Etneo BGA ETA-H15 Operation Manual

Bga/smd rework station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BGA ETA-H15
BGA/SMD Rework Station
Operation Manual
Catalogue
1. Summary ................................................................................................................................................... 1
2. Product Picture .......................................................................................................................................... 2
3. The unit is supplied with ........................................................................................................................... 2
4. Safety Instructions ..................................................................................................................................... 2
5. Specifications and Technical Parameters ................................................................................................... 3
5.1 Specifications .......................................................................................................................................... 3
5.2 Technical Parameters ............................................................................................................................... 4
6. Install and Connect System ....................................................................................................................... 5
6.1 Place System ............................................................................................................................................ 5
6.2 Install RPC............................................................................................................................................... 5
6.3 System Connecting .................................................................................................................................. 5
7. control box Instructions ............................................................................................................................. 6
8. IR System Operation ................................................................................................................................. 7
8.1 Part Function ........................................................................................................................................... 7
8.2 Parameters Setting ................................................................................................................................... 7
8.3 Operating technics instruction ............................................................................................................... 15
9. PL System Operation ............................................................................................................................... 17
9.1 Component function .............................................................................................................................. 17
9.2 Aligning Technics .................................................................................................................................. 18
10、Equipment Maintenance ...................................................................................................................... 19
11、QSOFT brief instruction ........................................................................................................................ 1
11.1 operation interface ................................................................................................................................. 1
11.2 counterpoint operation interface ............................................................................................................ 2
11.3 parameter testing interface ..................................................................................................................... 3
11.4 curve analysis interface .......................................................................................................................... 4
11.5 advanced setting interface ...................................................................................................................... 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGA ETA-H15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Etneo BGA ETA-H15

  • Page 1: Table Of Contents

    BGA ETA-H15 BGA/SMD Rework Station Operation Manual Catalogue 1. Summary ..............................1 2. Product Picture ............................2 3. The unit is supplied with ........................... 2 4. Safety Instructions ............................. 2 5. Specifications and Technical Parameters ....................3 5.1 Specifications ............................3 5.2 Technical Parameters ..........................
  • Page 3 IR Software, thus meeting the higher technical demands of modern electronic industry. It becomes one of the most valued electronic equipments in this field. BGA ETA-H15 consists of two parts: IR ETA-H15 Infrared Rework System and PL ETA-H15 Precision Placement System.

  • Page 4: Product Picture

    BGA ETA-H15 OPERATION MANUAL 2. Product Picture 3. The unit is supplied with Please check whether the following parts are included and intact. * Main Unit BGA ETA-H15 * Control box * IR Camera—RPC * BGA ETA-H15 Operation Manual * video line...

  • Page 5: Specifications And Technical Parameters

    BGA ETA-H15 OPERATION MANUAL Note: The laser alignment device includes a secondary laser device, so don’t see the laser bean directly. Note: When the system happens trouble and needs maintenance, it should be carried on by a experienced and authorized technician or expert, or contact with service agent and factory.

  • Page 6: Technical Parameters

    BGA ETA-H15 OPERATION MANUAL 9．The operation of Camera on PL and IR alternates according to the movement of PL’s telescopic arm. Brightness of IR camera is controlled by keyboard of PL. Net weight： 75kg Packaging dimension： 1050*800*880（mm） 5.2 Technical Parameters TL：Melting temperature of solder...

  • Page 7: Install And Connect System

    BGA ETA-H15 OPERATION MANUAL 6. Install and Connect System 6.1 Place System * Unwrap the packing of the unit, then take out BGA ETA-H15 Main Unit and put it on the horizontal worktable. 6.2 Install RPC 1. Unscrew RPC Fixing Knob on the RPC Fixing Bracket and install RPC in the Bracket, tighten knob.

  • Page 8: Control Box Instructions

    BGA ETA-H15 OPERATION MANUAL Connect USB line Connect video line Connect control box Connect ground line 7. control box Instructions IR system Key During selecting working flow period, knob UP and DOWN are used for controlling the moving upward or downward of cursor but when in standby interface, it can increase or decrease the digital.

  • Page 9: Ir System Operation

    BGA ETA-H15 OPERATION MANUAL L. Function of “YELLOW” key: rotate it, adjust yellow light of camera; press it, close the light. 8. IR System Operation 8.1 Part Function * Adjust the Aperture System The Aperture System of Top Radiator can be adjust from 20×20 (mm) to 60×60 (mm) by two Adjustment Knobs.
  • Page 10 BGA ETA-H15 OPERATION MANUAL you forget the setting password, you can input “159” to make the password of system come back to initial password “000”. Note: If want to modify any parameter system, you must input password, otherwise, you can only browse them.
  • Page 11 BGA ETA-H15 OPERATION MANUAL 2. 2．If you want to modify the next working flow, operate as the following B item; If you don’t want to modify, please press DOWN knob to browse the following parameter settings. B. Modify working flow For instance: Modify the working flow and make it become 1 flow.
  • Page 12 BGA ETA-H15 OPERATION MANUAL select: 1 type: desolder After finishing modifying working mode, if you want to modify laser alignment mode, operate as D item shows; if no need to modify it, please press DOWN key to browse the next parameter settings.
  • Page 13 BGA ETA-H15 OPERATION MANUAL Melting temperature of solder. At this temperature, the solder starts to melt down and turn into liquid. Heating time rising from T1 to T2. User can set the value in the range of 0~300s. Heating time rising from T2 to T3. User can set the value in the range of 0~300s.
  • Page 14 BGA ETA-H15 OPERATION MANUAL Press MENU Press MENU T1: 130℃ T1: 130℃ _S1: 060s S1: 060s rotate MENU Press OK T1: 130℃ T1: 130℃ S1: 060s S1: 070s T1: 130℃ S1: 070s rotate MENU Press MENU S1: 070s T2: 150℃...
  • Page 15 BGA ETA-H15 OPERATION MANUAL rotate MENU Press OK rotate MENU rotate MENU T2: 160℃ S2: 050s S2: 050s T3: 200℃ rotate MENU rotate MENU T3: 200℃ S3: 010s S3: 010s TL: 183℃ Press MENU Press MENU TL: 183℃ TL: 183℃...
  • Page 16 BGA ETA-H15 OPERATION MANUAL D. Modify laser alignment mode For instance: Modify the laser alignment mode and set it to “on”. rotate MENU Press MENU select: 1 type: desolder type: desolder laser: off rotate MENU Press OK type: desolder type: desolder...

  • Page 17: Operating Technics Instruction

    BGA ETA-H15 OPERATION MANUAL If above status happens, user should stop operating. 2. During the upward or downward movement of Top Heater or holding out and drawing back of fan arm, if it doesn’t reach over 10 seconds, the unit will come back to initial state all and singular in spite of what state it is here.
  • Page 18 BGA ETA-H15 OPERATION MANUAL B. Select the required flow, if need to modify, perform relevant operation. C. Select “solder” working mode. D. Select “IR” laser alignment mode. E. No change to communication speed, and press EXIT key to exit. IR window shows: TC:022˙C Tb:019˙C...

  • Page 19: System Operation

    BGA ETA-H15 OPERATION MANUAL F. Press START key and the system start working, perform content of selected flow. 7. After pressing START key, Bottom Heater starts to heat up and Top Heater moves downwards and reach to bottom. 8. IR window will show a series of setting temperatures during working. Indicate when it reaches T0, T1, T2, T3 and TL.

  • Page 20: Aligning Technics

    BGA ETA-H15 OPERATION MANUAL adjusting position. If you want to lock PCB Fixture, please screw down Fixture Fixed Knob. * When the component is aligned accurately, screw down Fixture Fixing Knobs first and then adjust accurately. Turn “PL Micro-adjustment knob1 to make PCB Fixture move right and left for adjusting PCB’s right and left position.

  • Page 21: 10、Equipment Maintenance

    BGA ETA-H15 OPERATION MANUAL component should be picked up from its center. As soon as the vacuum nozzle touches component, the vacuum pump starts to work and pick up component. 2． Press Sucks key, prism auto judge stick out or not. Follow flow auto process.

  • Page 22: 11、Qsoft Brief Instruction

    11 SOFT brief instruction 11.1 operation interface 1. Operation interface: this interface reaction executive condition of flow , we can real-time operate by this interface. 2. parameter of operation interface, be setting from “parameter testing interface”, in operation interface do not need setting.

  • Page 23: Counterpoint Operation Interface

    close”,“cooling fan enter ” , “cooling fan out”. 11.2 counterpoint operation interface We can complete total counterpoint operation by counterpoint operation interface, contain focus, magnify reduce, suck component, etc. Counterpoint display Counterpoint working area status bar Up light close/up light open: click close or open top blue light. Down light close/down light open: click close or open top yellow light.

  • Page 24: Parameter Testing Interface

    Exit: exit “counterpoint operation” interface, enter “operation interface”, current state have no change. When working area display aligning arm in, then status bar location of aligning arm: external; When working area display vacuum open, then vacuum state in status: “close”. When status bar display “high speed mode”, express move speed is high, when status bar display “low speed mode”, express move speed is low.

  • Page 25: Curve Analysis Interface

    “save curve”，can save current parameter and flow curve. In parameter setting display, can set parameter, setting range refer to 5.1. T0: only satisfy “TIR≥T0”, top infrared heater can start working. No special purpose, please set Tir＞ Can also click “flow select” in “edit flow display”, call saved parameter and modify it. heat dissipation air quantity: 35～100.
  • Page 26 Password setting: can set “enter password” and “parameter protect” two type password. The people who obtain enter password can operation this software, but no parameter modify power. The people who obtain parameter protect can operation this software, and modify parameter. If not set parameter protect password, people who obtain enter password also modify parameter.
