Kvaser Mini PCI Express HS User's Guide
Copyright 2011-2013 Kvaser AB, Mölndal, Sweden
http://www.kvaser.com
Last updated Wednesday, 18 September 2013
We believe that the information contained herein was accurate in all respects at the time of printing. Kvaser AB cannot, however, assume
any responsibility for errors or omissions in this text. Also note that the information in this document is subject to change without notice and
should not be construed as a commitment by Kvaser AB.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kvaser Mini PCI Express HS
Summary of Contents for Kvaser Mini PCI Express HS
- Page 1 Last updated Wednesday, 18 September 2013 We believe that the information contained herein was accurate in all respects at the time of printing. Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note that the information in this document is subject to change without notice and...
- Page 2 Kvaser Mini PCI Express HS User's Guide 2(12) (This page is intentionally left blank.) Kvaser AB, Mölndal, Sweden — www.kvaser.com...
-
Page 3: Table Of Contents
Kvaser Mini PCI Express HS User's Guide 3(12) Table of Contents About this manual ......................4 Introduction ........................4 Welcome to Kvaser Mini PCI Express HS ..............4 Major features ......................5 Additional software and documentation ...............5 Kvaser Mini PCI Express HS hardware ................6 Hardware installation ....................6 Firmware Update ......................6... -
Page 4: About This Manual
Kvaser Mini PCI Express HS User's Guide 4(12) 1 About this manual This manual is intended for Kvaser Mini PCI Express HS users. This document contains a description of the hardware’s properties and general instructions for connecting the device to a computer. -
Page 5: Major Features
Kvaser CANLIB SDK, which includes everything you need to develop software for the Kvaser CAN hardware. Includes full documentation and many sample programs, written in C, C++, C#, Delphi, and Visual Basic. All Kvaser CAN interface hardware shares a common software API. Programs written for one device type will run without modification on other device types! ... -
Page 6: Kvaser Mini Pci Express Hs Hardware
In this section you can read more about the CAN channels, power supply and led indicators. 3.1 Hardware installation The Kvaser Mini PCI Express HS may be inserted in any free Mini PCI Express slot on the host computer that supports USB. You do need to switch the power off before inserting or removing the device. -
Page 7: Led Indicators
Kvaser Mini PCI Express HS User's Guide 7(12) 3.6 LED Indicators The Kvaser Mini PCI Express HS has one LED, it's functionality is shown in Table 2. Table 2 LED configuration Function Description Green Power Steady light when unit is powered and working. -
Page 8: Appendices
Kvaser Mini PCI Express HS User's Guide 8(12) 4 Appendices In this section you will find technical information about the Kvaser Mini PCI Express HS and its connectors. 4.1 Technical data In Table 3 below you will find the Kvaser Mini PCI Express HS’s technical specifications. -
Page 9: Can Connectors
Kvaser Mini PCI Express HS User's Guide 9(12) 4.2 CAN connectors The Kvaser Mini PCI Express HS has one high-speed CAN channel with a 4-pin Molex connector (53780-0470) with the pinning described in Table 4. Table 4: Molex pin configuration. -
Page 10: Disposal And Recycling Information
Kvaser Mini PCI Express HS User's Guide 10(12) 5 Disposal and Recycling Information When this product reaches its end of life, please dispose of it according to your local environmental laws and guidelines. 6 Legal acknowledgements 6.1 Usage warning WARNING FOR ALL USERS... -
Page 11: Agency Approval
TO THE CORRECTION OF DEFECTS, AND KVASER AB HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE KVASER AB DOES NOT HAVE ANY INFLUENCE ON THE IMPLEMENTATIONS OF THE HIGHER-LEVER SYSTEM, WHICH MAY BE DEFECTIVE. -
Page 12: Document Revision History
Kvaser Mini PCI Express HS User's Guide 12(12) 7 Document revision history Revision Date Changes 2013-09-17 First revision Kvaser AB, Mölndal, Sweden — www.kvaser.com... - Page 13 X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for manufacturer: kvaser Other Similar products are found below : 00671-3 00685-0...
