- Page 1 Hybrid Bluetooth Speaker 288 User’s Manual RG2ACSK288 www.ranger-technology.com...
-
Page 2: Product Description
. The 3.5mm audio jack cable can use with devices that are without Bluetooth function such as MP3, MP4 or CD player. The Ranger Hybrid Bluetooth Speaker 288 is very portable. It is compact and weight only 81.5g and can be stashed into your bag and brought out... -
Page 3: Product Overview
2. Product Overview (1) Loudspeaker (2) Charging port (3) Indicator (4) Line in jack (5) Wire / Off / Bluetooth switch What’s in the box: Ranger Hybrid Bluetooth Speaker 288 3.5mm audio jack cable USB charging cable Carry pouch ... - Page 4 3. Charging Ranger Hybrid Bluetooth Speaker 288 use the DC power jack socket and comes with a USB charging cable. 1) Connect one end of the Usb charging cable to the DC port of the speaker and insert the other end ( USB-A ) into the USB port of your PC.
-
Page 5: Basic Operations
4. Basic Operations 4.1 Using 3.5mm audio cable 1). Connect the 3.5mm audio cable from the ( AUX IN ) port of the speaker to your music player. 2). Set / Push the switch to the “wire” position and the LED will shown as blue colour when Line in is working. - Page 6 2). Turn on the Bluetooth of your mobile phone or music device, search for Bluetooth device. 3). Select “Ranger 288” in the list of Bluetooth devices, then follow the steps and enter pin code 0000 to pair. 4). Once paired and connected, LED will flash blue once every 15 seconds. The...
- Page 7 4). Do not use outdoors in the wet or in damp surroundings.
-
Page 8: Product Specification
5. Product Specification Dimension: 45mm x 45mm × 55mm Net weight: 81.5g Bluetooth compliance: Bluetooth V2.1 Operating frequency band: 2.401-2.480 GHz (2.4GHz ISM segment) Operation range: Class 2, up to 10 meters Support profiles: A2DP, AVRCP ... -
Page 9: Troubleshooting
6. Troubleshooting Problem Possible cause Solution Low sound level Volume low on MP3/4 player Adjust volume on MP3/4 player LED not show up Battery low Charge battery No sound at all MP3/4 player not playing Press play on player Power switch off Slide power switch to “wire”... -
Page 10: Safety Information
7. Safety Information To avoid damage or malfunction of this device, do not drop it from high places. Keep this device away form humidity, water and other liquids. If the device is exposed to water, moisture or other liquids, do not operate it to avoid the potential of electric shock, explosion or damage to the device / injury to yourself. -
Page 11: Declaration Of Conformity
CAUTION: ELECTRIC SHOCK HAZARD The battery in this device may present a risk of fire or chemical burning if mistreated. 8. Declaration of Conformity 8.1. EU This product is CE certified according to the provision of the R&TTE Directive (99/5/EC). We declare that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. - Page 12 8.3. RF Warning Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. Changes or modifications not expressly approved by the party responsible for compliance. This could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 13 measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help 8.4.
