R182J, R482J, R845A, R847A, R882J,
RA89A, RA832A Switching Relays
R A 89 A 11 6
M38612
APPLICATION
These relays provide intermediate or heavy duty service in a
wide variety of switching configurations.
FEATURES
• Relays with 24V control coils: Rl82J, R882J, R847A,
RA89A, RA832A, and R845A.
• Relays with line voltage control coils: R482J.
• Relays with internal 24V transformer: R182J, RA89A,
RA832A, R845A, and R847A.
• Relays for use with an external 24V supply: R882J.
• Heavy duty relays: R847J.
• R847A has flexible internal leads to provide either spst or
spdt switching.
• RA832A has contacts for low voltage and millivoltage
(Powerpile®) use.
M38610
PRODUCT DATA
60-2481-03

Advertisement

loading
Need help?

Need help?

Do you have a question about the R182J and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for resideo R182J

  • Page 1 RA89A, RA832A, and R845A. • Relays with line voltage control coils: R482J. R A 89 A 11 6 • Relays with internal 24V transformer: R182J, RA89A, RA832A, R845A, and R847A. • Relays for use with an external 24V supply: R882J.
  • Page 2: Specifications

    R182J, R482J, R845A, R847A, R882J, RA89A, RA832A SWITCHING RELAYS SPECIFICATIONS IMPORTANT: The specifications given in this publication do not include normal manufacturing tolerances. There- fore, this unit may not exactly match the listed spec- ifications Also, this product is tested and calibrated...
  • Page 3: Installation

    R182J, R482J, R845A, R847A, R882J, RA89A, RA832A SWITCHING RELAYS Mounting For replacement, mount the relay in the same location as the 4- (108) (29) old control. If this is a new installation, locate the relay vertically on a solid wall or partition as near as possible to the device to be controlled.
  • Page 4 R182J, R482J, R845A, R847A, R882J, RA89A, RA832A SWITCHING RELAYS THREE-WIRE Table 3. Wire Length Specifications THREE-WIRE TWO-WIRE LOW VOLTAGE LOW VOLTAGE LOW VOLTAGE (SERIES 10) (SERIES 20) (SERIES 80) Length of Run to THERMOSTAT THERMOSTAT THERMOSTAT Total Wire Thermostat AWG Wire...
  • Page 5 R182J, R482J, R845A, R847A, R882J, RA89A, RA832A SWITCHING RELAYS HYDRONIC HEATING LOW VOLTAGE (CLASS 2) TO ADDITIONAL R845A CONTROL TERMINALS RELAYS FOR OTHER ZONES 2-WIRE THERMOSTAT R847A RA845A RELAY THERMOSTAT THERM. ZONE 1 THERMOSTAT ZONE 2 BURNER BURNER CONTROL CIRCULATOR CIRC.
  • Page 6: Service And Checkout

    R182J, R482J, R845A, R847A, R882J, RA89A, RA832A SWITCHING RELAYS SERVICE AND CHECKOUT 1. Never use oil on any part of the relay coil or contacts. 2. Keep the cover on the relay during normal operation and remove only for service and checkout.
  • Page 7 R182J, R482J, R845A, R847A, R882J, RA89A, RA832A SWITCHING RELAYS 60-2481—03...
  • Page 8 Resideo Technologies, Inc. 1985 Douglas Drive North, Golden Valley, MN 55422 1-800-468-1502 60-2481—03 M.S. Rev. 04-21 | Printed in United States www.resideo.com © 2021 Resideo Technologies, Inc. All rights reserved. This product is manufactured by Resideo Technologies, Inc. and its affiliates.
