USER GUI DE
RX720
MULTI-FREQUENCY, MULTI-CONSTELLATION, GNSS SMART ANTENNA
Thank you for choosing TeeJet Technologies' RX720 as your GNSS receiver solution. This document provides instructions for mounting and operation of
the RX720. Contact a local dealer for more information or visit www.teejet.com.
RX720 GNSS receiver delivers the latest in positioning technology for agricultural applications. This state-of-the-art smart antenna receives multiple GNSS
signals to deliver better satellite availability under challenging terrain and environmental conditions.
Accuracy, Stability and Reliability
The RX720 can deliver the positioning accuracy needed for your precision farming applications. This flexible receiver can be configured to deliver
basic performance using free correction signals, and can also be upgraded to use subscription-based satellite corrections or RTK for more demanding
applications. TerraStar services provide 19.7 in / 50 cm (TerraStar-L) or 1.2 in / 3 cm (TerraStar-C PRO) level accuracy (95%) using globally transmitted
satellite correction signals. ClearPath technology is integrated into the receiver and provides smooth positions and excellent pass-to-pass accuracy that
are ideal for agricultural guidance and steering applications.
Multi-Signal, Multi-Frequency, Totally Flexible
A high-quality internal antenna element combined with the ability to track 555 channels make the RX720 extremely flexible. This receiver can receive
GPS, GLONASS, BeiDou, Galileo and QZSS, along with TerraStar correction signals. This results in high numbers of satellite signals and a wide range of
configurations that can deliver the accuracy your application needs – from subscription free SBAS (WAAS, EGNOS, MSAS, GAGAN) corrections through
TerraStar-L and TerraStar-C PRO, and even centimeter-level RTK accuracy.
F E AT U R E S & B E N E F I T S
• Supports GPS, GLONASS, BeiDou, Galileo and QZSS
• Available centimeter-level accuracy with RTK or 1.2 in / 3 cm accuracy
(95%) with satellite-delivered TerraStar-C PRO
• A durable, waterproof housing that meets MIL-STD-810G environmental
standards for years of reliable use in the field
• Magnetic and screw mounting options
• For use with TeeJet and third-party guidance and steering systems
• Capable of operating on supplies of +7 to +30 VDC with low 4 W power
consumption *
C O R R E C T I O N O P T I O N S
• Capable of operating with free SBAS corrections
• Compatible with TerraStar-L correction service for 5.9 in / 15 cm (95%) pass-to-pass accuracy
• Compatible with TerraStar-C PRO corrections for repeatable 1.2 in / 3 cm (95%) accuracy, which means <0.8 in / 2 cm pass-to-pass accuracy
• TerraStar subscriptions offered in 3 month, 1, 2 or 3 year subscriptions
• RTK compatible with either conventional radio link or network-delivered NTRIP solutions
RX720 Kits and Components
Kit/Part Number
90-02942
90-02943
90-02944
90-02945
90-02946
65-05243
45-05957
Description
Kit, GNSS Receiver, RX720, Dual Frequency, TerraStar-L ready, ClearPath, no-SBAS
Kit, GNSS Receiver, RX720, Dual Frequency, TerraStar-L ready, ClearPath, SBAS
Kit, GNSS Receiver, RX720, Dual Frequency, TerraStar-L & TerraStar-C PRO ready, ClearPath, SBAS
Kit, GNSS Receiver, RX720, Dual Frequency, TerraStar-L & TerraStar-C PRO ready, ClearPath, no-SBAS
Kit, GNSS Receiver, RX720, Dual Frequency, TerraStar-L & TerraStar-C PRO ready, RTK, ClearPath, SBAS
Mounting bracket for RX520 and RX720
Cable, RX520 and RX720 to Power & Serial Com 1
