Digital Voice Systems Net-2000 Specifications page 2

Each Net-2000™ converts the input analog
speech into digital speech samples,
encodes the speech using the selected
AMBE Vocoder mode and then send the
®
compressed bit stream out as UDP packets
over the Ethernet interface. Simultaneously,
the compressed bit stream of UDP packets
from the other Net-2000™ is read in from
the Ethernet interface and decoded back in
to digital speech samples. The decoded
samples are converted back into analog
speech via the AIC-10 codec whose output
is sent to both the handset and line-level
output connections.
Alternatively, the Ethernet interface can
connect directly to a Local Area Network
(LAN). This configuration can be used to
create a real-time Ethernet based vocoder
communication system or to record /
playback of files using a PC. Being able to
encode/decode files stored on a PC makes
the Net-2000™ ideal for compressed-voice
storage applications or non-real-time testing
and evaluation.
Initial set-up of the Net-2000™ is fast and
straightforward thanks to its Ethernet
network connection. It is equipped to
handle IP address information from a DHCP
Rear Panel Connections
Serial Port
LAN
RS-422 Synchronous
RS-422 Asynchronous
2 Wire I/O
Analog Line In
Analog Line Out
Handset
AC Line In
AMBE is a registered trademark of Digital Voice Systems, Inc.
server when available on the LAN.
Alternatively, the Net-2000™'s RS-232 serial
port can be used via telnet as a console
terminal to allow low-level network setup
and selection among the various input and
output audio interfaces.
The Net-2000™ is controlled via PC
connected through the RS-232 or Ethernet
interface. When connected on a LAN —
any PC on the network can use a standard
web browser to configure and control the
unit without requiring custom PC software.
The user-friendly web pages built-into the
Net-2000™ make it easy to select analog
audio interfaces, configure the AMBE
vocoder mode and to establish real-time,
full-duplex communication across the
Ethernet or RS-422 connection. In addition
to the control, the web pages display
information about network settings,
operating mode and system status. Since
the Net-2000™ uses Ethernet, its web page
can even be accessed over a wireless
network through a wireless notebook or
tablet PC.
Technology Team
DB9s
RJ-45
DB-15HD
RJ-45
RJ-11
RCA Jack
RCA Jack
RJ-14
Pwr. Recp.
AMBE+2 is a trademark of Digital Voice Systems, Inc.
®
AC Power Requirements
V 100 - 240 V ~
FR 50 / 60 Hz.
28 W
The Net-2000™ is designed and
manufactured with Digital Voice Systems,
Inc.'s (DVSI) in-depth knowledge of voice
compression algorithms. DVSI's dedicated
engineering resources have years of
experience in vocoder technology,
specializing in Digital Signal Processing,
software generation and hardware
development. This has lead DVSI to
become the accepted industry leader in high
performance, low-bit-rate, voice
compression technology.
Contact Us
For more information on the NET-2000™
and how to achieve the best voice quality at
the lowest data rate contact us today.
Digital Voice Systems, Inc.
The Speech Compression Specialists
234 Littleton Road
Westford, MA 01886
Tel: (978) 392-0002
Fax: (978) 392-8866
Web: www.dvsinc.com
Mechanical Specifications
Dimensions: 17.25 X 3.5 X 7.25 inch
Weight: 4.5 pounds
Specifications subject to change.
