electLine

Economy functional & digital audio access systems

Audio 8 & 16

Functional & Digital

Installation Manual

Select Manufacturing Limited

Unit H1 - The Seedbed Centre - Wyncolls Road - Severalls Business Park - Colchester - Essex CO4 9HT

Telephone +44(0)1206 855800 - Facsimile +44(0)1206 855801

E-mail sales@selectman.co.uk - http:/www.selectman.co.uk

Digital Video

07/06/2002

Revision 1.08 Date: 05/12/2011

Table of Contents

Need help?

Do you have a question about the Audio 8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Select Audio 8

Page 1 Economy functional & digital audio access systems Audio 8 & 16 Functional & Digital Installation Manual Select Manufacturing Limited Unit H1 - The Seedbed Centre - Wyncolls Road - Severalls Business Park - Colchester - Essex CO4 9HT Telephone +44(0)1206 855800 - Facsimile +44(0)1206 855801 E-mail sales@selectman.co.uk - http:/www.selectman.co.uk...
Page 2: Table Of Contents
Digital Audio Installation Manual Page Contents DIGITAL SYSTEM: Single Entrance With PAC Single Entrance With PAC and Landing Control 8 & 16 way Main & Riser Controller Overview 5-5A System Wiring Overview Digital Network & Power Overview Digital & Landing Entrance Panel Digital Entrance Panel wiring detail Digital System Flat Programming Form Digital Entrance Panel Programming Instructions...
Page 3 Digital Audio Installation Manual Digital Audio Systems - 2 - Digital Audio Revision 1.09 Date: 05/12/2011...
Page 4 Digital Audio Installation Manual Digital System Basic Overview Strobe/Sounder Telephone Handset A+D+H Cable Requirements A -Single Earth 2.5mm Mains Type Cable (Continuity) B - 2 Wire (1 Pair) 1mm Mains Type Cable (Lock Release) PANEL 1 C - 2 Wire (1 Pair) CW1308 0.5mm dia Multipair Cable (Minimum) D - 8 Wire (4 Pair) CW1308 0.5mm dia Multipair Cable (Minimum)
Page 5 Digital Audio Installation Manual Digital System with Landing Controller Overview Strobe/Sounder Telephone Handset A+D+H Cable Requirements A -Single Earth 2.5mm Mains Type Cable (Continuity) PANEL 1 B - 2 Wire (1 Pair) 1mm Mains Type Cable (Lock Release) C - 2 Wire (1 Pair) CW1308 0.5mm dia Multipair Cable (Minimum) RTE T D - 8 Wire (4 Pair)
Page 6 Digital Audio Installation Manual Digital 50VAC Main Power Supply Overview 50VAC Rail to a Controller 5Amp Fuse Fused Spur 230VAC to 50VAC Supply - 4A - Digital Audio Revision 1.09 Date: 05/12/2011...
Page 7 Digital Audio Installation Manual 16 way Main, Riser and Landing Controller Overview PANEL 1 Entrance Panel 1 Amplifier Entrance Panel 1 Button Common Entrance Panel 1 Busy & Enter Display Flat Called Indicator Entrance Panel 1 Lock Supply + Input (12V-24VAC/DC Buttons Telephone Door open Tone ON/OFF Default OFF 12V DC Lock Release...
Page 8 Lock Release Tone and Door Open Tone Adjustment Door Open Indicator Panel Amplifier Active PANEL 1 Entrance Panel 1 Amplifier Entrance Panel 1 Button Common Entrance Panel 1 Busy & Enter Display Sub Entrance Panel 1 Buttons Flat Called Indicator Doors Lock Supply + Input (12V-24VAC/DC Telephone Door Release Tone ON/OFF Default OFF...
Page 9 Digital Audio Installation Manual 8 way Main, Riser and Landing Controller Overview 8 Flat Inputs Optional Earpiece Tone CALL on Lock Release Entrance Panel Buttons PAC+ 12VDC 2 second FAILSAFE PAC Input PAC- Trades Button Soft Reset Button Entrance Panel Amplifier Entrance Panel Button Common Door Open Indicator Display &...
Page 10: Digital Network & Power Overview
Digital Audio Installation Manual Digital Network & Power Overview Next Riser Controller PAC2+ PAC2 - Fuse 3.15A MFL+ Anti surge MFL- Digital Interface Board 50VAC Supply Indicator BUSY Display FLAT CALLED TALK NOW ENTER Main Controller Pre-wired To Panel Amplifier Note: Pre-wired for 12VDC Lock Output.
Page 11: Digital & Landing Entrance Panel
Digital Audio Installation Manual Landing Entrance Panel wiring detail BUSY FLAT CALLED TALK NOW ENTER PANEL 1 Brown of White White of Brown Slate of White Note: White of Slate See page 15 for Red of Orange wiring detail Orange of Red Green of Red Red of Green Brown of Red...
Page 12 Digital Audio Installation Manual Concierge Building Interface Card (Multi-Building) wiring detail Main Controller Fuse 3.15A Digital Entrance Panel Anti surge BUSY CONCIERGE Controller 2 CALLED TALK NOW Interface ENTER Card Pre-wired To Panel Amplifier 50VAC Supply Indicator CAM2 (Lobby) CAM1(Panel) Vout Board Healthy Indicator...
Page 13: Digital System Flat Programming Form
Digital Audio Installation Manual Digital System Flat Programming Form FUNCTION SWITCH FUNCTION SWITCH FUNCTION SWITCH FUNCTION SWITCH FUNCTION SWITCH 3 4 5 6 7 8 3 4 5 6 7 8 3 4 5 6 7 8 3 4 5 6 7 8 3 4 5 6 7 8 DATA SWITCH DATA SWITCH...
Page 14: Digital Entrance Panel Programming Instructions
Digital Audio Installation Manual Digital Entrance Panel Programming Instructions System Function Programming Function Description Parameters Notes Lock Release Time 1 - 255 Seconds Door Open Duration Time 1 - 255 Minutes Door Alarm Delay Time Zero minutes will disable the Door Alarm 1 - 255 Minutes Service Access Code (AC) Code + Trades to release door...
Page 15 Digital Audio Installation Manual Digital Entrance Panel Programming Instructions cont... System Function Programming cont... Function 8 (Setting Digital Panel Number(s)) Press 8 on the Digital Panel keypad and then press the PROG button. Enter from 1 to a maximum of 8 depending on the position of the Digital Panel in the system and press CALL.
Page 16 Digital Audio Installation Manual Digital Entrance Panel Programming Instructions cont... Main and Riser/Landing Controllers Program the Main and Riser/Controllers to the Functional System installation manual. Set all Controllers to their specified Riser/Landing positions for a Digital System. (See Controllers and Flat Location form). Digital Entrance Panel Programming An existing or previously used Digital Panel at switch on having pressed the PROG button should read 01.01 and will then alternate between 01.01 and a clear display or the previously...
Page 17: Digital System Summary
CAM1-2 SCN Camera 1-2 Video Signal Input CAM1-2 SIG Interface Board 50VAC Input 50VAC Input 50VAC Output 50VAC Output Data Select Input Data Select Output Data Input Data Output Microphone Input Microphone Output Speaker Input Speaker Output 0 Volt Input...
Page 18: Digital System Wiring Colour Codes
Speech Input White of Blue Microphone Input White of Brown Data Output Brown of White Data Select Orange of White 0V Common Line Main Controller Interface to Riser/Landing Controller Interface Riser/Landing Controller Interface Main Controller Interface 2.5mm Mains Type Cable 50VAC System Power Input/Output 2.5 Mains Type Cable...
Page 19: Panel Amplifier
Digital Audio Installation Manual AT-PID Telephone Privacy, Privacy On Indicator and Landing Panel Amplifier wiring detail Door Monitoring Indicator wiring detail Panel Amplifier PANEL 1 Blue of White White of Blue Blue and Red Pair White of Orange and Orange of White Blue of White White of Blue White of Orange and Orange of White...
Page 20: 12Vdc Auxiliary Output (Max 1Amp Output)
Digital Audio Installation Manual For Fail Secure (SE) Lock Releases. For Fail Safe (SA) Lock Releases. For Landing Panels only Emergency Override PANEL 1 Switch Emergency Override Switch Green of White RTE/T White of Green Common RTE/T Common Normally Open Normally Open System...
Page 21: Dc Fail Secure Lock Release
Digital Audio Installation Manual DC Fail Secure Lock Release wiring detail 1N4007 PANEL 1 Diode + LS - RTE/T To Fire Switch N/O Contact RTE/T Green of White White of Green System Controller Door Monitoring Contact Fail Secure Lock Release DC ( If Specified ) DC Fail Safe Lock Release wiring detail System Controller...
Page 22 Digital Audio Installation Manual Proximity Access wiring detail Proximity Access wiring detail KMS SIMPLEKEY 12VDC INPUT From DC IN RTE2 Select Controller 12VDC Auxilliary Terminals 14.6V Use the KMS 5Amp Power Supply Battery READER GND2 DOOR 1 RTE1 Both Door ReleaseTimes...
Page 23 Digital Audio Installation Manual Proximity Access wiring detail Both Door Times Must programed to 2 seconds Fail Safe 2 second PAC Easikey 250 Lock Output Fail Safe even if only one CAM2 (Lobby) CAM1(Panel) Reader1 Lock2 Reader2 Power Lock1 reader is being used. Vout L1 L2 L3 L4...
Page 24 Digital Audio Installation Manual System Controller Summary Connection Detail Controller Controller Telephone Handset Trades Clock Speaker/Electronic Call Secondary Trades Clock Microphone Secondary Trades Clock Note: N/O Clean Contacts Common Lock Release Privacy Switch Auxiliary Supplies Privacy On Indicator 3 x 0V Output Door Monitoring Indicator 3 x 12VDC Output Note: 3 Amp Overall Output...
Page 25: Controller Programming Instructions
(See Controller function Programming for set up and manufactures default settings). Note: If a Controller has already been set with an address this will be deleted. Select the line number to program using the FUNCTION switches 1 - 5, note that position 6, Controller Programming Instruction).
Page 26 60 Minutes 0 0 0 70 Minutes Note: 1 0 0 2 Hours 1) Select the combination that adds up to the 0 1 0 4 Hours required time period (Max 255 Seconds/Minutes) 1 1 0 6 Hours or Controller Address Number (Max 99).
Page 27 60 Minutes 70 Minutes 2 Hours Note: 4 Hours 1) Select the combination that adds up to the 6 Hours required time period.(Maximum 255 Min/Seconds). 8 Hours 10 Hours 2) All sw itches not required m ust be in the 12 Hours OFF position.
Page 28 Digital Audio Installation Manual Digital Trades Clock Operating Instructions Change Button Programme Button Sets Hours, Minutes Used to select the clock time and the 4 and Trade Times On/Off programmed times and to review them once set Output Status Showing Trades...
Page 29 Display shows:- GMT/BST TIME SWITCH TIME ? 17:12:56 Programming Instructions Select Manufacturing Limited Using the Green and Grey buttons as previously set the Unit H1 display to the correct time (24 hour clock). The Seedbed Centre Note:- The time entered is always normal ‘clock’ time i.e.
Page 30: System Wiring Colour Codes
Digital Audio Installation Manual System Wiring Colour Codes cont... System Wiring Colour Codes Controllers to Controllers to Telephone Handset Functional and Landing Entrance Panels Controller Controller Entrance Panel Telephone Blue of White Brown of White Button White of Blue White of Brown Button White of Orange and Orange of White Slate of White...
Page 31 Digital Audio Installation Manual System Wiring Colour Codes cont... Controller to Lock Release (AC/DC) Lock Release (Fail Safe DC) Controller Lock Release Connection 1mm Twin Mains Type Cable Lock Release Connection Controller Lock Release (Fail Secure DC) Lock Release Connection 1mm Twin Mains Type Cable Lock Release Connection Controller...
Page 32: Power Specification
Digital Audio Installation Manual Power Specification Power Input System Controller 230VAC Main Controller/Local Power Supply 230VAC Riser/Landing Controller 50VAC Working Voltage 12VAC Amplifier 6-12VDC Controller Outputs Lock Release (Fail Secure) 12VDC (Normally Open)(Rated 1Amp) Lock Release (Fail Safe) 12VDC (Normally Closed)(Rated 1amp) Auxiliary Supply 3 x 12VDC (Rated 3Amp overall) Battery Back Up:...
Page 33 Digital Audio Installation Manual User telephone Instruction Leaflet. Type AT-PID Door Release Once the Visitor has called you have the following options and indicators available to you: Replace The Handset You can replace the Handset without releasing the door. To Release the Door Press the Door Release button: this will cause the RED Door Open indicator to flash to confirm the door is being released for your visitor.
Page 34 Digital Audio Installation Manual Tel: 01206 855800 Fax: 01206 855801 Select Manufacturing Limited Functional & Digital Audio Systems ELECT Commissioning/Final Inspection Test Sheet. Commissioning Engineer: Client Name: Site Address: Installer Name: Telephone No.: Controller Comments Trades Trades settings General System Comments:...
