default setting.
Settings Start the "Cold pre-wash" DOS flow rate programme directly after venting in A flow rate of 60 ml/min is set as order to dilute and drain any cleaning standard. The flow rate can be modified agent that has escaped into the wash between 10 and 150 ml/min in cabinet.
Wi-Fi network via WPS (Wi-Fi dishwasher is switched off. Protected Setup). Additional menu options will be added Your Wi-Fi router must support WPS. to the “Settings“ and “Miele@home” menus. Confirm the message Press WPS button with OK.
- Call up information on the programme sequence of your Miele@mobile App dishwasher - Set up a Miele@home network with other Wi-Fi enabled Miele appliances Activate If you wish to connect your dishwasher to your Wi-Fi network, you can switch ...
Follow the instructions in the display. Even if the Remote control option is switched off, you can use the Miele@mobile App to call up information about your appliance. However, you cannot start any programmes or change any settings from it.
Otherwise, the update will be aborted and will not be Deactivate RemoteUpdate if you do not installed. want any updates to be downloaded automatically. - Some software updates can only be carried out by a Miele service technician.
EcoStart option to take advantage of dishwasher to your Wi-Fi network (see your electricity supplier’s cheaper “Settings - Miele@home”). energy tariffs (see “Options - Timer”). function (only functional SmartStart With this option selected, your...
Settings Setting the electricity rate times Changing the electricity tariff times Before you can use the EcoStart option, You can change the start, finish, or you must set at least one electricity priority of an electricity tariff time. tariff time. ...
Settings Deleting the electricity tariff times Consumption (EcoFeedback) You can delete the settings for an You can set whether the energy and energy tariff time and in doing so water consumption is displayed for the deactivate the EcoStart option for this selected programme.
Settings Display brightness Volume You can set the display brightness to A sequence of warning tones will sound one of seven different levels. at the end of the programme or if there is a fault, provided that the signal tones are activated.
If you only ever use combination In some programmes the door detergent products or automatic automatically opens slightly to assist dispensing using Miele PowerDisks (if the drying process. available), you can switch off the refill This function can be deactivated if you reminders for reactivation salt and rinse wish.
The settings of the Wi-Fi module (where switches off automatically after applicable) have to be reset separately 15 minutes. (see "Settings – Miele@home – Reset"). You can also switch off the wash Appliance settings cabinet interior lighting permanently. You can use this menu option to reset...
