Digital Blue DDA8040 Quick Reference

Disney digital music player
Hide thumbs
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Rotate to adjust the volume
Will light red when the power is on
Plug the small end of the AC adapter
Insert the Disney Digital Music
Player (DDA8040) directly to the
Input Plug and the USB Jack
SIMPLIFIED OPERATION FOR DISNEY DIGITAL MUSIC PLAYER (DDA8040)
1.
Connect the AC adapter (included) to the AC outlet and the DC IN jack at the
rear of the unit; the Power indicator will light red.
2a. To charge the rechargeable battery of the Disney Digital Music player
(DDA8040), slide the Power switch (on the DDA8040) to the OFF position; then
insert it directly onto the Audio Input plug and the USB jack to begin charging.
2b. To hear the music from the Disney Digital Music player (DDA8040), slide the
Power switch (on the DDA8040) to the ON position and insert it directly onto the
Audio Input plug and the USB jack. The Disney Digital Music player (DDA8040)
will start playback automatically; the sound will be heard through the Speaker
System and the lights around the speakers will flash randomly. Adjust the volume
by rotating the Volume control at the top of the Speaker system and the Volume
buttons on the Disney Digital Music player (DDA8040).
3.
When finished, unplug the AC adapter and the Disney Digital Music player from
the Speaker System.
SIMPLIFIED OPERATION FOR OTHER MP3 PLAYERS:
1.
Insert the MP3 player through the Audio IN cable (included) to the Audio Input
plug.
2.
Connect the AC adapter (included) to the AC outlet and the DC IN jack at the
rear of the unit; the Power indicator will light red.
3.
Refer to the owner's manual of the MP3 player to start playback. The sound will
be heard through the Speaker System and the light around the speakers will
flash randomly. Adjust the volume by rotating the Volume control.
4.
When finished, unplug the AC adapter and the MP3 player from the
System.
QUICK REFERENCE
into this jack
1
Connect the MP3 player through
the Audio In cable (included) onto
this plug and the other end to the
MP3 player's Line out or
Headphone jack
Speaker

Advertisement

Table of Contents
loading

Related Manuals for Digital Blue DDA8040

Summary of Contents for Digital Blue DDA8040

  • Page 1 2b. To hear the music from the Disney Digital Music player (DDA8040), slide the Power switch (on the DDA8040) to the ON position and insert it directly onto the Audio Input plug and the USB jack. The Disney Digital Music player (DDA8040) will start playback automatically;...

  • Page 2: Safety Precautions

    CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This Caution Marking is located at the bottom enclosure of the unit. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to...
  • Page 3 INFORMATION: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference...

  • Page 4: Power Source

    Only use the supplied AC adapter which has the following specs: DC 12V, 500mA z. • For the Disney Digital Music Player (DDA8040), while the player is turned off, directly connect it to the Audio Input plug and the USB jack, the Disney Digital Music Player’s...

  • Page 5: Location Of Controls

    1. VOLUME Control 2. Left Speaker 3. Right Speaker 4. Power Indicator 5. Audio Input Plug 6. DC IN Jack (Rear of Unit) 7. USB Jack (Can only be used to recharge the battery of the Disney Digital Music player [DDA8040])

  • Page 6: Operation

    Speaker System and the lights around the speakers will flash randomly. NOTE: For the DDA8040, if the unit is in the Stop mode, after two minutes, it will start playback again automatically. If you don't want it to start playback again, you should unplug the unit from the Speaker System.
  • Page 7 CONNECTING AN MP3 PLAYER Connect the MP3 player to the Speaker System following one of the two connections below: For Disney Digital Music Player (DDA8040), insert the unit directly onto the Audio Input plug and the USB jack. NOTE: Make sure to slide the...
  • Page 8 If charging is finished and you want to playback the music files from the Disney Digital Music Player (DDA8040), unplug the unit from the Speaker System. Then slide the Power switch on the DDA8040 to the ON position and insert it back onto the Speaker System to start playback.

  • Page 9: Specifications

    SPECIFICATIONS Power Requirement...DC IN 12V Speaker ...4 Ohms, 3W Dimensions ...5 (W) x 6 (H) x 2.3 (D) Inches...
