  • Page 1 Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp. MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel Corporation. Other product names used in this manual are the properties of their respective owners and are acknowledged. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 2 RF emission limits governing this device. Changes or modifications not expressly approved by the system’s manufacturer could void the user’s authority to operate the equipment. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 3 16A per phase and not subject to conditional connection  EN 55024 Information technology equipment-Immunity characteristics-Limits and methods of measurement  EN 60950 Safety for information technology equipment including electrical business equipment  CE marking LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 4 Do not spill water or any other liquid on your system. • When the system is turned OFF, a small amount of electrical current still flows. Always unplug all power, modem, and network cables from the power outlets before cleaning the system. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 5 Do not attempt to disassemble the optical drive. For your safety, have the optical drive serviced only by an authorized service provider. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 6 3. Do not expose this product to high levels of direct sunlight, high-humidity or wet conditions. 4. Do not block the air vents to this product or impede the airflow in any way. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 7 BIOS Setup Using BIOS Utility.  page 11 Chapter 3 Describes the motherboard software. Using the Motherboard Software  page 49 Chapter 4 Provides basic trouble shooting tips. Troubleshooting  page 61 LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 8 Memo LIVA Z2 SMALL FORM FACTOR PC USER MANUAL viii...

  • Page 9: Table Of Contents

    The Standard Configuration....12 Entering the Setup Utility......12 Resetting the Default CMOS Value..13 Using BIOS.............14 BIOS Navigation Keys......15 Main Menu..........16 Advanced Menu........17 Chipset Menu..........33 M.I.B X(MB Intelligent BIOS X) Menu..37 Boot Menu..........39 Security Menu........43 LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 10 Using the Motherboard Software Installing the Windows OS......49 Drivers auto-installing under Windows 10 ..Running Setup........51 Manual Installation........54 ECS Utility Software(Intelligent EZ Utility)..54 Windows 10 OS Recovery......56 Chapter 4 Troubleshooting Troubleshooting and problem solution..61 LIVA Z2 SMALL FORM FACTOR PC USER MANUAL viii...

  • Page 11: Introducing The Pc

    Chapter 1 Introducing the PC Introduction Thank you for choosing LIVA Z2 Small Form Factor PC featuring GLKM-MINI of great performance and with stylish and flexible de- sign. ® This Small Form Factor PC is based on Intel SoC N4000 / N4100 / N5000 Mobile platform.

  • Page 12: Specifications

    1 x DC_IN port (19V only) Rear Panel I/O • 1 x Giga LAN connectors • 1 x HDMI 2.0 port • 1 x HDMI 1.4 port • 2 x USB 2.0 ports LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 13 It should be done at your own risk and expense. We are not responsible for possible damage casesd by overclocking. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 14: Front And Rear I/O

    Connect your Type-C USB 3.0 device to this port. *Note: The Type-C USB 3.0 port of this model is used for data transmission only, it can not be used for DC-in power supply and video output. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 15 HDMI 2.0 port. 8. USB 2.0 Ports Use the USB 2.0 port to connect USB 2.0 device. 9. Giga LAN Port Connect the RJ-45 jack to the LAN ports for Network connecting. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 16: Motherboard Components

    Motherboard Components LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 17 LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 18 Front LED header (optional) 10. USB3F1~3 Front USB 3.0 ports (Type-A) 11. USB3F4 Front USB 3.0 port (Type-C) 12. DIMM1~2 Dual-channel DDR4 SDRAM SO-DIMM 13. AUDIO_JACK Audio jack 14. DMIC 4-pin Digital microphone connector LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 19: Header Pin Definition

    Header Pin Definition BT (Battery) +VBAT CPU_FAN DMIC LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 20 Memo LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 21: Using Bios

    The settings made in the Setup Utility affect how the computer performs. Before using the Setup Utility, ensure that you understand the Setup Utility options. This chapter provides explanations for Setup Utility options. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 22: The Standard Configuration

    (POST) routines. POST is a series of built-in diagnostics performed by the BIOS. After the POST routines are completed, the following message appears: Press DEL to enter SETUP Press the delete key to access BIOS Setup Utility. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 23: Resetting The Default Cmos Value

    CMOS data at factory by the manufacturer. You simply need to Load Default Settings and Save it to reset the default CMOS values. Note: Changes to system hardware such as different CPU, memories, etc. may also trigger this message. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 24: Using Bios

    The default BIOS setting for this motherboard apply for most conditions with optimum performance. We do not suggest users change the default values in the BIOS setup and take no responsibility to any damage caused by changing the BIOS settings. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 25: Bios Navigation Keys

    BIOS items presented in this manual. The BIOS setup screens shown in this chapter are for reference only and may differ from the actual BIOS. Please visit the manufacture’s website for updated manual. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 26: Main Menu

    If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility. BIOS Version (18.05.23) This item shows the information of BIOS version. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 27: Advanced Menu

    F1:General Help      USB Configuration F2:Previous Values      Trusted Computing F3:Optimized Defaults F4:Save & Exit ESC:Exit Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 28 Resume By USB (Disabled) This item allows you to enable/disable the USB device wakeup function from S3 mode. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 29 ATX power supply in order to use this feature. EUP Function (Enabled) This item allows user to enable or disable EUP support. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 30 Use this item to select SATA mode. SATA Port (Not Present) This item displays the information of SATA storage installed on the SATA port. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 31 ESC:Exit Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. Onboard LAN Controller (Enabled) Use this item to enable or disable Onboard LAN controller. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 32 System temperature, CPU & DIMM voltage, CPU & System fan speed... etc. • SoC Temperature (DTS) • TCC Activation Temperature (DTS) Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 33 Use this item to enable or disable Embedded Multi Media Card support. eMMC Information (MMC - TA2832 (31.3 GB)) This item shows the information of eMMC storage. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 34 Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. ACPI Sleep State [S3(Suspend to RAM)] This item allows user to select the highest ACPI sleep state that the system will enter. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 35 Intel Virtualization Technology [Enabled]      F1:General Help CPU Power Management F2:Previous Values Enhanced Halt (C1E) [Enabled] F3:Optimized Defaults F4:Save & Exit ESC:Exit Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 36 This item shows the version of microcode patch. Max CPU Speed (1100 MHz) This item shows the max speed of the CPU. Min CPU Speed (800 MHz) This item shows the min speed of the CPU. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 37 If bi-direction is enabled, external agents can drive PROCHOT# to throttle the processor. Intel Virtualization Technology (Enabled) When enabled, a VMM can utilize the additional hardware capabilities provided by VandorPool Technology. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 38 This item allows you to select the type of P-State coordination among processors with dependencies. The available options are HW_ALL, SW_ALL, and SW_ANY. C-States (Enabled) This item allows you to enable or disable the C-States. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 39 Press <Esc> to return to the CPU Configuration page. Enhanced Halt (C1E) (Enabled) Enable/Disable C1E. When enabled, CPU will switch to minumum speed when all cores enter C-State. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 40 Use this item to enable or disable all USB devices. Legacy USB Support (Enabled) Use this item to enable or disable support legacy USB devices. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 41 This item allows you to enable or disable the security device support. Active PCR banks (SHA-1, SHA256) This item shows activated PCR banks. Available PCR banks (SHA-1, SHA256) This item shows available PCR banks. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 42 2.0 devices, Auto will support both with default set to TPM 2.0 devices if notfound, TPM 1.2 devices will be enumerated. Press <Esc> to return to the Advanced Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 43: Chipset Menu

    Configuration  :Select Screen  :Select Item Enter : Select +/- : Change Opt. F1:General Help F2:Previous Values F3:Optimized Defaults F4:Save & Exit ESC:Exit Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 44 TXE Firmware Version (4.0.0.1016) Use this item to show the TXE Firmware version. GOP Driver Version (13.0.1016) Use this item to show the GOP Driver version. Press <Esc> to return to the Chipset Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 45 Azalia HD Audio (Enabled) This item enables or disables Azalia HD audio. Resotre AC Power Loss* (Power Off) This item enables your computer to automatically restart or return to ites operating status. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 46 *When Eup Function is set to Enabled, this item will be nonadjustable. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 47: M.i.b X (Mb Intelligent Bios X) Menu

    CPU Ratio (11) This item shows the information of the CPU Ratio. CPU Speed (1.10 GHz) This item shows the processor speed. Memory Speed (2133 MHz) This item shows the memory speed. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 48 Total Memory (8192 MB (DDR4)) This item shows the total memory. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 49: Boot Menu

    UEFI USB Flash Drive Priorities F2:Previous Values F3:Optimized Defaults F4:Save & Exit ESC:Exit Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. Operation System Select (Windows 10) This item is used to select the operation system. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 50 Boot Mode select (UEFI) Use this item to select boot mode. Boot Option #1~7 These items show the boot priorities and can be used to set the boot priorities of various device categories. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 51 Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. Boot Option #1 (Windows Boot Manage...) Use this item to set the system boot order. Press <Esc> to return to the Boot Menu page. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 52 F1:General Help F2:Previous Values F3:Optimized Defaults F4:Save & Exit ESC:Exit Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. Boot Option #1 (UEFI: JetFlashTrans...) Use this item to set the system boot order. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 53: Security Menu

    Version 2.19.1268. Copyright (C) 2018 American Megatrends, Inc. Administrator Password Status (Not Installed) This item shows administrator password is installed or not. User Password Status (Not Installed) This item shows user password is installed or not. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 54 This item is used to control the secure boot flow, it is possible only if system runs in User Mode. Secure Boot Customization (Standard) This item is used to set the secure boot customization. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 55: Exit Menu

    Discard Changes and Exit This item enables you to exit the system setup without saving any changes. Save Changes and Reset This item enables you to reset the system setup after saving the changes. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 56 This item enables you to save the changes that you have made as user defaults. Restore User Defaults This item enables you to restore the user defaults. Boot Override Use this item to select the boot device. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 57: Updating The Bios

    If your motherboard has a Flash BIOS jumper, reset the jumper to protect the newly installed BIOS from being overwritten. The computer will restart automatically. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 58 Memo LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 59: Using The Motherboard Software

    You need to change the booting priority in BIOS in order to boot from USB device. Enter into BIOS and select the Boot in menu (or press the hotkey F7), set USB drive as the first booting priority. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 60: Drivers Auto-Installing Under Windows 10

    DVD-ROM drive, the auto-run feature will automatically bring up the installation screen. Information: Displays the path for all software and drivers available on the disk. Click the “Setup” button to select and run the software installation program. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 61: Running Setup

    Click Setup. The installation program begins: The following screens are examples only. The screens and driver lists will be different according to the motherboard you are installing. The motherboard identification is located in the upper left-hand corner. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 62 Check the box next to the items you want to install. The default options are recommended. Click Next to run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 63 Windows 10 will appear below UAC (User Account Control) message after the system restart. You must select “Yes” to install the next driver. Continue this process to complete the drivers installation. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 64: Manual Installation

    ECS Intelligent EZ Utility provides friendly interfaces under Windows O.S., which make your computing more easily and conveniently. These software(s) are subject to change at anytime without prior notice. Please refer to the support disk for available software. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 65 ECS eBLU utility makes BIOS update faster and easier. eBLU will list the latest BIOS with a default check-mark. Click”install” button to install. Microsoft .NET Framework 3.5 is required. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 66: Windows 10 Os Recovery

    Windows 10 Recovery has basically 2 categories. Keep my files & Remove everything. Each types of recovery was defined by Microsoft, you can check their website “Reset my PC” section for further definition recovery scenarios.https:// support.microsoft.com/en-us/help/12415/windows-10-recovery- options 1. Select “Setting” LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 67 2. Select “Update & security ” 3. Select “Recovery” “Reset this PC – Get started” LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 68 Once “Get started” was selected, there are 2 types of recovery mode will be presented. [Keep my files] Click “Reset” and start the recovery process. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 69 [Remove everything] [Remove everything – Just remove my files] [Remove everything – Remove files and clean the drive] Select “Reset” to start the reocvery process. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 70 Memo LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...

  • Page 71: Troubleshooting

    Black screen or no image is displayed on the monitor. 1. Check whether the monitor has been turned on or works normally on other system. 2. Check whether the system has been power on successfully. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 72 1. Check whether the driver is correctly installed in “Device Manager”. If there is yellow mark or unknown devices message shown in the list, please reinstall the driver via LIVA official Driver DVD or ECS official website. LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
  • Page 73 1. Check whether the LAN driver is correctly installed in “Device Manager”. If there is yellow mark or unknown devices message shown in the list, please reinstall the driver via LIVA official Driver DVD or ECS official website. 2. Ensure the LAN cable is securely inserted to the RJ45 port and the LED light flashes normally.
  • Page 74 1. Check whether the WLAN card driver is correctly installed in “Device Manager”. If there is yellow mark or unknown devices message shown in the list, please reinstall the driver via LIVA official Driver DVD or ECS official website. 2. Check the WIFI in your working area is well functional and has good reception.
  • Page 75 1. Check whether the audio driver is correctly installed in “Device Manager”. If there is yellow mark or unknown devices message shown in the list, please reinstall the driver via LIVA official Driver DVD or ECS official website. 2. After connecting the speaker or header phone, adjust audio setting in Control panel>...
  • Page 76 Memo LIVA Z2 SMALL FORM FACTOR PC USER MANUAL...
