Air Pr o

U S E R

M A N U A L

Table of Contents

Need help?

Do you have a question about the AirPro and is the answer not in the manual?

Questions and answers

Summary of Contents for TBI AirPro

Page 1 Air Pr o U S E R M A N U A L...
Page 2: Table Of Contents
Master/slave mode How to wear Features Specifications Troubleshooting Read these instructions completely, they contain safety information. Keep them for future reference. If you have any questions, feel free to contact us by phone number: (800) 674-92-29 (Free) or via email: support@tbi-pro.com...
Page 3: Safety And Handling
SAFETY AND HANDLING IMPORTANT SAFETY INFORMATION Handle AirPro earphones and case with care. They contain sensitive electronic components, including batteries, and can be damaged. Don’t use damaged AirPro earphones or case as they may cause injury. S a f e t y a n d h a n d l i n g...
Page 4 Keep it away from high temperature and high humidity environment. Keep it away from WIFI and routers and other high-frequency transmitting devices. This will affect the signal reception of the unit and cause the sound to be broken and disconnected. Please use this product in the effective environment 50 ft (15 m), and there should be no physical blocking...
Page 5: In The Box
IN THE BOX 2 x Earbud 1 x Charging Cord 1 x Charging Case I n t h e b o x...
Page 6: Charging
CHARGING CHARGING THE CASE When charging the charging case, be sure to use a USB to AC adapter with DC 5V power output to avoid malfunction or abnormal heat generation. Use only the supplied charging cable to charge the case. supplied charging cable to connect the charging case to a PC...
Page 7 CHARGING The display on charging case will show 1%~100% to represent the current battery capacity. FULLY CHARGED The display on the charging case will show 100%. After charging complete, unplug the USB charging cable. C h a r g i n g...
Page 8 CHARGING EARBUDS When earbuds charging level is low, there will be voice prompt. Put the earbuds into the charging case and close the top to charge the earbuds. White indicator light will turn on once earbuds are placed in the case for charging.
Page 9: Power On
POWER ON METHOD 1 Open charging case, the earbuds will power on and will pair with each other automatically. Take out both earbuds, the LED light of master earbud will start to flicker white alternately. (The left earbud is the master earbud as per factory default ) P o w e r O n...
Page 10 METHOD 2 Use this method if: a. Earbuds are taken out of from the charging case and in power off state. b. Battery of the charging case run out (If charging case is drained, earbuds won`t activate automatically as you take them out of case).
Page 11: Pairing
PAIRING For the first pairing with a bluetooth device, power on AirPro earbuds according to method 1 or 2. The LED light of master earbud will start to flash alternately. Turn on bluetooth search function on the device (mobile phone, laptop, etc.) and choose AIrPro V5 for connection.
Page 12 After bluetooth device is connected successfully, no need to repeat Pairing steps again. After earbuds powered on (according to method 1 or 2), it will connect with the latest connected device (mobile phone, laptop, etc.) automatically. If the latest connected device is not near to the earbuds or Bluetooth function is turned off, the earbuds will be at searching status (the LED light on earbuds will be flashing)
Page 13: Power Off
POWER OFF METHOD 1 Place the earbuds back into the charging case and close the lid. This will automatically power off the earbuds. Note: If the battery level of the charging case is at 0%, the earbuds will not power off automatically.
Page 14 METHOD 2 Press and hold an earbud (either left or right) for 6 seconds. The LED will light for 1 second and then powers off. If earbuds are disconnected and paired device/s was not able to establish connection within 10 minutes, earbuds will power off automatically.
Page 15: Master/Slave Mode
MASTER/SLAVE MODE This product has master/slave switch function. Open the charging case, and take out any earbud, it will connect to the device (mobile phone, laptop, etc.) and start to work, if another earbud is taken out, it will also connect to device automatically for simultaneous work.
Page 16: How To Wear
HOW TO WEAR Please put the earbuds into the cochlea gently, adjust suitable angle. H o w t o w e a r...
Page 17: Features
FEATURES PHONE CALLS Answer a call: To answer a phone call, short press the multifunction button on any earbud. Ending a call: When calling, short press the multifunction button on any earbud to end the call. CALL SWITCHING MODE During the phone call, long press the multifunction button on any earbud for 2 seconds to switch from earbuds to phone, then long press the multifunction button...
Page 18 MUSIC FUNCTIONS On/Pause: When music is playing, short press the multifunction button on any earbud to pause the music and then, short press the multifunction button on any earbud to play the music again. Previous song: When music is playing, double press the left earbud to previous song.
Page 19: Specifications
SPECIFICATIONS Bluetooth version V5.0 Bluetooth Chipset Airoha AB1536U Connection distance (open 10-15m space without obstacles) Earbuds battery capacity 40mAh Earbuds charging time 1 hour Play time (on one charge) 4-6 hours Case battery capacity 400mAh Case charging time 3-3.5 hours Charging input port Type-C USB Battery level indicator...
Page 20: Troubleshooting
TROUBLESHOOTING If your bluetooth earbuds can not be paired with your phone, try the following steps: Please make sure the earbuds are fully charged; Please make sure the earbuds are powered on; Please make sure that earbuds are currently not paired with other active devices; Please make make sure the device Bluetooth function is enabled, and bluetooth function is Please make sure that distance, between the...
Page 21 If above steps were not able to help resolve your issue, please try to restore default factory settings: Make sure the earbuds are in power off state, long press the right/left earbuds for 5-10 seconds until the white light starts flashing for 1 second and will power off automatically.
Page 22 Questions? Contact us at support@tbi-pro.com +1 800 674 92 29 (Mon-Fri 8:00-20:00 GMT-6) www.TBI-STORE.com Designed by TBI Pro in Illinois. Made in China...
Page 23 USB to AC adapter with DC 5V power output to avoid generation. batteries, and can be damaged. malfunction or abnormal heat generation. Don’t use damaged AirPro earphones or case as they Use only the supplied charging cable to charge the System. To avoid product damage may cause injury.
Page 24 Contact us at Please put the earbuds ONE-KEY SIRI into the cochlea gently, When earbuds is under standby or music playing support@tbi-pro.com adjust mode, long press the multifunction button on +1 800 674 92 29 suitable angle. any earbud to activate or close Siri (this feature is only available for IOS devices).
