- Page 1 XT1520 Product Manual XT1520 Product Manual Firmware Version: NV11.1125AA1 Revised July 06, 2020 Page 1 | 10 CONFIDENTIAL AND PROPRIETARY...
-
Page 2: Table Of Contents
XT1520 Product Manual ABLE OF ONTENTS 1. Functional Description 1.1. Overview 1.2. Mechanical 2. General Operation 3. Installation 4. Bluetooth (BLE) 4.1. UID Frame 4.2. TLM Frame 5. Bluetooth protocol Diagram 6. Regulatory Statements 6.1. FCC 6.2. IC 6.3. CE... -
Page 3: Functional Description
VERVIEW The XT1520 series are Bluetooth beacons with a single chip Bluetooth 5 + ARM. The beacons allow the user to quickly identify a cart's location if it is within proximity of an XT49xx to determine whether a cart is at a distribution center or en route. -
Page 4: General Operation
ENERAL PERATION The XT1520 attaches to Amazon carts and is used in conjunction with an XT49xx mounted on an Amazon trailer. The XT49xx periodically captures the unique device IDs at a configurable rate of all beacons in range. The XT49xx then sends the information over the cellular network, which is received by AWS. -
Page 5: Installation
3. I NSTALLATION The XT1520 offers two different means of mounting: zip ties, or 3M VHB tape. The back of the device casing is flat so the VHB tape can be adhered. The holes zip ties are indicated below. Page 5 | 10... -
Page 6: Bluetooth (Ble)
4. B (BLE) LUETOOTH (TM) The XT1520 uses Bluetooth 5 network, utilizing the Eddystone message protocol from Google. This protocol has four frame types: UID, URL, TLM, and EID; however, URL and EID frames are not utilized in this application. In (TM) -
Page 7: Bluetooth Protocol Diagram
XT1520 Product Manual 5. B LUETOOTH PROTOCOL IAGRAM Page 7 | 10 CONFIDENTIAL AND PROPRIETARY... -
Page 8: Regulatory Statements
Consult the dealer or an experienced radio/TV technician for help. Radio frequency radiation exposure Information: This equipment, XT1520, complies with FCC and ISED radiation exposure limits set forth for an uncontrolled environment. This equipment must be installed and operated with minimum distance of 20cm between the XT1520 and your body. - Page 9 XT1520 Product Manual 6.2. IC Antenna Statement Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
- Page 10 XT1520 Product Manual WARNING: This product can expose you to chemicals including Nickel (Metallic), which is known to the State of California to cause cancer and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm.
