Arrow 8041 Installation Instructions

Towel warmer

Hide thumbs

B-1

(EN) Junction box.

(SV) Kopplingsdosa.

(EN) Accessories for connection

to junction box. Not included.

(SV) Tillbehör för anslutning till

kopplings dosa. Ingår ej.

Art. 8090

(for 8041, 8042, 8043)

Art. 8092

(for 8045)

B-3

Ø8mm

B-5

B-6

B-2

B-4

(EN) All electrical connections in the junction box

must be performed by a fully qualified electrician.

(SV) Alla elektriska anslutningar i kopplingsdosan

måste utföras av behörig elektriker.

Example:

Art. code: 8041, 8042, 8043, 8045

Rev: 2018-Apr-26 10:04

(EN) Towel warmer installation instructions

(SV) Eektrisk handdukstork installationsmanual

8041

8042

8045

Art-nr

RSK-nr

8041

8754000

8042

8754001

8043

8754002

8045

8754155

8041: 65W

220-240V AC

8042: 120W

50Hz

8043: 110W

Max 55°C

8045: 65W

Arrow Skandinavien AB

Tel: +46 (0)31 330 00 10

www.arrowshower.com

8043

E-nr

EAN-kod

9410534

7391551080416

9410535

7391551080423

9410536

7391551080430

9410847

7391551080454

IP44

CLASS I

Table of Contents

Need help?

Do you have a question about the 8041 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arrow 8041

Page 1 (EN) Junction box. Art. code: 8041, 8042, 8043, 8045 Arrow Skandinavien AB (SV) Kopplingsdosa. Tel: +46 (0)31 330 00 10 www.arrowshower.com Rev: 2018-Apr-26 10:04 (EN) Accessories for connection to junction box. Not included. (EN) Towel warmer installation instructions (SV) Tillbehör för anslutning till kopplings dosa.
