- Page 1 I N S TA L L AT I O N G U I D E...
- Page 2 SPECIFICATIONS Main features: • Micro tower case • Magnetic dust lter • Up to 7 fans capability (depends of PSU system used) • Vertical or horizontal GPU assemble • High speed USB 3.0 (x2) Micro tower Chassis size type: Micro ATX; ITX MB form factor: External drive bays: 3x 3.5"...
- Page 3 Power Reset USB 3.0 Audio & Mic USB 3.0 Front Panel Left HDD Micro-PSU Bracket / Fan Bracket Bottom Plate ATX PSU Bracket Side Cover ...
- Page 4 DISASSEMBLY Open & lift Remove side panels from the back Remove front panel Remove screws on rear plate, then Unscrew to remove HDD / Fan open top and bottom plate bracket and the side bracket MATX MOTHERBOARD INSTALLATION Prepare the IO slot Put the MATX motherboard in the right place Fix the MATX motherboard using the...
- Page 5 MATX MOTHERBOARD: ATX PSU INSTALLATION Unscrew the hard drive enclosure from the back of the motherboard tray Remove the micro PSU enclosure, place Fix with hexagonal screws from above the ATX PSU in the correct position MATX MOTHERBOARD: SFX PSU INSTALLATION Put in the gaskets before xing the Put in the PSU and x it using the HDD / SSD with the step screws.
- Page 6 ITX MOTHERBOARD INSTALLATION Prepare the IO slot Put the ITX motherboard in the right place Put the motherboard in the right place ITX MOTHERBOARD: ATX PSU INSTALLATION Unscrew the Micro HDD enclosure from the back of the motherboard tray Remove the micro PSU enclosure, place Fix with hexagonal screws from above the ATX PSU in the correct position...
- Page 7 ITX MOTHERBOARD: MICRO PSU INSTALLATION (METHOD 1) Put in the gaskets before xing the Put in the PSU and x it using the HDD / SSD with the step screws. hexagonal screws Apply the correct screws according to: 2.5’’ SSD screws | 3.5’’...
- Page 8 MAXIMUM CPU COOLER HEIGHT Up to 155mm when the GPU is Up to 88mm when the GPU is installed horizontally and without the installed vertically left side bracket GRAPHIC CARD INSTALLATION Lift the magnetic PCI bay Unscrew and remove the PCI bay Insert the GPU and x it with a screw Job’s done!
- Page 9 VERTICAL GPU INSTALLATION Lift the magnetic cover of the PCI bay Insert the GPU and x it with screws, and unscrew it then connect it with the cable VERTICAL GPU INSTALLATION: GPU MAX. LENGHT 245mm, with Micro PSU 245mm, with ATX PSU (when PSU is xed to the front panel) ITX MOTHERBOARD: MAXIMUM GPU LENGHT...
- Page 10 HDD INSTALLATION ON HDD / FAN BRACKET Prepare the SSD / HDD and the Place the SSD / HDD into the bracket bracket on the side with the raised edge Fix with screws: Fix it back to the chassis bottom / top HDD HDD screws SSD MB screws (ATX PSU installed: allows only x1 HDD)
- Page 11 FRONT PANEL DUAL SSD INSTALLATION Place the SSD in the location Use motherboard screws to x it indicated by the screw holes WATER COOLER INSTALLATION ON HDD / FAN BRACKET (INSTALLATION SUPPORTED ONLY AT THE BOTTOM) Fix the 120 / 240mm water cooler to Fix the bracket back to the bottom of the bracket as shown in the picture the chassis (water cooler installations on...
- Page 12 FANS INSTALLATION ON TOP PANEL HDD / FAN BRACKET Fix the 12cm fans to the bracket Fix the bracket back into t he chassis FANS INSTALLATION ON BOTTOM HDD / FAN BRACKET Fix 12cm fans to the bracket with the Fix the bracket back into the chassis air outlet facing the bottom FANS INSTALLATION ON...
