Premier Mounts LFC-L Installation Manual

Large format cart up to 300lbs/136kg flat panel display

Advertisement

Quick Links

Maximum Flat Panel Weight:
300 lb. / 136 kg.
LFC-L / LFC-LB
INSTALLATION GUIDE
Large Format Cart up to
300lbs/136kg Flat Panel Display
Leveling Feet Option
www.premiermounts.com | North America 800.368.9700 | International +1-714-632-7100
9500395 v1.1
2620 Palisades Drive, Corona, CA 92882 USA
publ. 05/29/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LFC-L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Premier Mounts LFC-L

  • Page 1 Maximum Flat Panel Weight: 300 lb. / 136 kg. LFC-L / LFC-LB INSTALLATION GUIDE Large Format Cart up to 300lbs/136kg Flat Panel Display Leveling Feet Option www.premiermounts.com | North America 800.368.9700 | International +1-714-632-7100 9500395 v1.1 2620 Palisades Drive, Corona, CA 92882 USA...
  • Page 2: Caution Statement

    Maximum Weight Capacity: CAUTION STATEMENT PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZE ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS, DEMANDS, SUIT ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.
  • Page 3: Core Components

    LFC-L / LFC-LB Installation Guide CORE COMPONENTS: INSTALLATION HARDWARE: M8 Lock Nut M8 x 16mm Button Universal Spacers M4 x 12mm M6 x 12mm M8 x 12mm (Qty 4) Hex (Qty 8) (Qty 8) (Qty 4) (Qty 4) (Qty 4)
  • Page 4 LFC-L / LFC-LB Installation Guide INSTALL THE CASTERS / LEVELING FEET Use 21mm wrench to install a pair of (L) locking and (NL) non-locking casters or four leveling feet. Soft Mat 3/8”-16 threaded casters Leveling Feet Option Notes: caster or leveling feet option may vary by model number.
  • Page 5 LFC-L / LFC-LB Installation Guide ASSEMBLE THE POLE ADAPTER TOGETHER Set the tab (8) M8 x 16mm pointing up Buttton Hex Vertical Brackets Pole Adapter MOUNT THE POLE ADAPTER Insert (4) M8 x 12mm set screws at the location shown, raise or lower the mount to desired height, and below then tighten using a M4 Hex key.
  • Page 6: Selecting The Mounting Hardware

    LFC-L / LFC-LB Installation Guide SELECTING THE MOUNTING HARDWARE Insert a small straw or toothpick into the threaded inserts found on the back of the flat-panel. Use a pencil to mark the depth of the threaded insert on the small straw or toothpick.
  • Page 7: Install The Mounting Brackets

    LFC-L / LFC-LB Installation Guide INSTALL THE MOUNTING BRACKETS EXTENSION ADAPTER WINGS 1019mm 910mm Selected mounting screws w/o adapters (from previous step) and Top of flat universal washers. panel Do not overtighten. 964mm 802mm w/o adapter Max Mounting Pattern Install the optional adapter wings to make accommodations for various mounting patterns.
  • Page 8 LFC-L / LFC-LB Installation Guide MOUNT THE FLAT-PANEL DISPLAY AND CENTER THE MOUNT Post-Level Locking STEP 1: Tighten/loosen the (2) M6 x 45mm screws for post-leveling adjustment. STEP 2: Install (2) M6 x 45mm screws to securely lock the mount firmly in place.
  • Page 9: Product Dimension

    LFC-L / LFC-LB Installation Guide PRODUCT DIMENSION 44.94 1141.47 (NESTING CAPABILITY) 28.98 736.20 41.00 1041.48 35.84 40.11 910.31 1018.77 37.94 31.58 963.57 802.15 81.66 65.37 2074.13 1660.40 4.04 84.72 MAX CENTER 102.63 2151.85 VIEWING HEIGHT WITH CASTERS TUBES 2" OD 5.30...
  • Page 10 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Premier Mounts intends to make this manual accurate and complete. However, Premier Mounts makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for every possible contingency in connection with the installation or use of this product.

This manual is also suitable for:

Lfc-lb
