Jeulin TECHNOSKLO DP 4000 Operating Manual

Distillation apparatus for producing of distilled water
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TECHNOSKLO Ltd.
Držkov
Distillation apparatus for producing of
distilled water
TYPE DP 4000
Operating manual
TECHNOSKLO Ltd.
Držkov 135
468 24 Držkov
Czech Republic
tel.: 00420 483 346 403
fax: 00420 483 385 040
Skype: miroslav.bruna
e-mail:
sales@technosklo.com
http://www.technosklo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TECHNOSKLO DP 4000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Jeulin TECHNOSKLO DP 4000

  • Page 1 TECHNOSKLO Ltd. Držkov Distillation apparatus for producing of distilled water TYPE DP 4000 Operating manual TECHNOSKLO Ltd. Držkov 135 468 24 Držkov Czech Republic tel.: 00420 483 346 403 fax: 00420 483 385 040 Skype: miroslav.bruna e-mail: sales@technosklo.com http://www.technosklo.com...

  • Page 2: Table Of Contents

    Content Page I. Description of the apparatus ..............3 II. Technical data..................3 III. General Instructions and safety regulations ........3 IV. Connection to the Electrical Mains/Water Supply ......4 V. Picture of the apparatus ..............5 VI. Unpacking the apparatus ..............6 VII.

  • Page 3: Description Of The Apparatus

    I. Description of the apparatus Distillation apparatus for producing of distilled water TYPE DP 4000 is identified for preparing of smaller amounts of distilled water. By way of this apparatus it is possible to prepare approximately 4 litre of distilled water at one hour.

  • Page 4: Connection To The Electrical Mains/Water Supply

    8. The available voltage and type of current must correspond to the data given on the type plate. 9. The electrical connection must have front end protection with fuse of at least 15 A. 10. Connections to the electrical mains and water supply must be made in such way as to avoid creating dripping hazards 11.

  • Page 5: Picture Of The Apparatus

    V. Picture of the apparatus Description of apparatus glass stopcock of the reservoir bottle outlet valve reservoir bottle mains switch tubing connection evaporator distillate nozzle green lamp mains protective cap degassing outlet level tube hole for switch off the temperature limiter tubing connection for cooling water supply 15 cooling coil overflow tubing connection...

  • Page 6: Unpacking The Apparatus

    VI. Unpacking the apparatus − Open carton box − Carefully remove upper part of interior cover made from polyurethane foam an lift up the apparatus form the box. − Check the apparatus immediately for glass breakage and other damage which may have occurred during transportation.

  • Page 7: Connecting Of The Tubing

    X. Connecting of the Tubing Use the PVC tubing supplied for the connections. Note Dip the end of the PVC tubing into hot water (approximately 80 °C) for about 3 minutes before use. This will make the tubing flexible so that it can easily fitted on the glass tubing connection.

  • Page 8: To Adjust The Water Supply

    − Stopcock is closed − The stopcock of the reservoir bottle and the outlet valve (9) are closed. Plug the mains supply plug into the mains socket To adjust the water supply − Slowly turn on water tap to allow just a small amount of water to flow through the overflow (rate of water flow approximately 0, 5 to 1 l/min).

  • Page 9: To Switch Off

    Caution − Close the water tap. − Switch off the apparatus (mains switch), and allow it to cool down for at least 15 minutes. − Clear the defect in the water supply. − Switch off the temperature limiter : take a piece of non-conducting material (length minimal 50 and maximal outside diameter 3 mm), insert it to the hole (14) on the back side of the base of the apparatus and slightly press on it .

  • Page 10: To Clean The Evaporator

    − acetic acid, 10 - 50 % − tape water for rinsing Warning Disconnect apparatus from the mains by pulling plug out of the socket before cleaning. There is risk of corrosive burns. Wear protecting clothing, gloves and goggles during cleaning.
  • Page 11 To rinse the evaporator − slowly pour approximately one litter of tap water into the funnel − carefully fill the evaporator up to the lower edge of the distillate drain tube (4) − drain it through the outlet valve (9) and close the outlet valve again −...

  • Page 12: To Clean The Cooling Spiral

    To clean the cooling spiral (15) − After the apparatus has cooled down completely, drain the water out of the evaporator through the outlet valve (9). The outlet valve (9) must remain open. − Hang the ends of the outlet valve (9) and the overflow tubing (8) into the vessel for disposal of the acid.

  • Page 13: Return Of The Apparatus For The Repair

    XV. Return of the apparatus for the Repair Carefully clean the instrument, and send it to your supplier. Please describe your complaint in detail. XVI. Disassembly and reassembly of the glass part Disassembly Drain all water from the apparatus. To carefully loosen all eight screws of the halving clamping ring.
