Summary of Contents for Vemer Tempo

  • Page 1 User Manual Digital time/astronomical switch Tempo...

  • Page 3: Table Of Contents

    Program menu: new daily timed page Program menu: new weekly timed page Program menu: new holiday timed page Program menu: new astro night page Program menu: new astro daily page Program menu: new astro weekly page - 1 - User manual Tempo...
  • Page 4 The digital switch Tempo is an electronic device for the management of the electrical utilities over time. It allows the time programming (periodicity: daily or weekly) or astronomical. Tempo is a device of electronic type that performs actions of 1B type, intended to operate in environments with III overvoltage category and pollution degree 2 in accordance with EN 60730-1 standard.

  • Page 5: Technical Features

    8) The product can be used in environments with Measurement Category III and Pollution degree 2, according to the Standard EN 60730-1 - 3 - User manual Tempo...

  • Page 6: Dimensions

    DIMENSIONS WIRING DIAGRAM 5A/250V~ - 4 - User manual Tempo...

  • Page 7: Installation

    INSTALLATION TEMPO (cod. VE787500) Mount the white or anthracite grey frame according to your Make connections respecting the diagram shown on page 4 preferences by hooking it to the special teeth on the device. in this user manual Insert the device into the adapter...
  • Page 8 (White/Grey) The device can be adapted to the cover plates of Berker, Busch-Jaeger, Gira, Jung and Merten. The complete list of compatible cover plates is available on the website www.vemer.it on the product page. - 6 - User manual Tempo...

  • Page 9: Display And Keyboard Description

    • Key “ ” + “ ” (3 sec): activation (or deactivation) of random relay switching. flashing: relay switching When the random switchings are active, the display occurred after pressing the key shows the symbol (see “Manual relay switching”). - 7 - User manual Tempo...

  • Page 10: Initial Operation

    Keyboard lock with pin: disabled (---) • From main screen it’s possible to manually acton the relay output (see page 7) or access the menu to perform the programming or change the operating settings - 8 - User manual Tempo...

  • Page 11: Menu Description

    (relay on) of the loads connected to the relay. “Reset” menu allows you to reset settings, carried programming, operating hour counter. “Ver FW” menu allows you to check the firmware version installed on the device. - 9 - User manual Tempo...

  • Page 12: Settings Menu

    SETTINGS date DATE time automatic daylight saving time (DST) change SETTINGS position (astronomical coordinates) TIME interval duration between two random switchings SETTINGS key lock with PIN protection DAYL SAV. TIME SETTINGS SETTINGS RANDOM SETTINGS - 10 - User manual Tempo...

  • Page 13: Language Setting Menu

    LANGUAGE ENGLISH LANGUAGE LANGUAGE Available languages: LANGUAGE Italian, English, Spanish, French, German. Quick access: from the main page it’s possible to access the language setting by pressing the key for at least 3 seconds. - 11 - User manual Tempo...

  • Page 14: Date Setting Menu

    ( MM/DD/YY Choose, by convention, the first day of the week. In Italy, for example, the first day of the week is Monday, in the UK it’s Sunday. Enter the date: day, month, year. - 12 - User manual Tempo...

  • Page 15: Time Setting Menu

    TIME 27/04/2021 13:56 12:11 SETTINGS Parameters TIME modification TIME ZONE 1:00 Parameters modification Set the time: hours, minutes. Set the time zone. Range: -14:00 ÷ +14:00 at 15 minutes steps. For Italy set +1:00. - 13 - User manual Tempo...

  • Page 16: Daylight Saving Time (Dst)/Winter Time (Cet) Change Setting Menu

    In Italy, for example, daylight saving time (DST) begins the last ( LAST ) Sunday ( ) of March ( ) at 02:00 o’clock, and ends the last ( LAST ) Sunday ( ) of October ( ) at 03:00 o’clock. - 14 - User manual Tempo...
  • Page 17 ) or to disable ( AUTO OFF ) the automatic time change. Set date and time of the winter time (CET)-daylight saving time (DST) change. Set date and time of the daylight saving time (DST)-winter time (CET) change. - 15 - User manual Tempo...

  • Page 18: Astronomical Coordinates Setting Menu

    Therefore, in some applications it is more interesting to take as times of switching on and off the twilight (civil)in place of sunrise and sunset. With the switch Tempo it’s possible to choose to turn on/off the loads depending on the times of sunrise and sunset or the civil twilight.
  • Page 19 Set a possible correction of the calculated sunset time. Positive values to delay, negative values to anticipate. Choose as switching times the civil twilight ( CIVIL S ) in place of sunrise and sunset ( CIVIL N ) times. - 17 - User manual Tempo...

  • Page 20: Random Switchings Setting Menu

    Set the minimum duration. It’s possible to set values between 1 minute and the maximum duration. Set the maximum duration. It’s possible to set values between the minimum duration and 23:59 hours. Note: setting the minimum duration equal to the maximum, the switchings will occur at fixed time intervals. - 18 - User manual Tempo...

  • Page 21: Protection Pin Setting Menu

    Note: if you do not remember the PIN code, to unlock the device you must turn off the power to the device, press the key and restore power. This procedure unlocks the keyboard for 3 minutes, time which is enough to access the PIN setting menu and display or deactivate the code. - 19 - User manual Tempo...

  • Page 22: Program Menu

    PROGRAM MENU PROGRAM The menu “program” allows you to: create a new program check created programs PROGRAM change or delete a created program CHECK delete all programs PROGRAM MODIFY PROGRAM DELETE - 20 - User manual Tempo...
  • Page 23 1 to 7: - by pressing the key to move to the next day without selecting the current day - by pressing the key to select/deselect the current day and move to the next CONFIRM ? - 21 - User manual Tempo...
  • Page 24 * times of sunrise and sunset are automatically calculated by the device according to geographic coordinates set during installation. In place of sunrise and sunset times it’s possible to use the times of civil twilight (see page 16). - 22 - User manual Tempo...
  • Page 25 * Date: select day, month, year (program carried “only once in the life of the product”). If the month is not specified, the program is carried out all days xx of all months of the specified year. - 23 - User manual Tempo...
  • Page 26 Carried out program not carried out because in the same day it is provided the beginning of the week program (even if the daily program of Monday begins and ends before the beginning of the weekly - 24 - User manual Tempo...

  • Page 27: Program Menu: New

    Program menu: new 27/04/2021 PROGRAM 12:11 PROGRAM - 25 - User manual Tempo...

  • Page 28: Program Menu: New Daily Timed

    TIMED DAILY HOLIDAY PULSE OFF Program parameters - on/off: on time and off time - on pulse: time and pulse duration (max 59 seconds) - off pulse: time and pulse duration (max 59 seconds) - 26 - User manual Tempo...

  • Page 29: Program Menu: New Weekly Timed

    - on pulse: day (or days)* and pulse time, pulse duration (max 59 seconds) - off pulse: day (or days)* and pulse time, pulse duration (max 59 seconds) * See “Select days” on page 21 - 27 - User manual Tempo...

  • Page 30: Program Menu: New Holiday Timed

    HOLIDAY OFF: the relay is OFF from the beginning to the end of Holiday program HOLIDAY ON: the relay is ON from the beginning to the end of Holiday program Program parameters - beginning of the program - end of the program - 28 - User manual Tempo...
  • Page 31 VV month of all years in the same day. Otherwise is signaled XX/MM/ZZ of all months of the specified ZZ year XX/VV/ZZ of the specified VV month of the specified ZZ year - 29 - User manual Tempo...

  • Page 32: Program Menu: New Astro Night

    Program menu: new astro night Choose Nights nights programs ASTRO NIGHT TIMED NIGHT NIGHT ASTRO CONFIRM ? ASTRO DAILY ASTRO WEEKLY ASTRO HOLIDAY - 30 - User manual Tempo...
  • Page 33 Selected nights: between day 1 and 2, between day 2 and 3, between day 4 and 5 Selected nights: between day 1 and 2, between day 3 and 4, between day 7 and 1 - 31 - User manual Tempo...
  • Page 34 Turning on at sunrise for a short settable (also if off time is after sunrise). PULSE duration (pulse, max 59 seconds). *** Switching on occurs before sunrise of the entire set time interval (also if on time is before sunset). - 32 - User manual Tempo...
  • Page 35 (**) DELAY DELAY Turning on at sunrise for a settable Turning on at sunset for a settable short duration (pulse, max 59 seconds). short duration (pulse, max 59 seconds). PULSE PULSE - 33 - User manual Tempo...

  • Page 36: Program Menu: New Astro Daily

    WEEKLY PULSE OFF ASTRO HOLIDAY Program parameters - on/off: on time and off time - on pulse: time and pulse duration (max 59 seconds) - off pulse: time and pulse duration (max 59 seconds) - 34 - User manual Tempo...

  • Page 37: Program Menu: New Astro Weekly

    - on pulse: day (or days)* and pulse time, pulse duration (max 59 seconds) - off pulse: day (or days)* and pulse time, pulse duration (max 59 seconds) * See “Select days” on page 21 - 35 - User manual Tempo...

  • Page 38: Program Menu: New Astro Holiday

    HOLIDAY ON: the relay is ON from the beginning to the end of holiday program. Program parameters - beginning of the program - end of the program - 36 - User manual Tempo...
  • Page 39 VV month of all years in the same day. Otherwise is signaled XX/MM/ZZ of all months of the specified ZZ year XX/VV/ZZ of the specified VV month of the specified ZZ year - 37 - User manual Tempo...

  • Page 40: Program Menu: Check

    Note: a program requires more screens to be displayed: - press the key to move from the first to the second part of the same program - press the keys to switch from one program to another - 38 - User manual Tempo...
  • Page 41 Choose Choose the period the type CHECK DAILY NIGHT ON - OFF Check programs DAILY CHECK PULSE ON DAILY CHECK DAILY WEEKLY PULSE OFF CHECK HOLIDAY - 39 - User manual Tempo...

  • Page 42: Program Menu: Modify

    - press the keys key to switch from one program to another To modify: press for a long time (at least 3 seconds) the key To delete: press for a long time and simultaneously the keys - 40 - User manual Tempo...
  • Page 43 Choose the Choose the period type MODIFY DAILY NIGHT ON - OFF Check programs DAILY MODIFY PULSE ON DAILY MODIFY DAILY WEEKLY PULSE OFF MODIFY HOLIDAY - 41 - User manual Tempo...
  • Page 44 Program menu: delete 27/04/2021 PROGRAM 12:11 PROGRAM Delete DELETE programs “Delete” menu is used to delete all stored programs on the device. Note: to delete one single program to see “modify” mode (see page 40). - 42 - User manual Tempo...

  • Page 45: Hour Couter Menu

    3 seconds until the display shows “ HOUR COUNTER DELETE ? ” 2. confirm by pressing (press to exit without zeroing) HOUR COUNTER HOUR COUNTER 27/04/2021 002408 HOURS DELETE ? 12:11 HOUR COUNTER Confirm delete - 43 - User manual Tempo...

  • Page 46: Reset Menu

    Holiday programs reset: deletes all saved holiday programs Astro programs reset: deletes all saved astronomical programs Counter reset: resets the hour counter of relay operating Reset all: carries out all the above described resets and deletes the language and PIN protection - 44 - User manual Tempo...
  • Page 47 RESET RESET 27/04/2021 CONFIRM ? SETTINGS 12:11 RESET PRG TIME RESET HOLIDAY RESET PRG ASTRO RESET HOUR COUNTER RESET - 45 - User manual Tempo...

  • Page 48: Firmware Menu

    FIRMWARE MENU This menu shows the firmware installed in the device, where: 27/04/2021 185 identification code of the model Tempo 12:11 FIRMWARE VERSION 23 firmware revision 185-23 - 46 - User manual Tempo...

  • Page 49: Error Signals

    * In this case, press the keys for a long time until already stored (see page 23) RESET occured. If the error persists, contact Vemer technical ERROR 007 Attempt to set an off pulse on if an on impulse support (tel.+ 39.0439.879885).

  • Page 50: Reference Standards

    An efficient sorted waste collection for the environmentally friendly disposal of the used device, or its subsequent recycling, helps avoid the potential negative effects on the environment and people’s health, and encourages the re-use and/or recycling of the construction materials. - 48 - User manual Tempo...
  • Page 52 Vemer S.p.A. I - 32032 Feltre (BL) • Via Camp Lonc, 16 06-2021 e-mail: info@vemer.it - web site: www.vemer.it...
